  • Page 1 ADSL 2/2+ Router ADE-3400 ►...
  • Page 2 "as is". Should the programs prove defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software. Further, PLANET reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes.
  • Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision User’s Manual for ADSL 2/2+ Router Model: ADE-3400 Rev: 6.0 (October. 2013) Part No. EM-ADE3400_v6...

  • Page 4: Table Of Contents

    ADSL 2/2+ Router ADE-3400 Contents Chapter 1. Overview ………………………………………………………………………3 1.1 Application …………………………………………………………………………3 1.2 System Requirements…………………………………………………………… 6 1.3 Features…………………………………………………………………………… 7 1.4 Specifications ………………………………………………………………………9 Chapter 2. Hardware Installation ……………………………………………………… 11 Chapter 3. Web Configuration ……………………………………………………………12 3.1 Accessing the Router ……………………………………………………………12 3.2 Status ………………………………………………………………………………13 3.2.1 Device Information …………………………………………………………13...
  • Page 5 ADSL 2/2+ Router ADE-3400 3.8.3 Reboot ………………………………………………………………………57 3.8.4. Time……………………………………………………………………… 57 3.8.5 Log…………………………………………………………………………58 3.8.6 Diagnostic …………………………………………………………………58 Chapter 4. Q&A …………………………………………………………………………64...

  • Page 6: Chapter 1.Overview

    Improved Networking Function for Future IP Compatibility PLANET ADE-3400 is an ADSL 2/2+ Router. The ADE-3400 is the ideal solution for office and residential users to share a high-speed ADSL 2/2+ broadband Internet connection and four-10/100Mbps Fast Ethernet backbone. It can support transmission rates up to 24Mbps downstream and 3.5Mbps upstream with ADSL 2+ support.
  • Page 7 ADSL2/2+ Router ADE-3400...
  • Page 8 ADSL2/2+ Router ADE-3400 Front Panel The following table describes the LEDs of the device. State Description When the router is powered on and in ready state. The devise is being turned on and booting. When the router is powered off.

  • Page 9: System Requirements

    ADSL2/2+ Router ADE-3400 Rear Panel The following table describes the interfaces and buttons of the device. Connector Description POWER Button The power button is for turn on or turns off the router. Power Power connector with 5V DC, 1A The reset button can restore the default settings of device. To restore...

  • Page 10: Features

    Internet Access Shared All users in the LAN can access the Internet through the ADE-3400 by just a single external IP Address. The local (invalid) IP Addresses are hidden from external sources. This process is called NAT (Network Address Translation).
  • Page 11 It is an easy way to remotely manage the router via SNMP. LAN Features DHCP Server Support Dynamic Host Configuration Protocol provides a dynamic IP address to PCs and other devices upon request. The ADE-3400 can act as a DHCP Server for devices on your local LAN and WLAN.

  • Page 12: Specifications

    ADSL2/2+ Router ADE-3400 1.4 Specifications Product ADSL 2/2+ Router Model ADE-3400A Hardware Compliant with ADSL Standard - Full-rate ANSI T1.413 Issue 2 - G.dmt (ITU G.992.1) - G.lite (ITU G.992.2) - G.hs (ITU G.994.1) Standard Capable of ADSL2 Standard - G.dmt.bis (ITU G.992.3) Annex A, L and M - G.lite.bis (ITU G.992.4)
  • Page 13 ADSL2/2+ Router ADE-3400 Built-in NAT Firewall IP Port Filter, MAC Filter, URL Blocking, DoS Setting PPP over PAP (Password Authentication Protocol;RFC1334) PPP over CHAP (Challenge Authentication Protocol;RFC1994) Access Control List (ACL) Security Denial of Service (DoS) IP-based Packet filtering MAC filtering...

  • Page 14: Chapter 2.Hardware Installation

    ADSL2/2+ Router ADE-3400 Chapter 2.Hardware Installation Connect the LINE interface of the device and the Modem interface of the splitter with a telephone cable. Connect the phone set to the Phone interface of the splitter through a telephone cable. Connect the input cable to the Line interface of the splitter.

