Page 1: Operating Instructions
Thank you for buying a Panasonic product. Please take the time to become familiar with the operating instructions and how it is set up. Keep this manual handy for future reference. Quick Start Guide for Software on page 13. Be sure to read page 4 before unpacking the provided CD-ROM.
Page 2: For Your Safety
For Your Safety The power switch turns the DVD Video Camera on and off, leaving the date/time feature unaffected. If the camera/recorder is to be left unattended for a long period of time, turn it off . WARNING : TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
Page 3 Panasonic Model No.: VDR-M50PP VDR-M70PP Responsible party: Matsushita Electric Corporation of America One Panasonic Way, Secaucus, NJ 07094 Support Contact: Panasonic Consumer Electronics Company 1-800-211-PANA (7262) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 4: Be Sure To Read The Following Before Opening The Cd-Rom Package
Be sure to read the following before opening the CD-ROM package This Agreement will take effect at the moment you open the package of the storage device (CD-ROM) provided with this product, if you agree to the terms herein. If you do not accept the terms of this Agreement, immediately return the unopened package of storage medium and enclosed materials (printed matter, external package, and all others) to your dealer, or return only the package of storage medium to your dealer.
Page 5: Important Safeguards
In addition to the careful attention devoted to quality standards in the manufacture of your video product, safety is a major factor in the design of every instrument. But, safety is your responsibility too. This page lists important information that will help to assure your enjoyment and proper use of DVD Video Camera and accessory equipment.
Page 6 An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn. Power Lines — An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits.
Page 7: Cautions When Using
Cautions When Using Handle the liquid crystal display (LCD) with care: • The LCD is a very delicate display device: Do not press its surface with force, hit it or prick it with a sharp object. • If you push the LCD surface, unevenness in display may occur. If unevenness does not disappear, turn the DVD Video Camera off, wait for a few moments, and then turn it on again.
Page 8 Heat on surface of product: • The surface of the DVD Video Camera will be slightly warm, but this does not indicate a fault. Screen on connected TV: • Never leave the disc navigation screen, still image or camera image displayed on your TV to which the DVD Video Camera is connected: Doing so could result in displayed image retention or phosphor degradation of TV screen.
Page 9 Be careful of moisture condensation: • When you move the DVD Video Camera between places where the difference in temperatures is great - such as entering a lodge from a ski slope or going out of a cooled room or vehicle - condensation (vapor in air warmed or cooled to water droplets) could occur on the lens and/or inside the DVD Video Camera.
Page 10: Cautions When Storing
• Panasonic cannot compensate for any damages caused when recording is not made normally or recorded contents cannot be played back because of a defect in the DVD Video Camera, disc or card. Also, Panasonic cannot be responsible for your recorded video and audio.
Page 11: Table Of Contents
Although the external appearances of VDR-M50PP and VDR-M70PP are different, the method of operating both models is identical. The illustrations of VDR-M70PP are used in this text.
Page 12: Introduction
Introduction lYou can record even during playback (page 51) Unlike tape devices, you do not need to search for the recording start position or locate the beginning of a blank portion. New recording will not overwrite any previously recorded data. If you stop playback midway and start recording, overwrite will not occur.
Page 13: Quick Start Guide For Software
Install this driver when using stills and images recorded on a DVD-RAM disc on a PC. DVD-MovieAlbumSE By combining DVD-MovieAlbumSE with VDR-M50PP/VDR-M70PP DVD Video Camera, it is possible to use playback, recording and editing on the DVD-RAM disc. It is also possible to transfer extracted data and title information etc.
Page 14: Cautions For Use
Export motion image data to PC using DVD-MovieAlbumSE. MyDVD program will automatically start. (see page 142 for details) Edit motion images and introduce interactive DVD menus using MyDVD Software. Insert a new DVD-R disc into the DVD Video Camera. • When making an original DVD-R disc using MyDVD software, a message for initialization appears on the LCD of DVD Video Camera.
Page 15: Table Of Contents
Table of Contents Important Information ... 2 Be sure to read the following before opening the CD-ROM package ... 4 IMPORTANT SAFEGUARDS ... 5 Cautions When Using ... 7 Cautions When Storing... 10 Suggestions and Restrictions ... 10 Read This First ... 11 About This Manual...
Page 16 Other Video Cameras ... 76 Recording (Dubbing) Images on Other Video Devices ... 77 Advanced Techniques Understanding Flow of Menus ... 78 Setting Up Camera Functions... 80 Selecting Shooting Mode to Match the Subject (Switching Program AE Mode) ... 80 Adjusting Color (White Balance)...
Page 17 Installing Software Compatible PC for use with DVD Video Camera: VDR-M50PP/VDR-M70PP... 130 Operations will not be guaranteed under the following conditions ... 130 Contents on Provided CD-ROM ... 131 Installing USB Driver ... 133 Installing DVD-RAM Driver ... 135 Installing DVD-MovieAlbumSE ... 138 Installing MyDVD ...
Page 18: Checking Provided Accessories
Checking Provided Accessories Make sure that you found all the following accessories in the package: Battery Pack (CGA-DU14A): Portable power supply for this DVD Video Camera. Charge it before use. Power Cable: Connect between household AC outlet and AC adaptor. AV/S Input/Output Cable: (EW12522) Used when playing back the DVD Video Camera picture to a TV screen, or input or...
Page 19: Names Of Parts
The BATTERY EJECT switch is located on the bottom of this DVD Video Camera: Slide it when removing the battery pack. Although the external appearances of VDR-M50PP and VDR-M70PP are different, the method of operating both models is identical. VDR-M70PP illustrations are used in this manual.
Page 20 14 Viewfinder (P. 7, 37) 15 Diopter control (P. 37) To adjust the focus of image appearing in the viewfinder (Pull out the viewfinder.). 16 ACCESS/PC indicator (P. 9, 51, 52) Will blink or light when the disc in DVD Video Camera is accessed (write or read is executed) or the DVD Video Camera is connected to PC.
Page 21: Back Light (Backlight Compensation)
EXPOSURE AUTO FOCUS DISPLAY 28 AUTO button (P. 67) To switch the DVD Video Camera to full automatic. 29 FOCUS button (P. 64) To switch between manual focus and auto-focus. 30 EXPOSURE button (P. 66) Press this button to adjust the exposure. 31 BACK LIGHT (backlight compensation) button (P.
Page 22 41 REC button (P. 51, 52) 42 DIGITAL ZOOM button (P. 57) 43 Reverse skip button (P. 61) 44 Reverse search button (P. 60) 45 DISC NAVIGATION button (P. 95) 46 MENU button (P. 40, 79, 101) * The buttons on remote controller will function the same as those on DVD Video Camera. 47 ZOOM T button (P.
