LCDV1955HD LCD TV USER MANUAL IMPORTANT ! WARRANTY INFORMATION INSIDE. PLEASE READ www.teac.com.au...
Page 2
The warranty does not cover freight or insurance. In all cases of transit damage or lost, a claim must be filed against the carrier by the purchaser, even if shipment is arranged by TEAC. TEAC in- home service may also be available at a fee upon request.
Page 3
*Your nearest Authorised TEAC Service Centre is listed in your Owners Manual 10. No one is authorised to assume any liability on behalf of TEAC or impose any obligation on it, in connection with the sale of any equipment other than as stated in this warranty and outlined above.
Page 4
Dealer’s Address Postcode Please ensure that your product is packed appropriately upon return to the service centre. If you have any other queries regarding service or warranty please contact the TEAC Customer Care Centre below: service@teac.com.au www.teac.com.au 1800 656 700...
Table Of Contents Important Safety Instructions......................1 View of Unit ............................3 Special Feature of DVD Module ..................... 6 Disc Information ..........................7 Remote Control..........................8 System Connections ........................12 Connecting to the Power Supply ..................... 12 Connecting to the Power Adapter....................12 Connecting to an External AV Signal Source ..................
Important Safety Instructions This symbol indicates that dangerous voltage instituting a risk of electric shock is present within this unit. This symbol indicates that there are important operation and maintenance instructions in the literature accompanying the appliance. Caution: Laser radiation when open. Do not stare into beam. Caution: use of any controls, adjustments, or procedures other than those specified herein may result in hazardous radiation exposure.
Page 7
Important Safety Instructions Read these instructions. IMPORTANT FOR LASER PRODUCTS Keep these instructions. 1. CLASS 1 LASER PRODUCT Heed all warnings. 2. DANGER: Visible laser radiation when open and Follow all instructions. interlock failed or defeated. Avoid direct exposure to Do not use near water.
View of Unit Front and Left Side Panel 1. Color TFT screen 7. USB Port EJECT button Connect the USB device. Press to eject the disc from the unit. 8. INPUT button 3. ■ STOP button Press to select enter the source selecting Press to stop disc playback in DVD mode.
Page 9
View of Unit Front and Left Side Panel 10. CH ▲/▼ buttons 12. POWER button In TV or DTV mode, press to select Press to enter or exit standby mode. channels; 13. Speaker On system setup menu, the same function 14.
View of Unit Rear Panel 1. HDMI Input Jack in Composite or S-Video mode. Composite Connect the HDMI signal source. and S-Video share L/R audio jacks. 2. upgrade port 7. COAXIAL Output Jack Connect device only Output the coaxial digital audio signal. upgrading the TV software.
Special Feature of DVD Module Your TV comes equipped with a removable DVD module. Please follow the procedures below to remove or install the DVD module. Note: Before removing or installing the DVD module, ensure that the television is unplugged and turned off.
Disc Information Discs Supported DISC LOGO CONTENTS SIZE MAXIMUM TIME 133min(SS-SL) 242min(SS-DL) Audio+Video 12cm (active picture) 266min(DS-SL) 484min(DS-DL) Audio 12cm 74min JPEG Still high resolution 12cm DIVX 12cm The operating method of some DVD discs is specified by the software maker. Please refer to the instruction manual of the disc.
Remote Control Remote Control Drawing 4. SOUND button Press to select the screen picture mode: choose from Standard, User, Sports, Movie or Music. 5. TV.RADIO button Press to select DTV program playback or Radio program playback in DTV mode. 6. 0~9 Number buttons Press to select numbers such as TV channel.
Page 14
Remote Control 16. ► PLAY button 22. FAV.LIST button Press to play a disc in DVD mode. Press to display the favorite channel list. button In Channel Edit menu, press this button to Press to search backward or forward in set a favorite channel (see for details).
Remote Control Remote Control Drawing In teletext mode, they are the teletext colour buttons. 35. REPEAT button Press to repeat a chapter, track, title or all program content in DVD mode. In teletext mode, press to hold the current page and press again to resume. 36.
Remote Control Preparation of Remote Control Using of Remote control Softly push the back cover to open the battery Point the remote control unit from no more than compartment. about 7 meters from the remote control sensor and within about 60 degrees of the front of the unit.
