Marantz PM-KI-PEARL /N1B/U1B Service Manual
  1. Manuals
  2. Brands
  3. Marantz Manuals
  4. Amplifier
  5. PM-KI-PEARL /N1B/U1B
  6. Service manual

Marantz PM-KI-PEARL /N1B/U1B Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Service
Manual
SECTION
1. TECHNICAL SPECIFICATIONS............................................................................................1
2. CAUTION ...............................................................................................................................1
3. ALIGNMENTS ........................................................................................................................2
4. SERVICE MODE ....................................................................................................................4
5. PROTECTION MODE ............................................................................................................6
6. MAIN MICROPROCESSOR (QU01) UPDATE PROCEDURE ..............................................8
7. WIRING DIAGRAM ..............................................................................................................23
8. BLOCK DIAGRAM ...............................................................................................................25
9. SCHEMATIC DIAGRAM ......................................................................................................27
10. PARTS LOCATION ..............................................................................................................39
11. EXPLODED VIEW AND PARTS LIST ..................................................................................65
12. MICROPROCESSOR AND IC DATA ...................................................................................71
13. ELECTRICAL PARTS LIST ..................................................................................................77
14. AFTER REPLACEMENT OF U-PRO OR FLASH ROM ......................................................94
Please use this service manual with referring to the user guide (D.F.U.) without fail.
修理の際は、 必ず取扱説明書を準備し操作方法を確認の上作業を行ってください。
X0477V02DM/DG0910

TABLE OF CONTENTS

PM-KI-PEARL
PM-13S2
Copyright 2009 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.
PM-KI-PEARL /
PM-13S2 /
FN/K1G
Integrated Amplifier
PAGE
Part no. 90M28AJ855020
N1B/U1B
Ver. 2
Please refer to the
MODIFICATION NOTICE.
First Issue 2009.10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM-KI-PEARL /N1B/U1B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marantz PM-KI-PEARL /N1B/U1B

Summary of Contents for Marantz PM-KI-PEARL /N1B/U1B

  • Page 1: Table Of Contents

    Service PM-KI-PEARL / N1B/U1B PM-13S2 / FN/K1G Manual Integrated Amplifier TABLE OF CONTENTS SECTION PAGE 1. TECHNICAL SPECIFICATIONS....................1 2. CAUTION ..........................1 3. ALIGNMENTS ........................2 4. SERVICE MODE ........................4 5. PROTECTION MODE ......................6 6. MAIN MICROPROCESSOR (QU01) UPDATE PROCEDURE ..........8 7. WIRING DIAGRAM ......................23 8.
  • Page 2 MARANTZ Parts for your equipment are generally available to our National Marantz Subsidiary or Agent. ORDERING PARTS : Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.

  • Page 3: Technical Specifications

    1. TECHNICAL SPECIFICATIONS Power output (20 Hz – 20 kHz simultaneous drive of both Maximum allowed PHONO input (1kHz) channels) ....(8Ω load) 90 W x 2 [ N1B / U1B / FN ] MC ................. 15 mV ............. 80 W x 2 [ K1G ] MM ..............

  • Page 4: Alignments

    3. ALIGNMENTS アイ ド リ ング電流調整 Idling Current Adjustment Digital Voltmeter Digital Voltmeter R ch L ch P701 P601 R725 R729 J709 R629 R625 J609 1. リ アパネルの SPEAKER の LchとRch の端子にデジタル 1. Digital voltage is connected with Lch/Rch of the speaker ボル...
  • Page 5 Digital Voltmeter Digital Voltmeter PHONO P.DIRECT F.C.B.S. PRE OUT PHONO SPEAKER SYSTEMS BI.AMP STEREO SPEAKER IMPEDANCE : 4 - 8 OHMS LINE 2 RECORDER DC オフセット電圧調整 DC Offset Voltage Adjustment 5. 最初に、 P601/P701 基板上の半固定抵抗 R625とR725 5. First, adjust the DC offset voltage with the variable resistor でDCオフセ...