Page 23: Setting Up The Battery Pack
Setting Up the Battery Pack The CGA-DU14A battery pack provided with this DVD Video Camera has not been charged at purchase time: Charge it before using the DVD Video Camera. Note • Be sure to use the specified battery pack CGA-DU14A (provided) for the DVD Video Camera: using other batteries could cause the DVD Video Camera to malfunction, or result in fire.
Page 24: Before You Begin
Try to Record and Play Back Using Disc (Video and Photo) • It is recommended that you use a DVD-RAM disc for trial recording, since Before You Begin you can delete the recorded contents (See page 28). You can record both videos and photos on DVD-RAM disc; only videos on DVD-R disc. Connect power supply (P.
Page 25 Start recording (P. 51). 1. Open the LCD monitor (See page 38). 2. While holding the switch at the center of power switch, set the switch to “ ” or “ Note When using an unformatted disc, format (initialize) it on this DVD Video Camera. If unformatted disc is inserted into this DVD Video Camera, a message will appear: Format the disc following the instructions on screen (P.
Page 26: Try To Record And Play Back Using Card (Photo)
Try to Record and Play Back Using Card (Photo) Only photos can be recorded on card. Connect power supply (P. 45). DC cord Connect them in sequence of the digits. Insert a card (P. 49). 1. Open the cover of card insertion slot with power turned off.
Page 27 Start recording (P. 52). 1. Open the LCD monitor (See page 38). 2. Set the LOCK switch to (to the right). View the playback of recorded content on LCD monitor. 1. Open the LCD monitor (P. 38). 3. While holding the switch at the center of power switch, set the switch to “...
Page 28: Available Discs
DVD Video Camera: It will not be removable. Note • It is recommended that you use Panasonic discs, since their compatibility with this DVD Video Camera has been confirmed. Using a disc other than those made by Panasonic may not allow the DVD Video Camera to deliver optimum performance.
Page 29: Information On Dvd-R Disc
Information on DVD-R Disc You cannot record a still on DVD-R disc, or delete any recorded images or data. For optimum recording on DVD-R disc, this DVD Video Camera writes control data to the disc in order to automatically make adjustments when it is inserted and ejected accompanying recording.
Page 30: Handling Discs
Handling Discs lUsing discs DVD-RAM and DVD-R discs are very delicate recording media. Carefully read the following cautions and observe them: • When using a disc in this DVD Video Camera, be sure to keep it in Round DVD Holder. •...
Page 31: Available Cards
SD Memory Card. When MultiMediaCard is used, the performance of certain features may be slightly slower than advertised. • We recommend that you use a Panasonic brand SD Memory Card. • This DVD Video Camera can play back image data...
Page 32: Storage Capacity Of Disc Or Card
Storage Capacity of Disc or Card Recordable Time of Movie (Video) The recordable time will vary depending on the recording quality: See page 86 for the setting of recording quality. Movie recordable time on one disc (on single side) (when recording only movies) Recording quality DVD-RAM XTRA...
Page 33: Recordable Stills (Photos) On Disc
Recordable Stills (Photos) on Card The number of recordable stills will vary depending on the recording quality: see page 87 for the setting of recording quality. For VDR-M50PP Recording quality Capacity FINE NORM 8 MB Approx.
Page 34: Setups
Setups This section explains preparations for recording - setting up the DVD Video Camera and battery pack. Setting Up the DVD Video Camera Holding DVD Video Camera Using Grip Belt Insert your right hand from the bottom of DVD Video Camera up to the base of your thumb.
Page 35: Attaching Shoulder Belt
To use as a Grip Belt again Attach the tip of the grip belt to the DVD Video Camera (1). Press down the lock cover in the direction of the arrow so that the belt will not fall out (2). Attaching Shoulder Belt Be sure to pass through the 2 slots.
Page 36: Inserting Battery Into Remote Controller
Inserting Battery into Remote Controller Insert the provided button type battery into remote controller. Slide the cover to remove it. Insert the button type battery with the positive R terminal facing up. Removing Battery from Remote Controller While pushing the battery stopper, slide the battery out.
Page 37: Viewing Subject Through Viewfinder
lUsing Remote Controller To operate the DVD Video Camera with the remote controller, point it at the infrared receiver before pressing buttons. If it does not work properly, do not forget to point it at the receiver to repeat the action. The remote controllable distance is up to 16 feet (5 m).
Page 38: Viewing Image On Lcd Monitor Screen
Viewing Image on LCD Monitor Screen If you open the LCD monitor, you can monitor subject image on the LCD screen. Open the LCD monitor. The LCD monitor has a spot where you can hook your finger. Hook the finger there to open the monitor. lRange of LCD monitor movement The LCD monitor can be opened up to approximately 90º.
Page 39: Closing Lcd Monitor
Closing LCD Monitor Before closing the LCD monitor, be sure to reset it at a right angle to the DVD Video Camera. Close the LCD monitor, with the LCD screen facing inward, until a click is heard. Note • Be sure to return the LCD monitor to a right angles to the DVD Video Camera before closing it.
Page 40: Setting Date And Time
Setting Date and Time Set the current date and time so that the date and time at which you make a recording can be recorded correctly. The following procedure can also be used to correct the date and time you have already set. Turn the DVD Video Camera on.
Page 41: Changing Display Format Of Date And Time
Changing Display Format of Date and Time You can select one of three date display formats: month/day/year, day/month/year, or year/month/day. The time display format will also change as follows: Display format M/D/Y D/M/Y Y/M/D Press the MENU button. The menu screen will appear. Use the joystick to choose “Date Mode”...
Page 42: About The Battery Pack
About the Battery Pack Attaching Battery Pack to DVD Video Camera Fit the battery pack to the battery attachment platform on this DVD Video Camera and slide it upward until a click is heard. Terminal must face up. Removing Battery Pack After using the DVD Video Camera, remove the battery pack from it.
Page 43 (with no zoom operation, etc.) For your reference, the approximate DVD Video Camera recordable time with fully charged battery pack [with model CGA-DU14A]: VDR-M50PP Video quality DVD-RAM disc mode XTRA When using approx. 140 min...
Page 44: Remaining Battery Level Indicator
Remaining Battery Level Indicator When the battery pack is used to power the DVD Video Camera, the battery remaining level appears in the viewfinder or on the LCD screen as follows: Fully charged Note • If you use the optional CGA-DU07A battery pack at low temperatures, “ time may be shorter.