  • Page 15: Chapter 3.Web Configuration

    ADSL2/2+ Router ADE-3400 Chapter 3.Web Configuration This chapter describes how to configure the device by using the Web-based configuration utility. 3.1 Accessing the Router The following describes how to access the device for the first time in details. Step 1 Open the Internet Explorer (IE) browser and enter http://192.168.1.1 in the address bar.

  • Page 16: Status

    ADSL2/2+ Router ADE-3400 3.2 Status In the navigation bar, choose Status. On the Status page that is displayed contains: Device Info, ADSL and Statistics. 3.2.1 Device Information Choose Status > Device Info and the page displayed shows the current status and some basic settings of the router, such as software version, DSP version, uptime, upstream speed, and downstream speed.

  • Page 17: Statistics

    ADSL2/2+ Router ADE-3400 3.2.3 Statistics Choose Status > Statistics. Click Statistics in the left pane and the page shown in the following figure appears. On this page, you can view the statistics of each network port.

  • Page 18: Wizard

    ADSL2/2+ Router ADE-3400 3.3 Wizard When subscribing to a broadband service, you should be aware of the method by which you are connected to the Internet. Your physical WAN device can be either PPP, ADSL, or both. The technical information about the properties of your Internet connection is provided by your Internet Service Provider (ISP).
  • Page 19 ADSL2/2+ Router ADE-3400 Bridge After setting, click Next and the page as shown in the following figure appears. PPPoE/PPPoA On the Connection Type page set the WAN connection type to PPP over Ethernet (PPPoE), and the encapsulation mode to LLC/SNAP.
  • Page 20 ADSL2/2+ Router ADE-3400 Field Description PPP Username Enter the username for PPPoE dial-up, which is provided by your ISP. PPP Password Enter the password for PPPoE dial-up, which is provided by your ISP. After setting, click Next and the page as shown in the following figure appears.
  • Page 21 ADSL2/2+ Router ADE-3400 1483 MER/1483 Routed On the Connection Type page set the WAN connection type to 1483 MER, and the encapsulation mode to LLC/SNAP.
  • Page 22 ADSL2/2+ Router ADE-3400 After setting, click Next and the page as shown in the following figure appears. The following table describes the parameters on this page: Field Description Select it, DHCP automatically assigns the IP address for WAN Attain IP Automatically connection.
  • Page 23 ADSL2/2+ Router ADE-3400 1483 Bridged On the Connection Type page set the WAN connection type to 1483 Bridged, and the encapsulation mode to LLC/SNAP. After setting, click Next and the page as shown in the following figure appears.

  • Page 24: Setup

    ADSL2/2+ Router ADE-3400 3.4 Setup In the navigation bar, click Setup. The Setup page that is displayed contains WAN and LAN. 3.4.1 WAN Choose Setup > WAN. The WAN page that is displayed contains WAN, Auto PVC, ATM and ADSL.
  • Page 25 ADSL2/2+ Router ADE-3400 The following table describes the parameters on this page: Field Description You can select Auto or Specified. Default Route Selection The virtual path between two points in an ATM network, ranging from 0 to 255. The virtual channel between two points in an ATM network, ranging from 32 to 65535 (1 to 31 are reserved for known protocols) You can choose LLC and VC-Mux.
  • Page 26 ADSL2/2+ Router ADE-3400 3.4.1.2 Auto PVC Click Auto PVC in the left pane, page shown in the following figure appears. In this page, you can get a PVC automatically through detecting function, and add or delete the PVC that you do not want.

