- Page 1 Wild Camera DENVER WCT-3004 MK3 Instruction Manual WWW.DENVER-ELECTRONICS.COM ENG-1...
-
Page 2: Table Of Contents
Table of Contents 1.Instructions ....................... 3 1.1 General Description ................3 1.2 Camera Body Interface ................3 1.3 Camera components and features............3 1.4 Remote Control ..................4 1.4.1 Navigating ................... 5 1.5 Shooting Information Display ..............5 1.6 Supported Format ................... 6 Cautions ...................... -
Page 3: Instructions
1. Instructions 1.1 General Description This digital trail camera is a surveillance camera working automatically. It can be triggered at once by any movement of human (or animals) in a certain region of interested (ROI) monitored by a high sensitive Passive Infrared (PIR) motion sensor, and then automatically captures high quality pictures (up to 12M pixels) or records FHD video clips (WVGA or QVGA). -
Page 4: Remote Control
1.4 Remote Control The remote control is an input device of the camera and is primarily used for customer settings and password input. This is an infrared type wireless remote control. The maximum remote distance is 9 meters. There are fifteen buttons on the remote control. -
Page 5: Navigating
1.4.1 Navigating Press UP or DOWN to select or highlight the menu item, while press LEFT or RIGHT to select the option of each item and press OK to make selection. Select Item (UP) Display Menu Selection Exit (MENU) (OK) Select Option Select Option (Left) -
Page 6: Supported Format
1.6 Supported Format Item Format Photo Video File Format FAT32 Here are some important notices. You don’t need to concern about the file system format of the camera unless you have problems with reading the SD-card by your other equipment. If this happened, please format the SD-card in the camera or in a computer at first and then reinsert the card into your camera to make a try. -
Page 7: Easy Operation
3. Easy Operation 3.1 Power Supply To supply power for the camera, four or eight AA size batteries are needed. Open the bottom cover. Confirm that the power switch is at the OFF (Right) position, pull out the battery depot. Load the fully charged batteries into the depot according the polarities sign shown below. -
Page 8: Enter Into The Test Mode
Slide the power switch to the ON position to power on the camera and enter into the ON mode. In ON mode, the camera will take pictures or videos automatically according to the default settings or previous custom settings. The camera has the sound recording function, so the sound will be embedded in the video clip while capturing a video. -
Page 9: Advanced Operations
4. Advanced Operations From the basic operations of the camera in previous chapter, we know that the camera has three basic operation modes: 1. OFF mode: Power switch is at OFF position (Right). 2. ON mode: Power switch is at ON position (Left). 3. -
Page 10: System Setting
4.1.1 System Setting 4.1.2 Photo Setting ENG-10... -
Page 11: Video Setting
4.1.3 Video Setting 4.1.4 Default Default Settings are listed as below: Setting Default Mode Photo Photo Resolution Photo series 1photo Video 1080P Resolution Video Length Date/Time Same as last time Language English Format Internal Memory Serial NO Password protection 4.1.5 General Settings The operating steps are suitable for following menu items: Photo Mode, Photo resolution, Video Resolution, series, Video Length. -
Page 12: Set Photo Size
c) Press OK to start formatting the SD-card. During formatting, the display screen will show a message “Please Wait” as below. Press MENU to cancel setting and return to info display. Please Wait! 4.1.8 Set Photo Size This parameter has three values: 8MP, 5MP and 3MP. The default one is 5 mega pixels. -
Page 13: Set Video Length
4.1.12 Set Video Length The following shows how to set video length to 30 Seconds, provided that the previous value is 10 Seconds: a) Press MENU to display the setting menu. b) Press DOWN to select Video Length. c) Press OK switch to save the current setting, then press MENU to return to info display. -
Page 14: File Numbering
8. Insert the SD card into the camera for its working. Please note, that this is not an error with the Camera: Heavy rain, fog and drizzle (in the dark) will give white photos without motive ALL RIGHTS RESERVED, COPYRIGHT DENVER ELECTRONICS A/S ENG-14... - Page 15 Additional information is available at the technical department of your city. Please fill the blank with the model number of this player for future reference Imported by: DENVER ELECTRONICS A/S Stavneagervej 22 DK-8250 Egaa Denmark www.facebook.com/denverelectronics...
