- Page 1 A932 OWNER'S MANUAL ASSEMBLY INSTRUCTIONS XTENSION PDF created with pdfFactory trial version www.pdffactory.com...
- Page 2 A. Introduction Back cover Front top cover Frame Front cover (B) Front cover (A) Usage sticker Back cover Back cushion Selection pin (3.5 lbs / 1.5 kgs) Rotator Selection pin (6.5 lbs / 3 kgs) Seat back Cord Stack fork Seat pad Weight stacks (11 lbs / 5 kgs) Foot press plate...
-
Page 3: List Of Parts
B. List of Parts 1. One frame. 2. One seat pad. 3. One back cushion 4. One seat back 5. Four hexagon head bolts M10 x P1.5 x L20 for frame and seat pad 6. Four spring washers M10 for frame and seat pad 7. - Page 4 C. STEP BY STEP INSTRUCTION: 1. Hold the side frame during assembly. Tighten the side frame to the recumbent seat frame with screws provided (item 5,6,7 as listed in parts list). (See Fig. 1) Fig.1 2. Secure the seat back with screws provided (item 8 as listed in parts list). (See Fig. Fig.2 PDF created with pdfFactory trial version www.pdffactory.com...
- Page 5 3. Assemble the back cushion to the rotator, tighten it with screws provided. (See Fig.3) Fig.3 PDF created with pdfFactory trial version www.pdffactory.com...
- Page 6 D. Operating Instruction: 1. The rotator adjusting pin is used for adjusting the rotator to the proper initial position for the user. (See Fig. 4) rotator adjusting pin Fig.4 2. The plate adjusting pin is used for user to adjust the plate to the proper position. (See Fig.
- Page 7 3. The rotating range is shorten when rotator adjusting pin moves to "A", the rotating range is lengthen when rotator adjusting pin move to "B". (See Fig. 6 or 6-1) rotator range adjusting pin Fig.6 Fig.6 Fig.6-1 PDF created with pdfFactory trial version www.pdffactory.com...
- Page 8 HOW TO USE THE MINOR WEIGHT STACK 1. To have a minor weight stack selection, insert the upper pin to add 3.5Lb/1.5kg or the lower pin to add 6.5Lb/3kg. 2. Pull the pin to release the minor weight stack. (See Fig. 7) Fig.7 PDF created with pdfFactory trial version www.pdffactory.com...
- Page 9 F. Belt Adjusti ng 1. If the belt is too tight or too loose, loosen the nut A as shown in the diagram first, then adjust the nut B, if the belt length is too long, adjust downward; if the belt length is too short adjust upward. Adjust the belt to the proper position then tighten the nut A.
-
Page 10: Usage Instruction
Usage Instruction: PDF created with pdfFactory trial version www.pdffactory.com...