  • Page 27: Lan

    ADSL2/2+ Router ADE-3400 Field Description (in microseconds). Its value ranges from 0 to 4294967295. Sustained cell rate (SCR) is the maximum rate that traffic can pass over PVC without the risk of cell loss. Its value ranges from 0 to 65535.
  • Page 28 ADSL2/2+ Router ADE-3400 The following table describes the parameters of this page: Field Description Enter the IP address of LAN interface. It is recommended to use an address from a block that is reserved for private use. This address block is 192.168.1.1- IP Address 192.168.1.254.
  • Page 29 ADSL2/2+ Router ADE-3400 3.4.2.2 DHCP Dynamic Host Configuration Protocol (DHCP) allows the individual PC to obtain the TCP/IP configuration from the centralized DHCP server. You can configure this router as a DHCP server or disable it. The DHCP server can assign IP address, IP default gateway, and DNS server to DHCP clients.
  • Page 30 ADSL2/2+ Router ADE-3400 Field Description name) on each individual PC. The domain name can be assigned from the router through the DHCP server. DNS Servers You can configure the DNS server IP addresses for DNS Relay. Click it, the Device IP Range Table page appears. You can configure the IP Set Vendor Class IP Range address range based on the device type.
  • Page 31 ADSL2/2+ Router ADE-3400 Click Set Vendor Class IP Range on the DHCP Mode page and the page as shown in the following figure appears. On this page, you can configure the IP address range based on the device type. In the DHCP Mode field, choose None and the page shown in the following figure appears.
  • Page 32 ADSL2/2+ Router ADE-3400 In the DHCP Mode field, choose DHCP Relay and the page shown in the following figure appears. The following table describes the parameters and buttons on this page: Field Description If set to DHCP Relay, the router acts a surrogate DHCP Server and relays the DHCP Mode DHCP requests and responses between the remote server and the client.
  • Page 33 ADSL2/2+ Router ADE-3400 Field Description After entering the IP address and MAC address, click it. A row will be added in the DHCP Static IP Table. Select a row in the DHCP Static IP Table, then click it, this row is deleted.

  • Page 34: Advanced

    ADSL2/2+ Router ADE-3400 3.5 Advanced In the navigation bar, click Advanced. In the Advanced page that is displayed contains Route, NAT, QoS, TR-069 and Others. 3.5.1 Routing Choose Advance > Routing, and this page contains Static Route and RIP. 3.5.1.1 Static Route Click Static Route in the left pane, and the page shown in the following figure appears.
  • Page 35 ADSL2/2+ Router ADE-3400 Click Show Routes, the page shown in the following figure appears. The table shows a list of destination routes commonly accessed by your network. 3.5.1.2 IPv6 Static Route Click IPv6 Static Route in the left pane, and the page shown in the following figure appears. This page is used to configure the routing information.

  • Page 36: Nat

    ADSL2/2+ Router ADE-3400 The following table describes the parameters and buttons of this page: Field Description You can select OFF or ON. In this example, OFF is selected. Apply Click it to save the settings of this page. Interface Choose the router interface that uses RIP.
  • Page 37 ADSL2/2+ Router ADE-3400 3.5.2.2 Virtual Server 3.5.2.2 Virtual Server Click Virtual Server in the left pane and the page shown in the following figure appears. Click Virtual Server in the left pane and the page shown in the following figure appears.
  • Page 38 ADSL2/2+ Router ADE-3400 The following table describes the parameters of this page. Field Description You can select the common service type, for example, AUTH, DNS or FTP. You can also define a service name. If you select Usual Service Name, the corresponding parameter has the Service Type default settings.
  • Page 39 ADSL2/2+ Router ADE-3400 3.5.2.4 NAT Exclude IP Click NAT Exclude IP in the left pane, and the page shown in the following figure appears. In the page, you can configure some source IP addresses which use the purge route mode when accessing internet through the specified interface.
  • Page 40 ADSL2/2+ Router ADE-3400 3.5.2.6 FTP ALG Port Click FTP ALG Port in the left pane, the page shown in the following figure appears. The common port for FTP connection is port 21, and a common ALG monitors the TCP port 21 to ensure NAT pass-through of FTP. By enabling this function, when the FTPserver connection port is not a port 21, the FTP ALG module will be informed to monitor other TCP ports to ensure NAT pass-through of FTP.