  • Page 6: Service Mode

    4. SERVICE MODE DISPLAY button DISPLAY ATT button PHONO P.DIRECT F.C.B.S. PRE OUT PHONO SPEAKER SYSTEMS BI.AMP STEREO SPEAKER IMPEDANCE : 4 - 8 OHMS LINE 2 RECORDER POWER ON/OFF button 1. 本 体 の DISPLAY ボ タンと ATT ボ タン を 押し な が ら 1.
  • Page 7 2. DISPLAYボタンを押します。下記の表示になり ます。 2. Press DISPLAY button, the display will be the following. 3. DISPLAYボタンを押します。下記の表示になり ます。 3. Press DISPLAY button, the display will be the following. 4. POWER ON/OFFボタンを押し、 電源を切り ます。サービ 4. Turn off power to quit service mode. スモー ドが解除されます。 Service mode can be ended if turn off power from every サービスモー...

  • Page 8: Protection Mode

    5. PROTECTION 動作について 5. PROTECTION MODE マイコン(QU01)のPROT-1 (pin54) とPROT-2 (pin53)の説明。 Explanation of microprocessor (QU01) [PROT-1 (pin54) and PROT-2 (pin53)]. [A] PROT-1(pin54) は、 パワーアンプの下記の異常動作を検 [A] The PROT-1(pin54) is the port to detect the following 出するポー ト abnormalities of the Power AMP 1.
  • Page 9 [B] PROT-2 (pin53) は、 電源回路の異常を検出するポー ト To check if the amp is in order, switch off the unit and switch 1. パワーアンプ用電源回路の異常を検出。 it on again one minute later. This action will deactivate パワーアンプ用電源の +50V と-50V の中点電圧を監視し、 the protection operation. If the PROT-1 (pin54) remains R829とR830 の接続点の電圧が約...

  • Page 10: Main Microprocessor (Qu01) Update Procedure

    6. MAIN MICROPROCESSOR (QU01) UPDATE 6. MAIN MICROPROCESSOR (QU01) アップデート方法 PROCEDURE Necessary Equipment 必要機器 • Windows PC (OS:Windows2000 または WindowsXP) • Windows PC (Windows2000 or WindowsXP) with COM port でCOM port のあるもの • RS232C cable straight type (9pin female - 9Pin •...
  • Page 11 6.2. 書き込みソフトウェアのインストール 6.2. Installs of The software (Flash Development Toolkit 3.0) (Flash Development Toolkit 3.0) The explanation drawing 説明図について • The explanation drawings are using PM-11S1 in this • 説明図は PM-11S1 を使用しています。 図中に PM-11S1 section. Please replace with PM-KI-PEARL / PM-13S2 と記載されている箇所は...
  • Page 12 3. インス トールウィ ザー ドが起動します。 Nextをク リ ッ ク します。 3. Click Next. 4. 言語を選んでNextをク リ ッ ク します。 4. Choose the language. And click Next. 5. Yesをク リ ッ ク します。 5. Click Yes.
  • Page 13 6. チェ ッ クボッ クス全てにチェ ッ クが入っていることを確認して 6. Check to the all check boxes. And click Next. Nextをク リ ッ ク します。 7. Nextをク リ ッ ク します。 7. Click Next. 8. チェ ッ クボッ クス全てにチェ ッ クが入っていることを確認して 8. Check to the all check boxes. And click Next. Nextをク...
  • Page 14 9. Nextをク リ ッ ク します。 9. Click Next. 10. Nextをク リ ッ ク します。 10. Click Next. 11. Nextをク リ ッ ク します。 11. Click Next.
  • Page 15 12. Installをク リ ッ ク します。 12. Click Install. 13. インス トールを開始します。 13. The status bar appears. 14. Finishをク リ ックして書き込みソフ ト ウェアのインス トールを 14. Click Finish. 完了 します。...
  • Page 16 6.3. 書き込みソフトウェアの設定 6.3. The writing software setup procedure. Launch up the writing software. ソフ ト ウ ェ アの起動 1. Click Start / Programs / Renesas / Flash Development 1. Start / Programs / Renesas / Flash Development Toolkit 3.0 / Flash Development Toolkit 3.0. Toolkit 3.0 / Flash Development Toolkit 3.0 をク...
  • Page 17 3. Create a new project workspaceにチェ ッ クを入れ、 OK 3. Check Create a new project workspace, and click OK. をク リ ッ ク します。 4. Workspace Name に PM-15と入力します。 4. PM-15 is inputted into the Workspace name. ( 同時に Project Name にも入力されます。) (It is simultaneously inputted into Project Name.) OKをク...
  • Page 18 6. Select Portから接続するSerial Port 番号を選び、 ク リ ッ ク 6. Choose the Serial port No. in the Select Port. します。Nextをク リ ッ ク します。 Click Next. 7. 8.0 is inputted into the "Enter the CPU crystal frequency 7. "Enter the CPU crystal frequency for the selected device:"...
  • Page 19 9. ProtectionからAutomaticにチェ ッ クを入れます。 9. Check the Automatic in Protection. MessagingからAdvancedにチェ ッ クを入れます。 Check the Advanced in Messaging. Finishをク リ ッ ク します。 Click Finish. 以上で設定は完了です。...
  • Page 20 6.4. 書き込み方法 6.4. Writing procedure 1. Click Start / Programs / Renesas / Flash Development 1. Start / Programs / Renesas / Flash Development Toolkit3.0 / Flash Development Toolkit3.0. Toolkit3.0 / Flash Development Toolkit3.0 をク リ ッ ク します。 2. Click OK. (This window appears at every starting) 2.
  • Page 21 5. ア ッ プデー トディ スク （90M-PM15S2CDR） の softフ ォルダ 5. Open the CD-ROM (90M-PM15S2CDR) and double click をダブルク リ ッ ク します。 soft folder. 6. V090507.motを選択し、 Addをク リ ッ ク します。 6. Select V090507.mot, and Click Add. 7. V090507.mot のホルダーが出来ます。 7.
  • Page 22 8. PM-KI-PEARL / PM-13S2とWindows PC の COM ポー 8. It checks that PM-KI-PEARL / PM-13S2 and the COM トの接続を確認します。 port are connected by RS232C cable. 9. POWERボタンを押し、 Power On 状態にします。 9. Press POWER Button to turn on the unit. (この状態より、 書き込みモー ドですが、 前面の LED 及び The unit is in the boot mode.( LED and LCD display on LCD 表示は消えます。) the front panel disappear.)
  • Page 23 12. 以上で、 書き込み作業は終了です。 12. The Main microprocessor (QU01) has been Update. 13. PM-KI-PEARL / PM-13S2 の電源を切り、 FFC ケーブルを 13. Turn off Power switch, then disconnect FFC cable from 外します。 PM-KI-PEARL / PM-13S2. 14. VERSION の確認を します。 14. Check the version number of the firmware Refer to "4.
  • Page 24 Personal notes:...

