Typical
Connection
Note: 1. The product model shown in this QIG is "Archer C7", as an example.
2. Information for technical support can be found in the last page.
Connect the Hardware
1. Power off the modem, and
remove the backup battery if
any.
2. Connect the modem to the
Internet port on your router
with an Ethernet cable.
INTERNET
Modem
Power Off
LAN
INTERNET
INTERNET
