Carolift Wheelchair lifts
Loading the Carolift 6900
Place the wheelchair with the front in
the opposite direction compared to the
car. Prepare the wheelchair for loading
by removing /folding down the seat back
if fitted.
Swivel out the hoist using the hand
control. Extend the outer lift arm using
the EXTEND button. Make sure the lift
belt with lifting device is positioned as di-
rectly above the wheelchair's attachment
as possible. To avoid the risk that the
wheelchair starts swinging when lifted.
Lower the lift belt with lifting device,
using the hand control. Hook/tension
the lifting device in the wheelchair's
attachment. Check that the wheelchair is
secured correctly in the hoist.
