Denver HSC-3004 Quick Start Manual

Overview

1) Bottom Cover
2) SD-Card Slot
3) USB Connector
4) TV Out connector
5) PIR
6) Infrared Flash
7) Lens
8) 2 inch color LCD Display
9) Sound recorder
10) Lock
11) Power switch
12) Battery Depot
13) Portable remote controller
A. Preparation
1. 4 or 8 AA battery or 6V DC input from top power jack
2. unlocked SDHC card (up to 32G)
B. The camera has 3 basic operation modes:
1. OFF mode: Power switch is at OFF position.
2. ON mode: Power switch is at ON position.
3. TEST mode: Power switch is at TEST position.
In the above three modes, the OFF mode is the specified safe mode when replacing the SD-card or batteries and transporting the camera.
C. There are 3 modes under system setting for your selection.
a. Camera
It only takes photos at a time.
b. it only takes videos at a time.
c. Camera &Video.
It takes photo firstly, then takes videos at time.
D. There are also 2 ways to take photos or videos.
a. Manually by using the remote control
DENVER HSC-3004
Wildkamera

Quick Start Guide

ENG-1