Page 45: Using Dvd Video Camera With Ac Adaptor
Using DVD Video Camera with AC adaptor It is recommended that you use the AC adaptor to power the DVD Video Camera from a household AC outlet when you perform settings on it, play back or edit images, or use it indoors. Note Be sure to use the specified AC adaptor to power the DVD Video Camera.
Page 46: Inserting And Removing Disc
Inserting and Removing Disc Inserting Disc Press down the DISC EJECT lever once and release A few moments after the ACCESS/PC indicator blinks, the cover of disc insertion compartment will open slightly. Gently open the cover by hand until it stops. Insert the disc, in Round DVD Holder, into the disc guide until it stops.
Page 47 Note • Disc cannot be inserted or removed unless the battery pack or AC adaptor is connected to DVD Video Camera. • See page 74 for how to set disc in Round DVD Holder. • If there is some delay before recording starts, refer to “Check 4”...
Page 48: Removing Disc
Removing Disc Set the power switch to “OFF” to turn the DVD Video Camera off. Press down the DISC EJECT lever once and release it. In a moment, the cover of disc insertion compartment will open slightly. Gently open the cover until it stops.
Page 49: Inserting And Removing Card
Inserting and Removing Card Turn the DVD Video Camera off. Open the cover of card insertion slot. Insert card with its contacts inward until it locks. Removing Card Push the center of card edge: The card will come out so that it can be held by fingers.
Page 50: Basic Techniques
Basic Techniques This section explains the basic techniques of recording movies and still images, and also basic settings on DVD Video Camera. Basic Operation of DVD Video Camera Turning DVD Video Camera On or Off While holding down the button at the center of power switch, set the switch according to each recording function: Set to “...
Page 51: Recording Movie
For various functions available during recording, see “Setting Up Camera Functions” on page 80. • Panasonic cannot be responsible for video and audio that cannot be recorded or edited because of any defect. • The power switch can be changed even during recording, but the operation will not be changed.
Page 52: Recording Stills
Recording Stills Note Recording of still images is possible on DVD-RAM disc and card. ACCESS/PC indicator REC button Power switch Turn the DVD Video Camera on. When using DVD-RAM disc: Set the power switch to “ When using card: Set the power switch to “ ”.
Page 53: Compensating For Backlight
Compensating for Backlight When subject is lit from behind , this function will compensate for lighting so that the subject is not too dark. Press the BACK LIGHT button during recording. Backlight correction icon The backlight correction icon will appear. Note •...
Page 54: On-Screen Information
On-Screen Information Various types of information will appear in the viewfinder or on the LCD screen during recording. Information Display during Recording L IN FULL AUTO DISC ACCESS S E P 3 0 2 0 0 4 FINE The above screen is an example for explanation: It is different from the actual display.
Page 55 (Digital Zoom: Off) (Digital Zoom: 40×) [Digital Zoom: 500× (VDR-M50PP), 240× (VDR-M70PP), only in movie recording mode] Exposure correction FULL AUTO indicator Warning message Disc/Card type : DVD-RAM : DVD-R : DVD-RAM (write-protected) : DVD-R disc already finalized on this...
Page 56 lSwitching the information display mode You can switch the display mode of on-screen information: Press the DISPLAY button. The full and minimum display modes will alternate. • Full display mode: All types of information will appear. • Minimum display mode: The recording mode (see 1 on page 54) and recording status (see 7 on page 54) will appear.
Page 57: Zooming
Zooming This DVD Video Camera allows you to record using optical 18- (on VDR-M50PP) or 10- (on VDR-M70PP) power zoom and digital zoom. If you continue to hold the zoom lever on the “T” control side with Dig. Zoom 40x or 240x specified, the digital...
Page 58: Macro Recording
Use tele-conversion lens or wide-conversion lens to record subjects for stronger telefoto or wide-angle effect. Use conversion lenses with the following filter diameter. VDR-M50PP/VDR-M70PP : 37 mm Remove the lens hood on the top surface of lens, and then attach the conversion lens over the lens.
Page 59: Playing Back
Image data edited on PC or certain types of image data may not be displayed on this DVD Video Camera. • Image data recorded on another camcorder may not be playable on this DVD Video Camera. • Depending on the amount of data to be played back, it may take some time for the playback image to appear.
Page 60: Playback From Start Of Disc Or Card
Playback from Start of Disc or Card Use the Go To function (P. 62) or Disc Navigation function (P. 95) to play back from the start of disc or card. Search Playback of Movie During playback, tilt the joystick right or left and hold it: Search playback will start.
Page 61: Skip Playback Of Movie
Skip Playback of Movie During playback, tilt the joystick up or down to locate the start of desired scene. Tilt down once : To skip to the first image of the scene following the one being played back, and start playback. Tilt up once : To return to the first image of the scene being played back, and start...
Page 62: Jumping To Specified Point (Go To)
Jumping to Specified Point (Go To) Press the MENU button during playback. Choose the option (point you want to go to), and then press the A button. lSpecifying the point to view Choose “Specify” in step 2 above, and then press the A button.
Page 63: On-Screen Information Display
On-Screen Information Display Information Display during Playback Various types of information on recording will be superimposed on playback image you are viewing. No display lSwitching the information display mode Press the DISPLAY button: You can switch the display mode of on-screen information. When using disc: Recording mode Scene No.
Page 64: Manually Focusing Subject
Manually Focusing Subject The DVD Video Camera usually focuses on a subject automatically (autofocus). You can also manually focus a subject depending on the recording conditions. Focusing during Recording This DVD Video Camera automatically focuses a subject at the center of screen (auto-focus). When the DVD Video Camera is turned on, auto-focus will always be set.
Page 65 Objects not in the center of screen Objects moving rapidly Object behind glass with water droplets, dirt on it Objects with little variation in brightness, such as white wall Objects lit by neon sign, spotlight, etc. which glares or emits strong light Night view Objects that...
Page 66: Adjusting Exposure Manually
Adjusting Exposure Manually The DVD Video Camera usually adjusts the exposure automatically. You can also manually adjust the exposure depending on the recording conditions. Press the EXPOSURE button during recording. The exposure indicator will appear on the screen. Exposure indicator Use the ) ( buttons to adjust the exposure while viewing the image in the viewfinder or on the LCD screen.
Page 67: Using Auto Function
Using Auto Function Pressing the AUTO button will fully automate the camera functions. Press the AUTO button. “FULL AUTO” will be displayed on the screen of DVD Video Camera for several seconds. The following settings will reset to defaults: When setting Function full auto Program AE...
Page 68: Using External Microphone
Video Flash for use. Setting of On-screen Video Flash information AUTO * Unusable on VDR-M50PP. To external microphone jack Note • The DVD Video Camera automatically sets the shutter speed between 1/800 and 1/30 second (between 1/800...
