A958
OWNER'S MANUAL
ASSEMBLY INSTRUCTIONS
L
L
C
YING EG
URL
PDF created with pdfFactory trial version
www.pdffactory.com

Advertisement

loading

Summary of Contents for SPORTS ART A958

  • Page 1 A958 OWNER'S MANUAL ASSEMBLY INSTRUCTIONS YING EG PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 2 A. Introduction Rear cover Front top cover Side frame Front cover (A) Usage sticker Front cover (B) Back cover Selection pin (3.5 lbs / 1.5 kgs) Rotator Selection pin (6.5 lbs / 3 kgs) Cord Leg cushion Stack fork Weight stacks (11 lbs / 5 kgs) Upholstery B Upholstery A Foot pad...
  • Page 3: List Of Parts

    B. List of Parts 1. One side frame 2. One main frame 3. One leg cushion 4. One handle bar 5. Four hexagon head bolts M10 x P1.5 x L30 for side frame and main frame 6. Four spring washers M10 for side frame and main frame 7.
  • Page 4 C. STEP BY STEP INSTRUCTION: 1. Hold the frames during assembly, then tighten the frames with screws provided (item 5,6,7 as listed in parts list). (See Fig. 1) Fig.1 2. Tighten the handrail with screws provided (item 8,9 as listed in parts list). (See Fig.
  • Page 5 3. Assemble the leg cushion to rotator tightly with screws as shown in the diagram. (See Fig.3) Fig.3 PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 6 D. Operating Instruction: 1. The rotator adjusting pin is used for adjusting the rotator to the proper initial position for the user as shown in the diagram. (See Fig. 4) rotator adjusting pin Fig.4 2. The Plate adjusting pin is used for user to adjust the plate to the proper position as shown in the diagram.
  • Page 7 3. The rotating range is shorten when rotator adjusting pin moves to "A", the rotating range is lengthen when rotator adjusting pin moves to "B". (See Fig. 6 or 6-1) Rotating range adjusting pin Fig.6 Fig.6-1 PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 8 HOW TO USE THE MINOR WEIGHT STACK 1. To have a minor weight stack selection, insert the upper pin to add 3.5Lb/1.5kg or the lower pin to add 6.5Lb/3kg. 2. Pull the pin to release the minor weight stack. (See Fig. 7) Fig.7 PDF created with pdfFactory trial version www.pdffactory.com...
  • Page 9 F. Belt Adjusting Instruction: 1. If the belt is too tight or too loose, loosen the nut A as shown in the diagram first, then adjust the nut B, if the belt length is too long, adjust downward; if the belt length is too short adjust upward. Adjust the belt to the proper position then tighten the nut A.
  • Page 10: Usage Instruction

    Usage Instruction: PDF created with pdfFactory trial version www.pdffactory.com...