  • Page 25: Wiring Diagram

    7. WIRING DIAGRAM P401 P251 P351 00MWA27AJ203- 00MWG27AJ307- 00MWA27AJ102- PHONO/CD PWB TONE PWB PRE OUT PWB J482 J402 J251 J372 J105 J104 J201 J321 P601 W019 J605 J905 W031 J301 J601 W005 J602 J903 00MWA27AJ201- LCH POWER W007 W013 J603 J901 P651 AMP PWB...

  • Page 26: Block Diagram

    8. BLOCK DIAGRAM PHONO EQULIZER PRE OUT BUFFER PM-15S2,PM-13S2,PM-KI-PEARL PRE OUT PHONO RIAA MUTE POWER BUFFER RIAA DIRECT IN CD DIRECT POWER AMP TREBLE BUFFER BASS MUTE TONE CONTROLLER SPEAKER OUT LINE 1 LINE BUFFER HEADPHONE LINE 2 REC.1 PROTECT REC.2 REC OUT BUFFER...

  • Page 27: Schematic Diagram

    9. SCHEMATIC DIAGRAM P101 00MWA27AJ1010...
  • Page 28 5307 00MWG27AJ3070 P351 00MWA27AJ1020 5501 00MWG22AJ5010 5601 00MWA27AJ6010...
  • Page 30 P401 00MWA27AJ2030 TPZ409 R443 +22V JAMPER +21.4V +21.4V L401 F,U: N.C L401 R427 R435 +0.6V +0.6V K,N: 320UH 320UH +20.8V EX01 Q401 Q415 Q417 F,U: 0 +VCC K,N: N.C HDAM-SA3 HDAM-SA HDAM-SA C407 R453 +20.2V F,U: 100P F,U: N.C TPZ401 +OUT +OUT +OUT...
  • Page 31 P891 00MWA27AJ2100 J831 TPF832 +28V +28V TPF833 PROT_1 PROT_1 POWER SW PWB TPF834 D_GND W013 D_GND S891 TPF835 TO SPK PWB SP_ON SP_ON J907 TPF836 C891 R831 470p B-GND Q831 KTA1267 TPF810 TPF805 J891 R833 NORMAL 0V V-DET V-DET TPF811 TPF806 PROT-2 B-GND...
  • Page 32 PD71 00MWG27AJ3030 +3.3V +15V PD71 CU16 JU01 1000p 00MWG27AJ3030 +3.3V CU17 15.0V TPFU63 1000p SU73 CLOCK:8.0MHz TPZU54 TPFU01 +3.3V LU01 D_OE DISP P_DIRECT MC_ON TPZU29 CU03 MC_ON ON 3.0V ON 3.6V ON 3.6V TPFU02 TPZU03 LU02 D_CE OFF 15V OFF 15V OFF 15V VOLUME 0.01u...