Page 69: Connecting To A Tv
Viewing on TV Screen Connecting to a TV Use the provided AV/S input/output cable to connect the DVD Video Camera to a TV as follows: To AV input/output jack AV/S input/output cable (provided) * If your TV has an S-VIDEO input jack, you can connect the S-VIDEO plug to it. Note •...
Page 70: Viewing On Tv Screen
Viewing on TV Screen Turn on the TV and set the input selector to the Input connection the DVD Video Camera is connected to. This is often refered to as “line”. Refer to the TV instruction manual for how to switch the TV input.
Page 71: Playback On Dvd Video Recorder/Player
Playback on DVD Video Recorder/Player You can use a DVD video recorder (see “Terminology” on page 148) or DVD player that conforms to 8 cm DVD-RAM to play back DVD-RAM discs recorded on this DVD Video Camera. Note, however, that such DVD-RAM discs are not compatible with all DVD video recorders and all DVD players.
Page 72: Playback On Dvd Player
See “Terminology” on page 148 for linear PCM recording. • DVD-R discs recorded on this DVD Video Camera can be played back on Panasonic DVD players, but playback on all DVD players is not guaranteed. • Playback may not be possible on some DVD players, or...
Page 73: Removing From/And Replacing In Round Dvd Holder
The following explains the procedure for removing the disc from and replacing it in the Round DVD Holder made by Panasonic. It is recommended that you do not remove the disc from Round DVD Holder until camera recording is finished, in order to avoid getting dirt on disc.
Page 74: Replacing Disc In Round Dvd Holder
Replacing Disc in Round DVD Holder Open SIDE A of the Round DVD Holder, and replace the disc in the holder with the SIDE A mark or label surface facing up, taking care not to touch the disc surface. OPEN marks SIDE A mark side or Label surface When the Hinge of Round DVD Holder Comes Off...
Page 75: Recording (Dubbing) Images
• With VDR-M70PP, using S-VIDEO will enable you to record clearer images. • The VDR-M50PP cannot record S-VIDEO input. • Reduce the volume of external input sound heard from the built-in speaker: The loud volume may cause noise to enter the recorded image.
Page 76: Recording (Dubbing) Images From Other Video Cameras
Recording (Dubbing) Images from Other Video Cameras You can record (dub) images from other video cameras on a disc or card in DVD Video Camera. Use the AV/S input/ output cable (provided) to connect the DVD Video Camera to the other video camera. AV/S input/output cable (provided) To S-VIDEO output jack of video camera, etc.
Page 77: Recording (Dubbing) Images On Other Video Devices
Recording (Dubbing) Images on Other Video Devices You can record (dub) images played back on this DVD Video Camera, onto other video devices. Use Disc Navigation to create a play list by selecting desired scenes of those recorded on this DVD Video Camera (P.116).
Page 78: Advanced Techniques
: LCD Setup : Initial Setup Functions settable WIDE mode will not appear on VDR-M50PP. When “Wide 16:9” is specified, black bands will appear across the top and bottom of screen. * The menu screen, the screen for playing back images...
Page 79: Initial Setup
ENTER RETURN Wide (P. 84) Not displayed on VDR-M50PP. Displayed on VDR- M70PP only for movies using DVD-RAM disc. Recording Functions Setup Movie quality Rec o r d F u n c t i o n s Se t up Input selection (P.
Page 80: Setting Up Camera Functions
Setting Up Camera Functions • See page 79 for how to set. Before You Begin • No menu screen appears with external input. Selecting Shooting Mode to Match the Subject (Switching Program AE Mode) This DVD Video Camera automatically sets the shutter speed and aperture according to the subject brightness for optimum recording: You can also specify one of six modes depending on subject conditions, recording environment or purpose of filming.
Page 81: Adjusting Color (White Balance)
Adjusting Color (White Balance) This DVD Video Camera automatically adjusts the color of subject. Change the white balance setting depending on the recording conditions. Mode Setting contents Auto White balance always automatically adjusted You can manually adjust white balance to match the light source or situation Outdoor...
Page 82 Note • Do not block the infrared sensor (see “Terminology” on page 148) with hand, etc. Infrared sensor block • If a optional-user provided tele or wide-conversion lens is used, the auto white balance may not operate depending on the recording conditions. If this happens, set the mode to match the recording conditions, or manually set the white balance.
Page 83: Using The Electronic Image Stabilizer (Eis)
Using the Electronic Image Stabilizer (EIS) When you use zoom to record a magnified subject image, it will correct fuzziness in the recorded image. Press the MENU button, choose “EIS” on the “Camera Functions Setup” menu screen, and then press the A button.
Page 84: Setting To Wide Tv Screen Mode (Wide) (Only For Vdr-M70Pp)
Setting to Wide TV Screen Mode (Wide) (Only for VDR-M70PP) If you view the images recorded with “Wide 16:9” specified on a wide-screen TV (aspect ratio 16:9), screen image will be wider than the images recorded with “Wide 4:3” (aspect ratio 4:3) by the size of the areas on left and right (in dotted lines).
Page 85 The Wide setting will be kept even after the DVD Video Camera is turned off. • The VDR-M50PP does not have the Wide setting. • Even if you use the provided application software (MyDVD) and dub wide movies on DVD-RAM disc to DVD-R disc, the screen image will not be wider.
Page 86: Setting Up Record Functions
Setting Up Record Functions Switching Movie Quality (VIDEO Mode) Choose the movie quality from “XTRA” (only with DVD-RAM disc), “FINE”, “STD” and “LPCM” (only with DVD-R disc). It is recommended that you record critical subjects in “XTRA” or “FINE” when you are using a DVD-RAM disc, or in “FINE”...
Page 87: Switching Quality Of Still Image (Quality)
Switching Quality of Still Image (Quality) You can switch the still recording quality only when using card. It is recommended that you use “FINE” when recording vital images. Press the MENU button, choose “Quality” on the “Record Functions Setup” menu screen, and then press the A button.
Page 88: Receiving Image From Another Device (Input Source)
Receiving Image from Another Device (Input Source) If you wish to input an image from another device to this DVD Video Camera, you must first switch the setting on the DVD Video Camera. Refer to the explanation starting from page 75 on how to connect the DVD Video Camera to other devices or record images input from them.
Page 89: Self Timer
Note • The PHOTO Input setting can be confirmed using the on- screen information. • The PHOTO Input setting will be stored in memory even when the DVD Video Camera is turned off. • Refer to “Recording (Dubbing) Images” on page 75 to see how to connect the DVD Video Camera to another device.
