Fig. 9
Fig. 10
Disconnect
the drain
hose at the drain
connection
by sliding
the hose clamp
away
from
check
valve
with
pliers,
and remove
the hose from
the check
valve.
Grasp
hoses and
pull
them
through
the side. CAUTION:
Do not
loosen
or disconnect
any wires
or
connections
when
removing
hoses. Remove
the screw and retainer
from
the hose bracket.
The existing
drain
hose may
be used for making
the drain
connection
upon
installation.
If the existing
hose cannot
be used, a new hose along
with
any required
fittings
may be purchased
from
your
KitchenAid
dealer.
DO NOT
use the existing
fill hose to connect
water
supply
to the dishwasher.
8.
Set the dishwasher
upright.
Open
the door
and remove
the two #lO
flat
head wood
screws that
retain
the wood
top,
The angle
brackets
will
remain
fastened
to the machine.
Pull the top forward
and lift
it
off. The top will
not be needed
and may be discarded.
9.
If the dishwasher
is to be installed
at the end of a counter,
the right
or left side panel
(whichever
side
will
be exposed)
will
have to be re-attached.
Using
a hacksaw,
cut the hose anchor
bracket
(removed
during
step 5) at the scored
line. Discard
the
smaller
of the two
pieces.
When
fastening
either
side panel,
remove
the rear panel
mounting
bracket
(on.top
of the tank)
from
the side on which
the panel
is to be installed
and replace
it with
the mod-
ified
bracket.
This
bracket,
along
with
the screw
and countersunk
washer,
will
be used to secure the
side panel.
See Fig. 11.
10.
Check
to make
sure the stainless
steel washer
is in place
on the wash arm support
shaft
and then
re-
place the wash arm, rack, and silverware
basket.
11,
Hemove
tape from
rinse agent dispenser
and replace
the front
panel.
12.
The dishwasher
is now ready
for undercounter
installation.
, BACK
OF DISHWASHER
/
,MODIF
IED BRACKET
VIEW
FROM
1
FRONT
MODlFlEb
BRACKET
SCREW
AND
COUN-
TERSUNK
WASHER
DISHWASHER
TANK
/
RIGHT
SIDE
PANEL
L TOP OF TANK
RIGHT
SIDE
PANEL
INSTALLATION
SHOWN,
REVERSE
FOR LEFT
SIDE
PANEL
INSTALLATION.
IPL-19267-
II
Fig. 11