  • Page 33: Parts Location

    10. PARTS LOCATION P101 A C101 B16 C182 C11 C505 B10 C876 E8 L132 B14 Q507 B8 Q872 D8 R148 C14 R205 B2 R358 E5 R531 B7 R875 D7 U114 D15 C102 D16 C183 B12 C506 B10 C877 D10 L133 B14 Q508 A8 Q873 E8 R149 C14...
  • Page 34 P101 B J202 E1 Q501 C10 鉛フリー半田 半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。 Lead-free Solder When soldering, use the Lead-free Solder (Sn-Ag-Cu).
  • Page 35 P102 A P201 A C601 D1 Q612 D7 R640 B4 C602 B3 Q613 D7 R641 B6 C603 B1 Q614 D7 R642 B4 C604 D1 Q615 D6 R643 B6 C605 C7 Q616 D7 R644 B6 C606 C7 Q617 D5 R645 B6 C607 C4 Q618 C5 R646 B6...
  • Page 36 P202 A C701 B1 D718 C6 Q717 B5 R722 B4 R750 C7 U362 B6 C702 C1 D719 C6 Q718 C5 R723 A6 R751 C7 U363 D6 C703 C3 J701 A1 Q719 C4 R724 A6 R752 C7 U364 B6 C704 B1 J702 D5 Q720 D5 R725 A6...
  • Page 37 P203 A C401 D8 C433 D8 Q404 B6 R414 B6 R444 B2 U384 B2 C403 D8 C434 C8 Q405 D6 R415 D6 R445 D2 U385 C2 C404 C8 C437 C6 Q406 B6 R416 B6 R446 B2 U386 B3 C405 D8 C438 C6 Q407 D6 R417 C6...
  • Page 38 P204 A P204 B C901 D2 D904 C2 Q951 A7 R903 D6 U422 C2 U439 C6 C902 D5 D951 D7 Q952 B7 R904 D6 U423 B2 U440 D5 C903 D2 D952 C7 Q953 C7 R905 C2 U424 B2 U441 C7 C904 D5 J901 D3 Q954 C5...
  • Page 39 P205 A P205 B C821 C3 R821 D4 C824 C3 R827 C3 C834 C2 R828 C3 C835 C3 R829 C2 C836 C2 R830 C3 D801 B2 R836 C2 D802 B3 R837 C3 D831 C2 R838 B1 D832 C2 U451 B1 D833 C2 U453 B2 D834 C2...
  • Page 40 P208 A P208 B C822 B7 D823 A7 J821 A6 L854 C5 Q854 D5 R858 D4 C823 B6 D824 A7 J822 D6 L855 C4 Q855 D3 R859 C4 C831 D6 D851 C1 J824 A8 L856 C4 R822 B8 R860 D4 C832 C6 D852 C1 J825 E8...
  • Page 41 P209 A P211 A P211 B C991 B2 J871 B3 C992 A1 J872 B2 J991 A3 J992 A1 R991 A1 R992 A1 W991 B1 P209 B P212 A P212 B P210 A P210 B P213 A P213 B C891 A3 J891 A2 S891 B2 鉛フリー半田...
  • Page 42 P301 A CU01 D9 CU83 B5 QU04 C11 RU28 D10 CU02 D9 DD02 D11 QU07 C9 RU29 D4 CU03 D11 DU61 C3 QU08 C9 RU30 D5 CU04 D11 DU62 A2 QU09 D5 RU31 D5 CU05 C10 DU63 C2 QU12 D5 RU32 D9 CU06 D11 DU71 C12...
  • Page 43 P302 A P302 B CD01 B4 JD02 B4 CD02 B4 QD02 B4 CD03 B4 QU05 B2 CD04 B4 QU06 B5 CD05 B4 QU11 C1 CD06 A4 RD01 C4 CD07 A4 RD03 B5 CD08 B4 RD05 B4 CD09 B4 RD06 B4 CD10 B4 RD07 B4 CD12 B4...
  • Page 44 P305 A P305 A P304 A P304 B CD11 B1 CU81 A1 DD11 A1 CU82 B1 JD11 B1 JU31 A2 RD11 B1 SU82 B2 P306 A P306 B CB01 A4 JB07 B1 RB02 A5 CB02 B4 JB11 C3 RB03 B4 CB03 B4 JB12 C4 RB04 B3...
  • Page 45 P307 A P307 B P601 A P601 B JS01 A2 QS01 A1 QS02 A1 QS03 A1 QS04 B1 RS01 A1 RS02 A1 RS03 A1 RS04 A1 RS05 A1 C251 A3 Q251 B3 C252 A2 Q252 B2 C253 A3 R251 A3 C254 B1 R252 A1 5501 A...