  • Page 41: Qos

    ADSL2/2+ Router ADE-3400 3.5.3 QoS Choose Advanced > QoS, and the page shown in the following figure appears. Entries on the QoS Rule List are used to assign the precedence for each incoming packet based on physical LAN port, TCP/UDP port number, source IP address, destination IP address and other information.
  • Page 42 ADSL2/2+ Router ADE-3400...
  • Page 43 ADSL2/2+ Router ADE-3400 The following table describes the parameters and buttons of this page: Field Description Select to enable or disable IP QoS function. You need to enable IP QoS if you want to configure the parameters of this page.
  • Page 44 ADSL2/2+ Router ADE-3400 The following table describes the parameters of this page: Field Description The URL of the auto-configuration server to connect to. User Name The user name for logging in to the ACS. Password The password for logging in to the ACS.
  • Page 45 ADSL2/2+ Router ADE-3400 3.5.5.Others Choose Advance > Others, and the page shown in the following figure appears. The page displayed contains Bridge Setting, Client Limit, Tunnel and Others. 3.5.5.1 Bridge Setting Choose Advance > Others > Bridge Setting, and the page shown in the following figure appears. This page is used to configure the bridge parameters.
  • Page 46 ADSL2/2+ Router ADE-3400 3.5.5.2 Client Limit Choose Advance > Others > Client Limit, and the page shown in the following figure appears. This page is used to configure the capability of forcing how many devices can access to the Internet.

  • Page 47: Service

    ADSL2/2+ Router ADE-3400 3.5.5.4 Others Choose Advanced > Others > Others in the left pane, and the page shown in the following figure appears. You can enable half bridge so that the PPPoE or PPPoA connection will set to Continuous.

  • Page 48: Upnp

    ADSL2/2+ Router ADE-3400 3.6.1.2 MLD MLD means Multicast Listener Discovery, its component of the IPv6. MLD is used by IPv6 routers for discovering multicast listeners on a directly attached link, much like IGMP is used in IPv4. 3.6.2 UPNP Choose Service > UPnP and the page shown in the following figure appears. This page is used to configure UPnP.

  • Page 49: Dns

    ADSL2/2+ Router ADE-3400 The following table describes the parameters of this page: Description Field Select it to enable SNMP function. You need to enable SNMP, and then you can Enable SNMP configure the parameters of this page. Enter the trap IP address. The trap information is sent to the corresponding Trap IP Address host.
  • Page 50 ADSL2/2+ Router ADE-3400 3.6.4.1 DNS Click DNS in the left pane and the page shown in the following figure appears. 3.6.4.2 IPv6 DNS The following table describes the parameters and buttons on this page: Field Description Attain DNS Select it, the router accepts the first received DNS assignment from one of the PPPoA, Automatically PPPoE or MER enabled PVC(s) during the connection establishment.

  • Page 51: Ddns

    Click DDNS in the left pane and the page shown in the following figure appears. This page is used to configure the dynamic DNS address from DynDNS.org, TZO or Planet. You can add or remove to configure dynamic DNS. The Planet DDNS is free for customer.

  • Page 52: Ip/Port Filter

    ADSL2/2+ Router ADE-3400 3.7.2 IP/Port Filter 3.7.2.1 IP/Port Filter Click IP/Port Filter in the left pane and the page shown in the following figure appears. Entries in the table are used to restrict certain types of data packets through the gateway. These filters are helpful in securing or restricting your local...

  • Page 53: Url Filter

    ADSL2/2+ Router ADE-3400 3.7.2.2 IPV6/Port Filter 3.7.3 URL Filter Click URL Filter in the left pane and the page shown in the following figure appears. This page is used to block a fully qualified domain name, such as tw.yahoo.com and filtered keyword. You can add or delete FQDN and filtered...

