DS-7204HVI-S Series Net DVR
Technical Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the DS-7204HVI-S Series and is the answer not in the manual?

Questions and answers

Summary of Contents for HIKVISION DS-7204HVI-S Series

  • Page 1 DS-7204HVI-S Series Net DVR Technical Manual...
  • Page 2 DS-7204HVI-S/HI-VS Front DS-7204HVI-VS Rear Panel...
  • Page 3: Local Functions

    Features Compression H.264 video compression in real-time (PAL: 25FPS, NTSC: 30FPS). Each channel is independent. One channel audio input and output. Each channel is independent with OggVorbis compression at a bit rate of 16Kbps. Multi-area motion detection. On-screen display (OSD) and changeable OSD & Logo position. Supports both constant bit rate and variable bit rate.
  • Page 4 Several PTZ protocols supported Preset, sequence and cruise Alarms Exception alarm, motion detection alarm, external alarm, etc. Network Supports TCP, UTP, Multicast, DHCP, etc PPPoE for ADSL dialup. Remote parameters setup Remote download and playback the recorded files in DVR. Remote upgrade the DVR firmware Network PTZ control IE to preview and configure DVR.
  • Page 5: Specifications

    Specifications Model Item DS-7204HVI-S Video compression H.264 Preview resolution PAL: 352× 288 ; NTSC: 352× 240 Playback QCIF/CIF resolution Video input Video input BNC (Electrical Level: 1.0Vp-p, resistance: 75 ) interface Composite video 1 channel, BNC (Electrical Level: 1.0Vp-p, resistance: 75 ) output Spot video Output 1 channel, BNC (Electrical Level: 1.0Vp-p, resistance: 75 )
  • Page 6 Power ≤10W (without HDD) consumption Operating -10℃ to +55℃ temperature Relative humidity 10% to 90% Size 315× 230× 45 mm Weight < 8Kg (without HDD) PAL: 176×144(QCIF), 352×288(CIF), 704× 288(2CIF), 528× 384(DCIF), 704× 576(4CIF); NTSC: 176× 120(QCIF), 352×240(CIF), 704×240(2CIF), 528×320(DCIF), 704× 480(4CIF).