  • Page 46: Exploded View And Parts List

    11. EXPLODED VIEW AND PARTS LIST V E R S I O N Ｐ Ａ Ｒ Ｔ Ｓ Ｎ ＡＭ Ｅ ＭＡ Ｒ Ｋ ＭＡ Ｔ Ｅ Ｒ Ｉ Ａ Ｌ／Ｆ Ｉ Ｎ Ｉ Ｓ Ｈ SYMBOL Ｓ Ｔ Ｙ Ｌ Ｅ +B.H.M.SCREW （Ｍ）...
  • Page 47 POS. VERS. PART NO. POS. VERS. PART NO. PART NO. (MJI) PART NAME DESCRIPTION PART NO. (MJI) PART NAME DESCRIPTION COLOR (FOR EUR) COLOR (FOR EUR) 001D 00M21AJ257110 TOP COVER ASSY GOLD TOP COVER ASSY (GL) 039B 00M04AJ353110 MASTER KNOB RING GOLD MASTER KNOB RING (GL) 001D 00M21AJ257110 TOP COVER ASSY GOLD...
  • Page 48 POS. VERS. PART NO. PART NO. (MJI) PART NAME DESCRIPTION COLOR (FOR EUR) NOT STANDARD SPARE PARTS 001S 531210101006M PACKING CASE PACKING CASE PM-13S2 28AJ 001S 531210101006M PACKING CASE PACKING CASE PM-13S2 28AJ 001S 531210078007M 531210078007M PACKING CASE PACKING CASE PM-KI-PEARL 28AJ 001S 531210078007M PACKING CASE PACKING CASE PM-KI-PEARL 28AJ...

  • Page 49: Microprocessor And Ic Data

    12. MICROPROCESSOR AND IC DATA PD01 / QU01 : H8/3687...
  • Page 50 PD01 /QU01:H8/3687 SIGNAL PORT Functions Description NAME PB6_AN6 Left key A/D pin PB7_AN7 Model select AVcc AVCC Analog power supply Internal step-down power supply /RES Reset pin TEST TEST Test pin Connect to GND OSC2 OSC2 Main clock output OSC1 OSC1 Main clock input 8MHz...
  • Page 51 SIGNAL PORT Functions Description NAME P16_/IRQ2 PROT_2 Power supply error detect Active L(POW_OFF) P17_/IRQ3_TRGV PROT_1 DC/over current/Temp detect Active L(VOL -∞) L_CS LCD-Controler(ST7032) CE Active L L_SCL LCD-Controler(ST7032) Serial Clock Out L_RS LCD-Controler(ST7032) Register Select H/L = Data/Instruction L_RES LCD-Controler(ST7032) Reset Active L(Reset) PB3_AN3 TEST1...
  • Page 52 PB01 / QB21 : PC817 Anode Cathode Emitter Collector LC78211, 78212, 78213 Continued from preceding page. P101 / Q161 : LC78212...

