- Page 1 User’s Manual CNPS7XXX Series Intel Socket 1155/1156/775 CPUs AMD Socket FM2/FM1/AM3+/AM3/AM2+/AM2 CPU & APUs To ensure safe and easy installation, please read the following precautions. www.ZALMAN.com Ver.130424...
-
Page 2: Specifications
Check the components list and condition of the product before installation. If any problem is found, contact the retailer to obtain a replacement. Zalman Tech Co., Ltd. is not responsible for any damages due to overclocking. During transportation of the system, the cooler must be removed. - Page 3 3. Components Cooler Clip Support User’s Manual Washers Clip Support Fixing Bolts Nuts Fan Mate 2 Fan Mate 2 Cable Double-Sided Tape Thermal Grease Clip Lever AMD Clip (ZM-STG2M) (CNPS7000) (CNPS7000& CNPS7500) .COM...
-
Page 4: Installation Requirements
4. Installation Requirements 1) Space Requirements The cooler’s installation requires unobstructed space with dimensions of Width, Height, Depth, and the CPU as a central reference point. Please check if components such as ODDs and PSU protrude into the required space. CNPS7000 Series CNPS7500 LED Series 2) Compatible CPUs... -
Page 5: Installation
5. Installation 1) Intel Socket Installation Install the Clip Support to the motherboard Bolt Clip Support Washer Caution Lever Slot Please make note of the Lever Slot’s direction when installing the Clip Support. Clear off any particles or residue from the CPU’s surface then spread a thorough layer of Thermal Grease on the CPU and the base of the cooler. - Page 6 Insert the Clip Lever through the Clip Lever slot. Hook the opposite side of the Clip onto the Lug first. Then use a screwdriver to hook the Clip Lever onto its Lug. 2) AMD Socket Installation Clear off any particles or residue from the CPU’s surface then spread a thorough layer of Thermal Grease on the CPU and the base of the cooler.
- Page 7 Insert the Clip Lever through the Clip Lever slot. Hook the opposite side of the Clip onto the Lug first. Then use a screwdriver to hook the Clip Lever onto its Lug. 6. Fan Mate 2 Installation and Usage 1) Fan Mate 2 Installation Fan Mate 2 can be installed to the Connect Fan Mate 2 between the side of the case using Double-Sided...
- Page 8 2) Fan Mate 2 Operation Fan Speed Control Knob Ajust the Fan Speed Control Knob for RPM control. BIOS Boot Error In case you hear a BIOS error beep, please take the following steps. Rotate the Fan Speed Control Knob clockwise to its maximum setting. Disable CPU Fan Detected in BIOS setting or set the system monitoring program’s CPU Fan RPM to its lowest setting.