Page 90: Setting Osd Output On Or Off (On-Screen Display)
Setting OSD Output On or Off (On-Screen Display) If you connect this DVD Video Camera to a TV to view images on TV screen, you can switch off the on-screen information (displayed in the viewfinder or on the LCD screen) from the TV screen. Press the MENU button, choose “OSD output”...
Page 91: Lcd Setup
LCD Setup Setting Brightness of LCD Screen (Brightness) Press the MENU button, choose “Brightness” on the “LCD Setup” menu screen, and then press the A button. The brightness adjustment bar will appear on the screen. Use the joystick for adjustment. Tilt left :The screen becomes...
Page 92: Initial Settings
Initial Settings Switching Operating Sound On or Off (Beep) Setting Beep is heard when the power switch is turned on/off, the REC button is pressed, etc. No beep is heard. Press the MENU button, choose “Beep” on the “Initial Setup” menu screen, and then press the A button.
Page 93: Turning Record Led On Or Off (Record Led)
Turning Record LED On or Off (Record LED) You can switch off the recording indicator on the front of DVD Video Camera even during recording. Setting The recording indicator will light red to show that the DVD Video Camera is recording. The recording indicator will not light even during recording.
Page 94: Resetting Menu Settings To Defaults (Reset)
Resetting Menu Settings to Defaults (Reset) You can restore menu settings to defaults [initial settings at the factory (P. 164)]. Press the MENU button, choose “Reset” on the “Initial Setup” menu screen, and then press the A button. The screen for verifying reset will appear.
Page 95: Disc Navigation
Disc Navigation Using Disc Navigation Starting or Terminating Disc Navigation Disc Navigation is a tool for editing scenes recorded on this DVD Video Camera. Following is an explanation of “scene” and “program” so that you will be able to make the most use of the Disc Navigation function.
Page 96 DVD-R disc or card is used. Cursor Still image icon Operation guide Scene number refers to display number on thumbnail display screen. No still icon will appear for card. The operation guide will vary depending on the operation status of DVD Video Camera. Appears when 13 scenes or more have been recorded.
Page 97: Playing Back From Disc Navigation Screen
Playing Back from Disc Navigation Screen Press the DISC NAVIGATION button. Use the joystick to select the desired scene. The selected scene will be framed: This is called a “cursor”. A l l Pr og r ams 0 01 / 014 Up or Down PLAY Left or Right...
Page 98: Selecting Multiple Scenes
Selecting Multiple Scenes Press the DISC NAVIGATION button. Use the joystick to select the desired scene. Press the SELECT button once: The selected scene will be framed in red and yellow. Selecting Consecutive Scenes Together Press the DISC NAVIGATION button. Use the joystick to select the desired scene.
Page 99: Functions Available With Disc Navigation
Disc Navigation Menu Functions Available with Disc Navigation Disc Navigation allows you to do the following: Function Disc or card used Deletion of scenes Editing of scenes Scene information display Setting of title Creation of play list Disc or card initialization Copy from disc to card Disc finalization Repeat play...
Page 100: Understanding Flow Of Disc Navigation Menu
Understanding Flow of Disc Navigation Menu Press the MENU button on the Disc Navigation screen: The menu screens for Disc Navigation and menu screens for disc and card will appear. See pages 78-79 and 95 for how to interpret the screen. Refer to pages indicated for details.
Page 101: Scene
Scene Deleting Scenes (Delete) You may want to delete unwanted scenes. Scenes on DVD-R disc cannot be deleted, and menu item “Delete” will not appear with DVD-R disc. Press the DISC NAVIGATION button. Select the scene to be deleted. Press the MENU button. Choose “Delete”...
Page 102 lEditing using submenu Press the MENU button before pressing the A button in step 5 (see page 101): The submenu will appear. Ed i t E x i t De l e t e ENTER RETURN Edit Exit ...To restore the Disc Navigation screen Delete ...To delete selected scenes Select Start→Current ...To select scenes from the start to the one that the cursor is on at the moment...
Page 103: Changing Images For Thumbnails (Edit - Thumbnail)
Changing Images for Thumbnails (Edit - Thumbnail) Normally, the first image of the recorded scene is displayed as a thumbnail: You can choose another image of the scene for thumbnail. If you set a vivid image to thumbnail, you can know what you recorded from a glance at the Disc Navigation screen.
Page 104: Playing Back By Skipping Scenes (Edit - Skip)
Playing Back by Skipping Scenes (Edit - Skip) You can specify “Skip” for scenes you do not want to play back: The selected scenes will be skipped. Press the DISC NAVIGATION button. Select the scene to be skipped. Press the MENU button. Choose “Scene”, “Edit”, “Skip”, and then press the A button.
Page 105: Directing Scenes Effectively (Edit - Fade)
Directing Scenes Effectively (Edit - Fade) You can add fading to the beginning and/or end of scene. There are three types of special effects: Fade Out Fade In Black: Fades in from black screen Fades out to black screen Press the DISC NAVIGATION button. Select the scene for adding special effects.
Page 106: Combining Multiple Scenes (Edit - Combine)
Combining Multiple Scenes (Edit - Combine) If you have recorded numerous short scenes, combining them will be facilitated by the use of Disc Navigation. Be sure to select consecutive multiple scenes. Combining scenes is possible only when “Category: All” is specified (page 128).
Page 107: Dividing Movies (Edit - Divide)
Dividing Movies (Edit - Divide) You can divide a scene into two parts. To delete unnecessary portion of scene, first divide the scene, and then delete the unnecessary portion. Press the DISC NAVIGATION button. Select the scene to be divided. Press the MENU button.
Page 108: Copying Stills On Dvd-Ram Disc To Card (Copy)
Copying Stills on DVD-RAM Disc to Card (Copy) Set the power switch to “ Press the DISC NAVIGATION button. Select the still to be copied. Press the MENU button. Choose “Copy” on the “Scene” menu screen, and then press the A button. The “Copy to card”...
Page 109: Locking Scenes On Card (Lock)
Locking Scenes on Card (Lock) You can lock each photo recorded on card so that it will not be deleted or edited by mistake. Set the power switch to “ Press the DISC NAVIGATION button. Select the scene to be locked. Press the MENU button.
Page 110: Designating Scenes To Be Printed (Dpof)
Designating Scenes to be Printed (DPOF) You can use DPOF to set print information, including selection of the scenes to be printed, so that you will be able to use it on a system conforming to DPOF. Note DPOF stands for digital print order format. DPOF is used to ask a print lab to print recorded stills. Set the power switch to “...
