- Page 1 30" LCD TV LCM30HD USER MANUAL IMPORTANTI WARRANTY INFORMATION INSIDE. PLEASE READ FOR INQUIRIES CALL 1800 656 700 WWW.TEAC.COM.AU...
- Page 3 *Your nearest Authorised TEAC Service Centre is listed in your Owners Manual In the event that this unit or any defective parts must be returned to TEAC Service Centres, a copy of this warranty certificate and of your purchase receipt must be enclosed to be a valid warranty. Such equipment or parts must be sent freight prepaid to the nearest authorised TEAC Service Centre.
- Page 4 Dealer's Address Postcode Please ensure that your product is packed appropriately upon return to the service centre. If you have any other queries regarding service or warranty please contact the TEAC Service below: TEAC Total Care Ph: 1800 656 700 info@teac.com.au...
-
Page 5: Important Safety Instructions
Important Safety Instructions WARNING CAUTION RISK OF ELECTRIC SHOCK TO REDUCE THE RISK OF FIRE OR DO NOT OPEN ELECTRIC SHOCK, DO NOT CAUTION: TO REDUCE THE RISK OF ELECTRIC EXPOSE THIS DEVICE TO RAIN SHOCK, DO NOT REMOVE COVER (OR BACK). NO OR MOISTURE. - Page 6 Important Safety Instructions Important Safeguards for You and Your New Device Always be careful when using your LCD TV. To reduce the risk of fire, electric shock, and other injuries, keep these safety precautions in mind when installing, using, and maintaining your LCD TV. 1.
- Page 7 Important Safety Instructions 18. If an outside antenna or cable system is connected to the device, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the U.S. National Electrical Code, ANSI/NFPA 70 provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge...
- Page 8 User Instructions Recommendation to Avoid or Minimize Phosphor Burn-in: Like all phosphor-based display devices and all TFT LCD Displays, LCD TV' s can be susceptible to phosphor burn under certain circumstances. Certain operating conditions, such as the continuous display of a static image over a prolonged period of time, can result in phosphor burn if proper precautions are not taken.
- Page 9 Table of Contents SOUND START-UP Part Names and Functions ......10~11 Changing the Sound Standard ......32 Checking Parts ..........12 Customising the Sound........32 Battery Installation and Replacement ....12 Setting the BBE Mode ........33 CONNECTION Setting the Surround Effect .......33 Selecting the Stereo Sound ......34 Connecting VHF and UHF Antennas....13 Using the Auto Volume(AVL)......34 Connecting a Video/S-VHS ......14~15...
-
Page 10: Part Names And Functions
Part Names and Functions FRONT VIEW SPEAKER POWER/LED IR Receiver SOURCE/ MENU SELECT PAGE Menu : Displays the On screen Display (OSD). Source/Select : Displays an available video source (i.e. RGB, DVI, Video, S-Video, TV, Component, SCART). and also functions as the Select button for the On screen Display (OSD). -
Page 11: Rear View
Part Names and Functions REAR VIEW 325mm ⑪ Bottom View VHF / UHF RS-232C DIGITAL PC INPUT ANALOG PC INPUT (UP GRADE) AUDIO INPUT COMPONENT Cb / Pb VIDEO Cr / Pr S-VIDEO VIDEO INPUT SCART AC INPUT AUDIO INPUT S-VIDEO VHF/UHF Input an S-VHS signal from VCR or DVD players. - Page 12 Checking Parts Checking Parts User’s Manual Remote Control Batteries(AAA) Power Cord Battery Installation and Replacement Insert four AAA batteries, making sure of setting them in with the proper polarity. Press and Open the cover. Align the batteries according Close the cover. to the(+) and (–) indication inside the case.
