SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
TECHNICAL & SERVICE MANUAL
Wall Mounted
Series PKFY
Indoor unit
[Model names]
PKFY-P20VAM-E
PKFY-P25VAM-E
INDOOR UNIT
R410A
[Service Ref.]
PKFY-P20VAM-E
PKFY-P25VAM-E
2004
R407C
R22
CONTENTS
1. SAFETY PRECAUTION ·····················2
3. SPECIFICATION·································8
5. WIRING DIAGRAM···························11
7. TROUBLESHOOTING······················12
8. DISASSEMBLY PROCEDURE·········19
9. PARTS LIST ·····································22
No. OC309