Page 111: Selecting Scenes Using Menu Screen (Select)
Selecting Scenes Using Menu Screen (Select) You can use this “Select” function to select consecutive scenes at one time. This function is useful when there are numerous scenes. Press the DISC NAVIGATION button. Press the MENU button. Choose “Select” on the “Scene” menu screen. Current scene A l l Pr ogr ams 006 / 011...
Page 112: Displaying Information Using Menu Screen (Detail)
Displaying Information Using Menu Screen (Detail) You can display various information for a scene: the recording mode, recording date/time and length, special effects and movie quality mode. Press the DISC NAVIGATION button. Select the scene whose information you wish to know. Press the MENU button.
Page 113: Program
Program What is “program”? Program refers to an assembly of scenes recorded on the same date regardless of whether they are movie or still. Scene No. 1 Scene No. 2 9:00AM Movie Movie Switching to Thumbnail Display of Specific Date (Switch) Since the scenes recorded on this DVD Video Camera are collected as “programs”...
Page 114: Playing Back Program (Play)
Playing Back Program (Play) You can play back only the selected program. Press the DISC NAVIGATION button. Press the MENU button. Choose “Play” on the “Program” menu screen, and then press the A button. Changing Title of Program (Title) The recording date/time is automatically attached to a programs as its title. You can change the recording date/time to any desired title.
Page 115 After entering the title, T I T L E choose “Enter” and then press the A button. The screen for verifying the T I T L E a t a Pa r k change in title will appear: Choose “YES”, and then press the A button.
Page 116: Play List
Play List What is “Play List”? You can create a play list on this DVD Video Camera by gathering your favorites from the recorded scenes. Since the play list is not created by copying data, you will consume little of the disc capacity by making a play list. On the other hand, deleting scenes on play list will not increase the remaining disc capacity for recording.
Page 117: Switching To Display Of Each Play List (Switch)
Switching to Display of Each Play List (Switch) Select the desired play list: The Disc Navigation screen of the selected play list will appear. Press the DISC NAVIGATION button. Press the MENU button. Choose “Switch” on the “PlayList” menu screen, and then press the A button.
Page 118: Adding Scenes To Play List (Editing Play List)
Adding Scenes to Play List (Editing Play List) Press the DISC NAVIGATION button. Press the MENU button. Choose “Edit” on the “PlayList” menu screen, and then press the A button. Use the play list select screen to select the play list to which you wish to add scenes, and then press the A button.
Page 119: Deleting Scenes From Play List (Editing Play List)
Deleting Scenes from Play List (Editing Play List) Press the DISC NAVIGATION button. Display the editing screen of the play list to be edited. Perform steps 2−4 on page 118. Move the cursor to the play list in lower row, and place the cursor on the scene to be deleted.
Page 120: Deleting Scenes Using Submenu For Editing (Editing Play List)
Deleting Scenes Using Submenu for Editing (Editing Play List) You can delete scenes from play list on the editing screen. Press the DISC NAVIGATION button. Display the editing screen of the play list to be edited. Perform steps 2−4 on page 118.
Page 121: Arranging Order Of Scenes (Move)
Arranging Order of Scenes (Move) You can move scenes only when “Category: All” is specified. Press the DISC NAVIGATION button. Press the MENU button. Choose “Switch” on the “PlayList” menu screen, and then press the A button. Select the scene to be moved, and then press the A button.
Page 122: Changing Title Of Play List (Title)
Changing Title of Play List (Title) The play lists have serial numbers based on the order in which you have created them, along with the created dates/ times: You can change these titles at any time. Press the DISC NAVIGATION button. Press the MENU button.
Page 123: Go To
Go To From the Disc Navigation screen, you can jump to the first scene or last scene. Top (End) Press the DISC NAVIGATION button. Press the MENU button. Choose “Top” or “End” on the “Go To” menu screen, and then press the A button.
Page 124: Disc Or Card Management
Disc or Card Management Verifying Remaining Free Space on Disc or Card (Capacity) You can find out how long you will be able to record on one side of disc or on card. Press the DISC NAVIGATION button. Press the MENU button. Choose “Capacity”...
Page 125: Initializing Dvd-Ram Disc Or Card (Format Disc. Format Card)
Initializing DVD-RAM Disc or Card (Format Disc. Format Card) • Take great care that power is not turned off during initialization: If the DVD Video Camera is turned off during initialization and the initialization is Before You Begin interrupted, incorrect initialization will result, and at worst, the data recorded on disc or card may be damaged.
Page 126: Updating Control Information Of Dvd-Ram Disc (Update Control Info.)
Updating Control Information of DVD-RAM Disc (Update Control Info.) Disc Navigation in this DVD Video Camera handles information on scenes, such as skip or fade, in a particular manner. If you use another device to edit a disc recorded on this DVD Video Camera, and then use the data again with Disc Navigation in this DVD Video Camera, the Disc Navigation may not appear normally.
Page 127: Finalizing Dvd-R Disc (Finalize Disc)
Finalizing DVD-R Disc (Finalize Disc) • Be sure to use the AC adaptor to power the DVD Video Camera when finalizing a DVD-R disc. Finalization cannot be executed using a battery Before You Begin pack. If the DVD Video Camera is turned off during finalization and the finalization is interrupted, incorrect finalization will result, and at worst, the disc may be damaged.
Page 128: Other Functions (Others)
Other Functions (Others) Displaying Movies or Stills Independently (Category) Scenes recorded on this DVD Video Camera will be displayed in the order of recording regardless of whether they are movies or stills. You can use the Disc Navigation screen to switch this display to stills only or movies only. Press the DISC NAVIGATION button.
Page 129: Slide Show (Continuous Playback Of Stills)
Slide Show (Continuous Playback of Stills) If you play back stills recorded on a card, the DVD Video Camera will enter playback pause mode after each still is played back. Setting Slide Show allows you to continuously play back stills. Press the DISC NAVIGATION button.
Page 130: Installing Software
We will not guarantee proper operation of this DVD Video Camera if you use software other than that supplied with this product to read/write data to the DVD Video Camera even though reading/writing of a file has finished without errors. Compatible PC for use with DVD Video Camera: VDR-M50PP/VDR-M70PP Personal computer : IBM PC/AT compatible computer...
Page 131: Contents On Provided Cd-Rom
Contents on Provided CD-ROM Upon inserting the provided CD-ROM into the PC, the “Setup Menu” screen will appear. You can install the included software. If the “Setup Menu” screen does not appear, double-click the CD-ROM drive icon. lUSB Driver (see page 133 for installation) Install this driver when using the provided USB cable to connect this DVD Video Camera to PC.
