maStEr

With the Port 01 FX as the Master, press the <PORT> soft key to change the remaining Ports and
designate the remaining FXs as Slaves. The MATE screen for Port 02 will look like this:
ADV/FX/STACK--------P02
stack
phase
DOWN
ADV/FX/STACK---------P02
stack
phase
DOWN
Note: There are no <OK> or <DONE> commands in the stacking menu. Whichever value—Master or
Slave—shows up on the MATE screen will be assigned to the chosen Port (and FX) upon leaving that
screen. It's important to watch the Port number in the top right corner of each screen to be sure you've
assigned it the desired status.

CLaSSIC SLaVE

ADV/FX/STACK---------P02
stack
phase
DOWN INC DEC
13
Master
INC DEC PORT
Master
INC DEC PORT
Classic Slave
PORT
• The MATE is now ready to program the FX plugged
into Port 02 of the HUB.
• Master is the factory default value for each grid-inter-
active FX.
• Pressing the <INC> soft key will keep the MATE's
attention on Port 02, but will change the stack phase
to Classic Slave screen. Port 02 will then be assigned
as a Classic slave. You can change the stacking phase
by pressing the <INC> or <DEC> soft keys and
change to a different port by continuously pushing
the <PORT> soft key.
• PO2 is now assigned as a Classic Slave.
