INSTRUCTION MANUAL
2-Speed Hammer Drill
HP2030
HP2031
002466
DOUBLE INSULATION
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HP2030 and is the answer not in the manual?

Questions and answers

Related Manuals for Makita HP2030

Summary of Contents for Makita HP2030

  • Page 1 INSTRUCTION MANUAL 2-Speed Hammer Drill HP2030 HP2031 002466 DOUBLE INSULATION WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    ENGLISH SPECIFICATIONS Model HP2030 HP2031 Speed High High Concrete 20 mm ----- 20 mm ----- Capacities Steel 8 mm 13 mm 8 mm 13 mm No load speed (min 0 - 2,900 0 - 850 0 - 2,900 0 - 850...
  • Page 3 a cord suitable for outdoor use reduces the risk of 20. Disconnect the plug from the power source electric shock. and/or the battery pack from the power tool If operating a power tool in a damp location is before making any adjustments, changing unavoidable, use a residual current device accessories, or storing power tools.

  • Page 4: Functional Description

    Keep hands away from rotating parts. Reversing switch action Do not leave the tool running. Operate the tool 1. Reversing only when hand-held. switch lever Do not touch the bit or the workpiece immediately after operation; they may be extremely hot and could burn your skin. Some material contains chemicals which may be toxic.
  • Page 5 To remove the bit, hold the ring and turn the sleeve counterclockwise. CAUTION: For Model HP2030 Always turn the action mode changing lever fully to • your desired mode position. If you operate the tool 1. Chuck key with the lever positioned halfway between the mode symbols, the tool may be damaged.
  • Page 6 There is a tremendous force exerted on the tool/bit • NOTE: at the time of hole break through. Hold the tool The depth gauge cannot be used at the position • firmly and exert care when the bit begins to break where the depth gauge strikes against the tool through the workpiece.
  • Page 7 Makita Authorized Service Centers, always using Makita replacement parts. ACCESSORIES CAUTION: These accessories attachments • recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons.
  • Page 8 Makita Corporation Anjo, Aichi, Japan 883988-918...