Page 132 You can read the instruction manual using either of the following procedures: • After installing DVD-MovieAlbumSE, open “Programs”or “All Programs” from the Windows “Start” menu, choose “Panasonic” and “DVD- MovieAlbumSE”, and then open “On-line Manual”. To read the above manual, you will need Adobe Acrobat Reader.
Page 133: Installing Usb Driver
Installing USB Driver Use the following procedure to install the USB Driver. The following instructions are an example for installing the USB driver from the supplied CD-ROM. It is necessary to repeat steps 6-9 for using the card (Select “ Insert the provided CD-ROM into the PC, and Click “USB Driver”...
Page 134 A warning message will appear, but click “Continue Anyway”. Click When installation of the USB driver is finished, click “Finish”. After the installation of the USB Driver is finished, make sure to restart your PC. lOperation with DVD Video Camera connected •...
Page 135: Installing Dvd-Ram Driver
Installing DVD-RAM Driver lBefore Installing DVD-RAM Driver If another DVD-RAM driver has already installed in your PC, confirm the original DVD-RAM driver. If the packet writing software which supports the DVD-RAM disc is installed, it is necessary to uninstall it, and then install the provided DVD-RAM driver.
Page 136 Check the folder in which the DVD-RAM driver will be installed, and then click “Next”. Check the program folder to be installed, and then click “Next”. Confirm Click “Next”. Installation will start. When installation is complete, some notes will appear: Check the contents, and then click “x”...
Page 137 *1:When using Windows 98 Second Edition or Me, “MATSHITA DVD-CAMERA M5070” is listed under “CDROM” and “Disk drives” respectively. • “Panasonic DVD CAMERA DVD Mode USB Interface” under “Universal Serial Bus controllers” When using card: • “MATSHITA DVD-CAMERA M5070 USB Device”...
Page 138: Installing Dvd-Moviealbumse
Installing DVD-MovieAlbumSE “DVD-MovieAlbumSE” software is used to edit movies that conform to DVD Video Recording format. Insert the provided CD-ROM into the PC, and Click “DVD-MovieAlbumSE 3” on the “Setup Menu” screen. If the “Setup Menu” screen does not appear, double- click the CD-ROM drive icon.
Page 139 If you do not change the program folder name, click “Next”. Check the contents, and then click “Next”. ® If your PC uses Windows 2000 Professional a message announcing “READ ONLY FILE DETECTION MESSAGE” will appear: Click “No”. Proceed with installation, following the instructions on screen.
Page 140: Installing Mydvd
Installing MyDVD MyDVD included in the provided CD-ROM does not contain the slideshows function. Therefore, you can not edit stills on MyDVD. Insert the provided CD-ROM into the PC, and Click “MyDVD 4.0” on the “Setup Menu” screen. If the “Setup Menu” screen does not appear, double- click the CD-ROM drive icon.
Page 141: Creating Dvd Video On Pc From Dvd-Ram Disc Recorded On Dvd Video Camera
MyDVD, recommends user registration of MyDVD, in order to offer appropriate support to customers. The guide for user registration will appear when you start MyDVD for the first time, or you can do it any time by accessing the following URL: http://www.mydvd.com (You will need an Internet connection for user registration.)
Page 142: Video Camera
Note • Choose “Divide by Marker” in the “Option” box: Each scene of program recorded on the DVD Video Camera will be saved as an independent movie file so that export can be executed at high speed. If you do not choose “Divide by Marker”, movie files may be unified and re-encoded, so it may take time to export them or the image quality may slightly deteriorate.
Page 143: Uninstalling Software
"Disk drives". If no item exists, proceed with the next step. Delete the following item in “Universal Serial Bus controllers”: “Panasonic DVD CAMERA DVD Mode USB Interface” If no item exists, proceed with the next step. Close Device Manager. If the message for restart appears, click “No”.
Page 144: Deleting Other Applications
If your PC uses Windows XP Home Edition/XP Professional or no item exists, proceed with the next step. Delete “Panasonic DVD CAMERA DVD Mode USB Interface” in “Universal Serial Bus controllers”. If no item exists, proceed with the next step. Close Device Manager.
Page 145: Supplementary Information
Supplementary Information Introduction to Optional Accessories Video Camera Accessories Accessory LM-AK60U 8cm DVD-RAM LM-RK30U 8cm DVD-R PV-DAC13 AC adaptor with AC Cable and DC Cable CGA-DU07A 680mAh/Rechargeable Lithium Ion Battery Pack CGA-DU14A* 1360mAh/Rechargeable Lithium Ion Battery Pack CGA-DU21A 2040mAh/Rechargeable Lithium Ion Battery Pack RP-SDH512U1A 512 MB SD Memory Card RP-SDH256U1A...
Page 146: Information On Round Dvd Holder
Information on Round DVD Holder This DVD Video Camera cannot use a square adapter, such as for 8 cm DVD-RAM disc, 8 cm DVD-R disc: Remove the disc from square adapter and set it in Round DVD Holder, referring to the instruction sheet of disc. lRemoving disc from square adaptor (Example 1) (Example 2)
Page 147: Cleaning
Cleaning Be sure to set the power switch to “OFF” before cleaning this DVD Video Camera. lCleaning LCD screen and camera lens Use a dry, soft cloth to wipe dirt off. When cleaning the LCD screen, be careful not to use force, scratch it, or subject it to impact: Doing such could cause a defect in the screen, resulting in display unevenness, or damage the LCD monitor.
Page 148: Terminology
Terminology DVD-RAM disc: Rewritable DVD disc. DVD-R disc: One-time recordable DVD disc. DVD Video format: This application format establishes the file name, directory structure, data format, etc. to record videos (movies). A generally available DVD video conforms to this format. DVD Video recorder: This device can record video and audio on any recordable DVD disc, such as DVD-RAM, that conforms to the DVD Video Recording format.
Page 149: Disc-Protect
Disc-protect: This disables writing to disc (protects disc from writing) so that images recorded on DVD-RAM disc cannot be accidentally deleted and the disc cannot be initialized. Howling: This phenomenon occurs as follows: When the DVD Video Camera is connected to a device, such as TV, the audio input to the microphone of DVD Video Camera is amplified and output from the speakers of TV, and the signal is again input to the microphone: This is repeated to form an endless loop of audio signal, and the signal is amplified up to the audio output amplitude limit of the device.
Page 150: Before Requesting Service
Before Requesting Service Check 1 No movie can be recorded Movie can be recorded only on DVD-RAM or DVD-R disc. Check the following: • Is DVD-RAM or DVD-R disc inserted? • Is power switch set to “ ”? • Is the DVD-RAM disc in DVD Video Camera write- protected? Release the write-protect.