  • Page 53: Pin Description

       DA6116.001   27 February, 2009  PIN CONFIGURATIONS P101 / Q501 : MAS6116 SO16 AGND AVCC ROUT    DA6116.001   27 February, 2009 RGND LGND RGND  DGND ZERO PEAK DVCC PIN CONFIGURATIONS CCLK CROSSING DETECTOR...
  • Page 54 PB01 / QU02 : AT24C08 PD01 / QU03 : 74HC4094 P101 / Q181 : 74HC4094...

  • Page 55: Electrical Parts List

    13. ELECTRICAL PARTS LIST PARTS INFORMATION NOTE ON SAFETY FOR FUSIBLE RESISTOR : The suppliers and their type numbers of fusible resistors RESISTORS are as follows; 1) 00MGD05 × × × 140, Carbon film fixed resistor, ±5% 1/4W 1. KOA Corporation 2) 00MGD05 ×...

  • Page 56: Display

    VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) HDAM-SA3 PWB(00MWG22AJ501-) 5501 DN01 00MHZ20014990 00MHZ20014990 KDS122 TAPING 5501 DN02 00MHZ20014990 00MHZ20014990 KDS122 TAPING 5501 DN03 00MHZ20014990 00MHZ20014990 KDS122 TAPING 5501 DN04 00MHZ20014990 00MHZ20014990 KDS122 TAPING 5501 JN01 00MYP07005670...
  • Page 57 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P101 C203 00MOF15101540 00MOF15101540 100PF J 100V APSV 100PF J 100V APSV P101 C204 00MOF15101540 00MOF15101540 100PF J 100V APSV 100PF J 100V APSV P101 C205 00MOF15101540 00MOF15101540 100PF J 100V APSV...
  • Page 58 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P101 J102 00MYT02041330 00MYT02041330 YKC21-3601V 2L4P FG BK AU YKC21-3601V 2L4P FG BK AU P101 J103 00MYT02041330 00MYT02041330 YKC21-3601V 2L4P FG BK AU YKC21-3601V 2L4P FG BK AU P101 J104 00MYJ06006280...
  • Page 59 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P101 Q525 00MHT800931A0 00MHT800931A0 KTC3200 KTC3200 NPN TRANSISTOR RANK=GR P101 Q526 00MHT800931A0 00MHT800931A0 KTC3200 KTC3200 NPN TRANSISTOR RANK=GR P101 Q527 00MHT600121A0 00MHT600121A0 KTA1268 KTA1268 PNP TRANSISTOR RANK=GR P101 Q528 00MHT600121A0...
  • Page 60 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) PRE OUT PWB(00MWA27AJ102-) P351 C371 K1G 00MOF15101540 00MOF15101540 100PF J 100V APSV 100PF J 100V APSV P351 C371 N1B 00MOF15101540 00MOF15101540 100PF J 100V APSV 100PF J 100V APSV P351 C372 K1G...
  • Page 61 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P401 C487 00MOF56331540 00MOF56331540 STAR(126)100VDC331J7-10 STAR(126)100VDC331J7-10 P401 C488 00MOF56331540 00MOF56331540 STAR(126)100VDC331J7-10 STAR(126)100VDC331J7-10 P401 C489 00MOA226025Z0 00MOA226025Z0 ROS-25V 220M - F3#PE - T2 (22UF 25V) ROS-25V 220M - F3#PE - T2 (22UF 25V) P401 C490 00MOA226025Z0 00MOA226025Z0 ROS-25V 220M - F3#PE - T2 (22UF 25V)
  • Page 62 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P601 D615 00MHD20002000 00MHD20002000 1SS133 T-77 1SS133 T-77 P601 D616 00MHD20002000 00MHD20002000 1SS133 T-77 1SS133 T-77 P601 D618 00MHD20027010 00MHD20027010 HSS81TD-E 150V 150MA AXIAL TAPG. HSS81TD-E 150V 150MA AXIAL TAPG.
  • Page 63 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P601 R646 00MGG05102160 00MGG05102160 1K OHM +- 5% 1/6W 1K OHM +- 5% 1/6W P601 R647 00MGG05472160 00MGG05472160 4.7K OHM +- 5% 1/6W 4.7K OHM +- 5% 1/6W LCH POSISTOY PWB(00MWA27AJ206-) P651 R671 U1B...