System Connections • Open the back cover on the right side of the unit’s rear panel. • Do not connect the power cord until all other connections have been made. • Ensure that you observe the color code when connecting audio and video cables. Connecting to the Power Supply Connect the power supply cord to the wall AC outlet, see the figure below.
System Connections Connecting to an External AV Signal Source Use the AV cables to connect the external AV signal source to the AV input jacks on the rear panel of the unit. Use a S-VIDEO cable (not supplied) to connect the external AV signal source to the S-VIDEO input jack on the rear panel of the unit.
System Connections Connecting to an External AV Signal Source(HDMI) Follow the figure below to connect an HDMI signal source to the HDMI jack on the rear panel of the unit. After connection, turn on the power of the unit and the external AV signal source.
System Connections Connecting to Coaxial Digital Output This unit is designed with a coaxial digital audio jack, can be connected to the digital amplifier, see the figure below: This feature is available only for amplifiers equipped with coaxial digital audio input connectors.
System Connections Connecting to a PC Follow the steps and figure below to connect PC to the unit. Connect one end of the VGA cable to the VGA input jack on the jack panel of the unit and the other end to the PC VGA output. Connect one end of the audio cables to the PC audio input jack on the jack panel of the television and the other end to the PC audio output jack.
System Connections Connecting to a TV Antenna Connect TV signal input source from the aerial to the TV jack on the rear panel of the unit. After connection, turn on the power of the unit. Then press the INPUT button and the direction buttons to select TV or DTV mode, press the ENTER button to confirm and conduct program selection.
Input Source Selecting The unit incorporates multiple video modes which can be selected via the Input button on the television or remote. Press the INPUT button to enter Input menu. The screen will display as shown below: Use the direction buttons and ENTER button On the input menu, press the direction button to select the desired video mode.
TV Function Preparations 1. After connection, press the POWER button to turn on the unit. 2. Press the INPUT button to select TV mode and you can then conduct the following operations: Note: In other mode, you can refer to the following instructions in TV mode to go on with some settings.
TV Function If you use the unit for the first time or if your setup has changed, you can setup the unit from Channel Setup menu. Please follow the instructions below: Channel Setting Press the MENU button once to enter CHANNEL setup menu as shown on the right.
Page 26
TV Function DTV Manual Tuning Press the ▲▼ button to select DTV Manual Tuning and press the ENTER or ► button, the screen will display as shown on the right: Press the ◄► button to select desired channel number and press the ENTER button to start tuning.
TV Function Rename a channel: (this function is only available for ATV channels) Press the ▲▼ button to select a channel you want to rename and press the green button to set a symbol “ ” on the channel. Press the ◄► button to highlight the character position of channel name and press the ▲▼...
Page 28
TV Function Brightness Press the ▲▼ button to select Brightness and press the ◄► or ENTER button to enter the brightness adjusting bar. Press the ◄► button to darken or brighten the picture. Color Press the ▲▼ button to select Color and press the ◄► or ENTER button to enter the color adjusting bar.
Page 29
TV Function Blue Press the ▲▼ button to select Blue and press the ◄► or ENTER button to enter the adjusting bar. Press the ◄► button to select adjust the level. Note: The items Red, Green and Blue are only available when Color Temperature is set to User. Within the adjusting bar, you can select Red, Green and Blue by pressing the ▲▼...
TV Function Sound Setting Press the MENU button once to enter CHANNEL setup menu and press the ▲▼ button to select SOUND, the screen will display as shown. Press the ENTER or ► button to enter the menu. In the SOUND setup menu, press the ▲▼ button to select the desired item.
TV Function Time Setting Press the MENU button once to enter CHANNEL setup menu and press the ▲▼ button to select TIME, the screen will display as shown. Press the ENTER or ► button to enter the menu. In the TIME setup menu, press the ▲▼ button to select the desired item.
TV Function Sleep Timer Press the ▲▼ button to select Sleep Timer and press the ◄► button to select the time to turn off the TV. Auto Sleep Press the ▲▼ button to select Auto Sleep and press the ◄► button to select On or Off. Time Zone Press the ▲▼...
Page 33
TV Function Subtitle Language Press the ▲▼ button to select Subtitle Language and press the ENTER or ► button to prompt a information box, as shown: Press the ▲▼ button to select Primary or Secondary, press the ◄► button to select desired language.