-
Page 13: Connecting Vhf And Uhf Antennas
Connection Connecting VHF and UHF Antennas Connecting an Outdoor Antenna For the best reception, we recommend you use an outdoor antenna. Severely weathered antennas and antenna cables can reduce the signal quality. Before making any connections, inspect all antenna hardware; any service center can explain the various outdoor antennas available to you. - Page 14 Connection Connecting a VCR (Composite Video) Rear of the LCD TV COMPONENT Cb / Pb VIDEO Cr / Pr S-VIDEO VIDEO INPUT AC INPUT AUDIO INPUT VCR/Cable Box 1. Connect video cable(not supplied) to the VIDEO INPUT jack on the LCD TV and the video output jack on the external equipments.(VCR/Cable box, etc.,) 2.
- Page 15 Connection Connecting a VCR (S-Video) Rear of the LCD TV COMPONENT Cb / Pb VIDEO Cr / Pr S-VIDEO VIDEO INPUT AC INPUT AUDIO INPUT VCR/Cable Box External equipments(VCR/Cable Camcorder/Video game device, etc.,) 1. Connect video cable(not supplied) to the S-VIDEO INPUT jack on the LCD TV and the video output jack on the external equipments.(VCR/Cable box, etc.,) 2.
- Page 16 Connection Connecting a SCART COMPONENT Cb / Pb VIDEO Cr / Pr S-VIDEO VIDEO INPUT SCART AC INPUT AUDIO INPUT SCART SCART DVD or VCR(REAR) Connect SCART cable (not supplied) to the SCART jack on the LCD TV and the SCART output jack on the external equipments. (DVD/VCR, etc.,) To play DVD/VCR : 1.
- Page 17 Connection Connecting a DVD player (Component Video) Rear of the LCD TV COMPONENT Cb / Pb VIDEO Cr / Pr S-VIDEO VIDEO INPUT SCART AC INPUT AUDIO INPUT DVD Player 1. Connect video cables(not supplied) to the Y, Cb/Pb, Cr/Pr input jacks(Component) on the LCD TV and the video output jacks on the DVD player.
- Page 18 Connection Connecting a DTV Receiver (Component Video) Rear of the LCD TV COMPONENT Cb / Pb VIDEO Cr / Pr S-VIDEO VIDEO INPUT SCART AC INPUT AUDIO INPUT Digital Set-Top Box 1. Connect video cables(not supplied) to the Y, Cb/Pb, Cr/Pr input jacks (Component) on the LCD TV and the video output jacks on the digital Set-Top Box.
- Page 19 Connection Connecting a DTV receiver( DVI ) Rear of the LCD TV Audio Cable DVI-I 29pin Cable Digital Set-Top Box 1. Connect a DVI cable(not supplied) to the DIGITAL PC INPUT jack on the LCD TV and DVI with HDCP OUTPUT jack on the digital Set-Top Box. 2.
- Page 20 Connection Connecting a PC ( DVI ) Rear of the LCD TV DVI-I 29pin Cable Audio Cable 1. Connect a DVI 29pin cable(not supplied) to the DIGITAL PC INPUT jack on the LCD TV and DVI output jack on the PC. 2.
- Page 21 Connection Connecting a PC ( RGB) Rear of the LCD TV Audio Cable PC cable (D-sub 15pin) 1. Connect a PC cable, D-sub 15pin(not supplied) to the ANALOG PC INPUT jack on the LCD TV and RGB output jack on the PC. 2.
-
Page 22: Remote Control Buttons
Remote Control Buttons POWER : Switches Power ON/OFF. NUMBER : Allows direct access to any program. INFOR : Displaying video information on select function button as display the OSD. ➊ ➌ SOURCE : Select one video source among the Video, S-Video, SCART, Component, RGB and ➍... - Page 23 QVIEW POSITION : Switches the current program to a : In PIP mode, transfer the sub- source screen position. former program. SOURCE : In PIP mode, select the sub- TIMER : Set up the clock. source. S-SWAP : In PIP mode, exchanges main- SIZE : In PIP mode, regulate the sub-source source with the Sub-source sound.
