Defensor PH15 Operating Instructions Manual page 43

Pos. Art.-No. Spare parts designation
1 2525253 Air outlet lattice right
2 252525 Air outlet lattice left
3 252531 Intake lattice
 2525255 Frame
5 1103 Motor support
 252530 Side board
 252525 Protecting grill cpl.
 252525 Handle
9 252525 Roll water carriage (2 pcs.)
1 25209 Water tank
1 11050 Tank cap with integrated level regulating valve with gasket
19 252523 Mobile base cpl.
20 252525 Double roll (2 pcs.)
21 25252 Double roll with brake (2 pcs.)
22 25252 Swash chicane (2 pcs.)
23 110319 Base cover
2 1105 Droplet trap
25 1102319 Coarse dust filter (5 pcs.)
2 252592 Carriage
2 11005 Evaporator mat
2 11025 Connecting bars with support
29 25252 Float cover
30 1102 Level switch
31 11035 Safety switch
32 110 Impeller
33 111535 Electrodes ionisation
3 252529 Impeller motor
35 252520 Fan cpl.
3 252521 Control panel Defensor
3 1115515 Display LCD
3 252530 Control PCB
39 110319 Humidity sensor cpl.
0 1113552 Gasket for tank cap with integrated level regulating valve
1 25259 Radio humidistat
2 2525353 Reiceiver module radio humidistat
3 2525305 Transformer 100 V
 1101225 Coarse dust filter
111032 Brush for impeller
5 252559 Support ionisation electrode cpl. (2 pcs.)
 2530 Micro switch with cable
3