EPG Function In DTV mode, press the EPG button to display the CHANNEL GUIDE menu as shown below: Within this menu, press the ▲▼ button to select a desired channel. Press the DISPLAY button to display the detail information of the selected channel. Press the yellow button to check the date information.
NICAM Function The unit supports NICAM function when in TV mode. Under NICAM TV broadcast: 1. When receiving stereo audio signals, press the STEREO button on the remote control repeatedly to select the sound tracks between NICAM STEREO and Mono and the screen will show the corresponding display as shown below: 2.
DVD Playback Operation Preparation 1. Connect the unit to the power supply and press the POWER button to turn on the unit. 2. Repeatedly press the INPUT button on the remote control to select DVD mode and press the ENTER button to enter. 3.
Page 37
DVD Playback Operation Previous and Next Press the button to go to the next chapter. Press the button once to return to the beginning of the current chapter or track; press it twice to go to the previous chapter. Fast Playback During playback, press the button to activate fast backward or forward playback.
Page 38
DVD Playback Operation CD Playback The player will play all tracks on a CD disc by default. You can use the buttons, or number buttons to select a track. Stop Press the ■ STOP button once to stop playback and press the ► PLAY button to resume normal playback.
DVD Playback Operation JPEG Playback JPEG is a common picture format that requires small amounts of storage per image and has low loss in resolution. Hundreds of pictures can be stored on a disc in this format. In order to view JPEG photo albums, you can ask your film development company to make a ”PICTURE CD”...
DVD Playback Operation DIVX Playback DIVX is the name of a revolutionary new video code, which is based on the new DIVX compression standard for video. Load a DIVX disc in the disc tray, the player will enter the reading mode. The screen displays the root menu.
USB and SD/MS/MMC Card Function Preparation In DVD mode, connect USB device to the USB port or insert SD/MS/MMC card into the SD/MS/MMC card slot on the right side of the unit. Make sure that files are stored in the USB and SD/MS/MMC card before connection. 1.
DVD System Setup Preparation 1. In DVD mode, press the SETUP button to enter DVD system setup menu. 2. Press the ◄► button to select setup menu. 3. Press the SETUP button again to exit DVD system setup menu. General Setup Page Press the SETUP button to enter the General Setup Page.
Page 43
DVD System Setup OSD Lang 1. Press the ▲▼ direction buttons to select OSD Lang. 2. Press the ENTER button to enter the setup. 3. Use the ▲▼ direction buttons to select desired OSD language. 4. Press the ENTER button again to confirm selection and return.
Page 44
DVD System Setup Audio Setup Page Press the SETUP button to enter the General setup menu, then use the ◄► direction buttons to select Audio Setup Page, the screen will display as the below: On the menu, Use the ▲▼ direction buttons to select the desired item.
DVD System Setup HDCD Setup In the Audio Setup Page, use the ▲▼ direction buttons to select HDCD Setup. Press the ENTER button to enter the menu as shown below: 1. On the menu, press the ENTER button to enter the setup.
DVD System Setup Brightness 1. Press the ▲▼ direction buttons to select Brightness. 2. Press the ENTER button to enter the setup 3. Use the ◄► direction buttons to adjust the level. 4. Press the ENTER button again to confirm setting and return.
Page 47
DVD System Setup Audio 1. Press the ▲▼ direction buttons to select Audio. 2. Press the ENTER button to enter the setup. 3. Press the ▲▼ direction buttons to select audio language. 4. Press the ENTER button again to confirm setting and return.
Troubleshooting SYMPTOM CHECK ITEM Make sure the disc is loaded in. Make sure the disc is not dirty or warped. Make sure the player’s region code is the same as the region The player cannot play. code of the DVD disc. Make sure water condensation has not occurred.
Specifications Model LCDV1955HD Screen Size 19-inch TFT LCD TV Native Resolution 1440×900 Pixels Brightness 300cd/m2 Contrast Radio 800 :1 Response time (ms) Color System Sound System BG/I/DK Tuner VHF/UHF: 48.25~863.25MHz Antenna 75Ω VHF/UHF input Stereo NICAM/A2 VIDEO INPUT CVBS input PAL/SECAM/NTSC Y/C separate video signal Y...1 Vp-p/negative sync/75Ωinput C...0.283...
Page 56
TEAC CUSTOMER CARE CENTRE (TCCC) Free call: 1800 656 700 Between Monday to Friday – EST 9AM to 5PM...