  • Page 54: Acl

    ADSL2/2+ Router ADE-3400 The following table describes the parameters and buttons on this page: Field Description You can choose Disable or Enable. URL Blocking Capability Select Disable to disable URL/KEYWORD blocking function and keyword filtering function. Select Enable to block access to the URLs and keywords specified in the URL Blocking Table.
  • Page 55 ADSL2/2+ Router ADE-3400 The following table describes the parameters and buttons of this page: Field Description Select the router interface. You can select LAN or WAN. In this example, LAN Direction Select is selected. LAN ACL Switch Select it to enable or disable ACL function.
  • Page 56 ADSL2/2+ Router ADE-3400 3.7.4.2 IPv6 ACL...

  • Page 57: Dos

    ADSL2/2+ Router ADE-3400 3.7.5 DoS Denial-of-Service Attack (DoS attack) is a type of attack on a network that is designed to bring the network to its knees by flooding it with useless traffic. Click Anti-DoS in the left pane and the page shown in the following figure appears. On this page, you can prevent...

  • Page 58: Maintenance

    ADSL2/2+ Router ADE-3400 3.8 Maintenance In the navigation bar, click Maintenance. The Maintenance page displayed contains Update, Password, Reboot, Time Log and Diagnostics. 3.8.1 Update Choose Maintenance > Update. The Update page displayed contains Upgrade Firmware and Backup/Restore. Caution: Do not turn off the router or press the Reset button while the procedure is in progress.

  • Page 59: Password

    ADSL2/2+ Router ADE-3400 3.8.1.2 Backup/Restore Click Backup/Restore in the left pane and the page shown in the following figure appears. You can back up the current settings to a file and restore the settings from the file that was saved previously.

  • Page 60: Reboot

    ADSL2/2+ Router ADE-3400 The following table describes the parameters of this page: Field Description Choose the user name for accessing the router. You can choose admin or User Name user. Privilege Choose the privilege for the account. Old Password Enter the old password 3.8.3 Reboot...

  • Page 61: Time

    ADSL2/2+ Router ADE-3400 3.8.4. Time Choose Maintenance > Time and the page shown in the following figure appears. You can configure the system time manually or get the system time from the time server. The following table describes the parameters of this page:...
  • Page 62 ADSL2/2+ Router ADE-3400 3.8.6.1 Ping Choose Diagnostic > Ping and the page shown in the following figure appears. The following table describes the parameter and button on this page: Field Description Host Enter the valid IP address or domain name.
  • Page 63 ADSL2/2+ Router ADE-3400 3.8.6.2 Ping6 Choose Diagnostic > Ping6 and the page shown in the following figure appears. 3.8.6.3 Traceroute Choose Diagnostic >Traceroute and the following page appears. By Traceroute Diagnostic, you can track the route path through the information which is from your computer to the Internet other side host.
  • Page 64 ADSL2/2+ Router ADE-3400 The following table describes the parameters and buttons on this page. Field Description Host Enter the destination host address for diagnosis. NumberOfTries Number of repetitions. Timeout Put in the timeout value. Datasize Packet size. DSCP Differentiated Services Code Point, You should set a value between 0-63.
  • Page 65 ADSL2/2+ Router ADE-3400 Click Go! to start testing. 3.8.6.6 ADSL Diagnostic Choose Diagnostic > ADSL Diagnostic and the page shown in the following figure appears. It is used for ADSL tone diagnostics. Click Start to start ADSL tone diagnostics.
  • Page 66 ADSL2/2+ Router ADE-3400 3.8.6.7 Diag-Test Choose Diagnostics > Diag-Test and the page shown in the following figure appears. On this page, you can test the DSL connection. You can also view the LAN status connection and ADSL connection. Click Run Diagnostic Test to start testing.

  • Page 67: Chapter 4.Q&A

    ADSL2/2+ Router ADE-3400 Chapter 4.Q&A Question Answer Check the connection between the power adapter and the power socket. Why are all the indicators off? Check whether the power switch is turned on. Check the following: The connection between the device and the PC, the hub, or the switch...