  • Page 64 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P701 Q720 00MHT348832A0 00MHT348832A0 ! TRANSISTOR 2SC4883 O OR Y TRANSISTOR 2SC4883 O OR Y P701 Q721 00MHT118592A0 00MHT118592A0 ! TRANSISTOR 2SA1859 O OR Y TRANSISTOR 2SA1859 O OR Y P701 KT07...
  • Page 65 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P801 Q835 00D2710311906 00D2710311906 KTA1267-GR-AT/P KTA1267-GR-AT/P P801 R838 00MGG05010140 00MGG05010140 ! 1 OHM 1/4W 1 OHM +-5% 1/4W MATSUSHITA:ERD25FYJ1R0T STANDBY PWB(00MWA27AJ208-) P851 C822 1340500220070 1340500220070 UFW1V472MHD1AA UFW1V472MHD1AA P851 C823...
  • Page 66 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P851 Q852 00D2690206908 00D2690206908 KRC102M-AT/P (10K-10K) KRC102M-AT/P (10K-10K) P851 Q853 00MHC3850509F 00MHC3850509F ! NJM78M05FA NJM78M05FA P851 Q854 00MHT800931A0 00MHT800931A0 KTC3200 NPN TRANSISTOR RANK=GR KTC3200 NPN TRANSISTOR RANK=GR P851 Q855 00D2690206908...
  • Page 67 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) P991 J991 K1G 00MYJ01005190 00MYJ01005190 YKB21-5834N (GRY/GLD) HEADPHONE YKB21-5834N (GRY/GLD) HEADPHONE JACK JACK P991 J991 N1B 6430100020040 6430100020040 YKB21-5805 HP JACK YKB21-5805 HP JACK P991 J991 U1B 6430100020040 6430100020040 YKB21-5805 HP JACK...
  • Page 68 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) PD01 CU62 00MEG10601650 00MEG10601650 10UF/ 16V 10UF/ 16V PD01 CU63 00MEG10601650 00MEG10601650 10UF/ 16V 10UF/ 16V PD01 CU64 00MEG10601650 00MEG10601650 10UF/ 16V 10UF/ 16V PD01 CU65 00MDK96103300 0.01UF +-10% 50V C1608JB1H103K 0.01UF +-10% 50V C1608JB1H103K...
  • Page 69 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) PD01 QU22 00MBA21303000 00MBA21303000 DTC124EU RN1303 UMT TYPE DTC124EU RN1303 UMT TYPE PD01 QU61 00MBA21303000 00MBA21303000 DTC124EU RN1303 UMT TYPE DTC124EU RN1303 UMT TYPE PD01 QU62 00MBA21303000 00MBA21303000 DTC124EU RN1303 UMT TYPE...
  • Page 70 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) PD01 SU71 00MSP01013370 00MSP01013370 EVQ11L05R H/5MM 160GF EVQ11L05R H/5MM 160GF PD01 SU72 00MSP01013370 00MSP01013370 EVQ11L05R H/5MM 160GF EVQ11L05R H/5MM 160GF PD01 SU73 00MSP01013370 00MSP01013370 EVQ11L05R H/5MM 160GF EVQ11L05R H/5MM 160GF PD01 XU01...
  • Page 71 VERS. PART NO. PART NO. POS. NO. PART NAME DESCRIPTION NAME COLOR (FOR EUR) (MJI) HDAM-SA2D PWB(00MWA27AJ601-) PS01 JS01 00MYP07005670 00MYP07005670 IMSA-6065B-06Z065-PT1 IMSA-6065B-06Z065-PT1 PS01 QS01 00MHT600121A0 00MHT600121A0 KTA1268 PNP TRANSISTOR RANK=GR KTA1268 PNP TRANSISTOR RANK=GR PS01 QS02 00MHT800931A0 00MHT800931A0 KTC3200 NPN TRANSISTOR RANK=GR KTC3200 NPN TRANSISTOR RANK=GR PS01 QS03...

  • Page 72: After Replacement Of U-Pro Or Flash Rom

    14. AFTER REPLACEMENT OF U-PRO OR FLASH ROM When replaced of the U-PRO (Microprocessor) or the Flash ROM, confirm contents of the following. Pos. After PWB Name Description Remark replaced PD01 QU01 HD64F3687H FLASH After replaced A : Mask ROM (With software). No need write-in of software to the microprocessor. B : Flash ROM (With software).

This manual is also suitable for:

Pm-13s2 /fn/k1g

Table of Contents
