S9200U1000 UNIVERSAL HOT SURFACE IGNITION INTEGRATED FURNACE CONTROL
INSTALLATION AND
CONFIGURATION STEPS -
OVERVIEW
The following is an overview of the steps required to
install and configure the S9000U100 Integrated Furnace
Control:
1. Identify cross reference target using Table 1.
2. Remove old device and carefully identify and mark
any wiring. See "Replacement" on page 6.
SKU
United Technologies
1012-925A
1012-925B
1012-925C
Rheem/ Robert Shaw
62-24268-01
62-24268-02
62-24268-03
Nordyne
624557
6245570
624557-0
624564
6245640
624591
624591A
624591-A
624591-B
624591-C
624591-D
624628
624628-0
6246310
624631-0
624631A
624631-A
624631-B
710128A
902378
902696
903106
United Technologies
1012-955A
1012955A
Carrier
903106
69-2075—01
Table 1. S9200U1000 Replaces These Integrated Furnace Controls.
Harness
50024568
Main Connector
50024566
Inducer & HSI
Connector
50024568
Main Connector
50024565
Inducer & HSI
Connector
50024568
Main Connector
50024565
Inducer & HSI
Connector
3. Mount the S9200U100 Integrated Furnace Control.
See "Replacement" on page 6.
4. Connect the wiring harnesses and make the wiring
connections. See "Wiring" on page 7.
5. Configure the field settings and safety timings. See
"Safety Timings, Field Settings, and Fixed Parame-
ters" beginning on page 11.

CROSS REFERENCE

See Table 1 for the replacement details for other
manufacturers' controls.
Field Settings
Recommendation -
DIP Switch S1 (See Table 8)
SW1: ON
SW2: OFF
SW3 & SW4: 60/90/120/180
SW1: ON
SW2: OFF
SW3 & SW4: 60/90/120/180
SW1: ON
SW2: OFF
SW3 & SW4: 60/90/120/180
2
Safety Timing Settings -
DIP Switch S2 (See Table 9)
SW1: ON
SW2: ON
SW1: ON
SW2: OFF
SW1: ON
SW2: OFF
