Xerox Phaser 3635 Service Manual
Hide thumbs
Also See for Phaser 3635:
- User manual (228 pages) ,
- System administration manual (212 pages) ,
- Service manual (202 pages)
Subscribe to Our Youtube Channel
Related Manuals for Xerox Phaser 3635
Summary of Contents for Xerox Phaser 3635
-
Page 1: Multifunction Printer
Phaser ® 3635MFP Black-and-white Multifunction Printer Service Manual Xerox Phaser 3635MFP ® Multifunction Printer fineline6... - Page 2 1 Service Call Procedures SCP 1 Initial Actions......................SCP 2 First Call Actions....................SCP 3 Normal Call Actions ..................... SCP 4 Fault Analysis ...................... SCP 5 Subsystem Maintenance ..................SCP 6 Final Actions ......................SCP 7 Machine Configurations and Options..............Draft 4 Service Call Procedures Phaser 3635MFP...
-
Page 3: Status Indicator Raps
2 Status Indicator RAPs Chain 1 - Standby Power Chain 9 - Xerographics 01-100 Door Open RAP ....................09-100 Toner Low RAP....................2-29 01-110 Fuser Door Open RAP..................09-350 Print Cartridge Warning RAP ................2-29 01-700 Stapler Door Open RAP..................09-450 Replace Drum RAP..................... -
Page 4: Image Quality Raps
3 Image Quality RAPs Image Quality RAPs IQ1 Image Quality Entry RAP ..................IQ2 Blank Copies RAP....................IQ3 Black Copies or Prints RAP..................IQ4 Blurred Image From the Scanner RAP..............IQ5 Vertical Black Lines or Bands RAP ................3-10 IQ6 Vertical White Lines RAP ..................3-10 IQ7 Light Image RAP ...................... - Page 5 4 Repairs and Adjustments REPs 1 - Standby Power REP 14.1 Scanner Assembly ..................4-37 REP 14.2 Scanner Components ..................4-38 REP 1.1 SMPS........................ REP 1.2 HVPS ........................ REPs - 28 External Covers REPs 2 - User Interface REP 28.1 External Covers ....................4-41 REP 28.2 Outbin Assembly.....................
-
Page 6: Parts List
5 Parts List PL 1 - Standby Power PL 11 - Stapler Assembly PL 1.10 HVPS ......................... PL 11.10 Stapler Assembly ..................... 5-33 PL 1.12 SMPS......................... PL 14 - Scanner PL 2 - User Interface PL 14.10 Scanner Assembly ................... 5-34 PL 2.10 User Interface .................... - Page 7 Xerox Phaser 3635MFP sm_08.pdf Xerox Phaser 3635MFP sm_08.pdf Xerox Phaser 3635MFP sm_08.pdf Xerox Phaser 3635MFP sm_08.pdf Xerox Phaser 3635MFP sm_08.pdf Xerox Phaser 3635MFP sm_08.pdf Xerox Phaser 3635MFP sm_08.pdf Xerox Phaser 3635MFP sm_08.pdf Xerox Phaser 3635MFP sm_08.pdf...