Page 151 Check 5 No DVD Video Camera operation Is a fully charged battery pack attached? Is the DVD Video Camera powered from AC outlet? Check 6 No image in viewfinder Is LCD monitor open? No image will appear in viewfinder unless the LCD monitor is closed and securely locked to DVD Video Camera.
Page 152: Error Messages
Error Messages A message may appear while you are operating the DVD Video Camera. If a message appears, refer to the following table and take appropriate corrective action. Messages are arranged in alphabetical order. Message (1) Data error in a part of It is possible that the system cannot normally complete writing of file image file.
Page 153 Message Cannot combine. Select only movies and combine them. Deselect PHOTO scenes. Cannot combine scene Scenes cannot be combined, because the programs are different. of multiple programs. Create a play list. Cannot combine. Select Select a range of at least 2 scenes to be combined, and then multiple scenes.
Page 154 Message Control Information Mismatch may occur between the recorded image and scene Error. information. Update the control information. • Use another disc. • See *3 on page 157. COPY PROTECTED The video signal input to this DVD Video Camera may be copy- guarded.
Page 155 Message Disc full. Cannot Delete unnecessary scenes before using this disc, or use another execute. disc. Disc has no data. This message will appear when an attempt is made to execute playback or editing on Disc Navigation with no scene recorded. Disc has no Play List.
Page 156 Message NO CARD Insert a card. No card. No card is inserted. Please insert card. Insert a card. NO DISC This message may appear when the DVD Video Camera or disc is moved from a cold place to a warm place. Condensation has occurred on the DVD Video Camera lens or DVD-RAM drive.
Page 157 Message UNFORMAT DISC The disc is not initialized or it is damaged. If this message appears, be sure to initialize the disc on this DVD Video Camera before using it. Reinitializing even a disc used on this DVD Video Camera may be necessary (initializing will erase all recorded contents on disc).
Page 158: Troubleshooting
Troubleshooting Check to see the following before asking for a repair. If the suggested solution still cannot restore the DVD Video Camera to normal, do not attempt to repair it yourself, but consult your dealer. Power supplies Symptom Battery pack cannot be Is the ambient temperature too low or too high? charged.
Page 159: During Recording
During recording Symptom Pressing the REC button Is input image copy-guarded? will not start recording. Copy-guarded image cannot be recorded on this DVD Video Camera. Recording starts but Is disc scratched or do dirt or fingerprints adhere to it? stops immediately. Clean the disc.
Page 160: During Playback
During playback Symptom Recognition of disc is not Is disc dirty? complete Use a soft, dry cloth to clean it. Pressing the playback Has the image been recorded by devices other than this DVD Video button will not start Camera? playback.
Page 161 When the DVD Video Camera is connected to PC: Symptom No drive icon appears on The DVD Video Camera is not turned on. Check the power supply. Driver is not properly recognized. Turn PC off and on again. If the drive icon still does not appear, use “Refresh driver”...
Page 162 Symptom The DVD-RAM drive of If DVD-MovieAlbumSE is running, terminate it. DVD Video Camera cannot be opened by PC Explorer or application. Error appears. Disc cannot be ejected. When the time stamp of The file system of this DVD Video Camera is operated on Greenwich file in DVD-RAM is Mean Time (GMT), and time lag information has not been set.
Page 163 Miscellaneous Symptom Power does not come on, Execute system reset (press the RESET button). or no operation occurs by Has the DVD Video Camera been subjected to impact? pressing button. The DVD Video Camera could be damaged. Please contact us. The date and time are Has the DVD Video Camera been left unused for a long period of incorrect.
Page 164: System Reset
System Reset If the DVD Video Camera does not operate normally, perform “System Reset”: The DVD Video Camera may recover to normal. “System Reset” will reset all settings to factory defaults. The date and time will also be reset: Set the date and time again before using the DVD Video Camera. Set the power switch to “OFF”...
Page 165: Major Specifications
(when using 32 MB card) Information for your safety DC 7.9/7.2 V When recording with LCD monitor off VDR-M50PP approx. 4.9 W (in FINE mode) VDR-M70PP approx. 5.2 W (in FINE mode) VDR-M50PP: 1/6-inch interlaced VDR-M70PP: 1/4-inch interlaced Total number of pixels VDR-M50PP: approx.
Page 166 960 pixels) Movie: Conforming to DVD Video Recording format (when MPEG 1 Audio layer 2 or LPCM Still: Conforming to JPEG (VDR-M50PP: 640 × 480 pixels, VDR-M70PP: 1280 × 960 pixels) standard MPEG 1 Audio Layer 2, linear PCM, Dolby AC3 8 cm DVD-RAM disc (conforming to DVD-RAM Ver.
Page 167 Power Source: Power Consumption: DC Output: Dimensions (W × H × D) Weight: Note Weight and dimensions shown are approximate. Designs and specifications are subject to change without prior notice. AC 110-240 V, 50/60 Hz 19 W 0.5 W (When not in use) DC 7.9 V, 1.4 A (DVD Video Camera operation) DC 8.4 V, 0.65 A (Battery Charging)
Page 168: Request For Service Notice (Usa Only)
(Failure to do so will delay your repair.) To further speed your repair, please provide an explanation of what wrong with the unit and any symptom it is exhibiting. Panasonic Services Company 1705 N. Randall Road Elgin, IL. 60123-7847 Attn: Camcorder Repair...
Page 169: Limited Warranty (For Usa Customers)
If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics Company or Panasonic Sales Company (collectively referred to as “the warrantor”) will, for the length of the period indicated on the chart below, which starts with the date of original purchase (“warranty period”), at its option either (a) repair your product with new or refurbished...
Page 170: Customer Services Directory
Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST. For hearing or speech impaired TTY users, TTY : 1-877-833-8855 Accessory Purchases Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting our Web Site at: http://www.pasc.panasonic.com or, send your request by E-mail to: npcparts@panasonic.com...
Page 171: Warranty (For Canadian Customers)
Warranty (For Canadian Customers) Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect for a period as stated below from the date of original purchase. LIMITATIONS AND EXCLUSIONS...
Page 172 MEMO...
Page 174 Executive Office: One Panasonic Way, Secaucus, NJ 07094 (201) 348-7000 Panasonic Company East: 6749 Baymeadow Drive, Glen Burnie, MD 21060 Panasonic Company Central: 1707 North Randall Road, Elgin, IL 60123 Panasonic Company West: 6550 Katella Avenue, Cypress, CA 90630 Division of Matsushita Electric Corporation of America Panasonic Sales Company Division of Matsushita Electric of Puerto Rico, Inc.
