INVENTOR R2-ION8L User Manual page 12

Press Swing:
When the unit is set on L / M /H, fla pping air guide will change
the angle between 90 to 45 degree. Press again, air guide stop
at the existing angle.
1. LED b links, air guide moves the between 90 to 45
degree.
2. LED goes off, the air guide stop at the existi ng angle.
Press Ionizer:
Switching On or Off the ionizer.
LED blinks when turns on.
Press Timer:
Setting operation time off by entering into 1/ 2 / 4/ 8 hours
Safety function
When the appliance is tilted at 45º or more, it' s function will stop for safety reasons.
The fan will k eep work ing for 4 minutes more at low speed.
When c ondensed water is full, beeper will alarm
Meanwhile, the icon s hown on LCD monitor blinks, the unit
stop operating automatically.The water reservoir must be
removed to empty a nd reinsta lled b efore the rotary desiccant
operates again.
Remove water reservoir in
accordance with arrow direction
Protection Of Internal Over Heating
During operating, the abnormal or malfunction may be raised
owing to air intake or exhaust being obstructed or blocked by
foreign objects which could occasionally resulting internal
temperature ascending, the unit will shut down automatically.
Unplug from power socket immediately and resume to operate
after 5 minutes.
Protecti on O f Water Full
times.
12
