AUREL XTR-8LR10 User Manual

Half duplex transceiver
Hide thumbs Also See for XTR-8LR10:

Advertisement

Quick Links

Download this manual
---------------------------------------------------------------------------------------------------------------------------------------------------
XTR-8LR10
is an half duplex transceiver for long range radio communication based on a patented
, providing
modulation technique
+14dBm power.
Compared to standard modulation techniques
long distances by using low power in transmission and low consumption, inexpensive power supply circuits and low
cost batteries.
Transceiver works in
869,70÷870,00MHz (25mW, ver. 8LR10)
XTR-8LR10
is a radio-modem with UART input interface
handle addressing schemes for point-to-multipoint star networks. Main radio parameters might be set up smoothly via
command mode procedure
in the field.
Operating voltage is 3,3V, current consumption is 17 mA in reception and 30 mA in transmission (14 dBm ERP).
Module is available in SMD version, for surface and vertical assembling, 18 pin whose size is
Tape & reel package for automatic assembling for
Main features
Direct transmission or radiomodem mode
RS-232 interface with store and foreward mode
No encoding or preamble requested
AT command mode for set up of parameters
HyperTerminal* compatible
Channels: 3 max
Small form factor (33.5x15.4x2.4 mm)
UART data rate: 9600, 19200, 115200 bps
Emitted power: max 20 mW
Sensitivity from -118 to-144 dBm
Operating voltage: 3,3V
Standard distance: 8000 m
Le caratteristiche tecniche possono subire variazioni senza preavviso. AUR°EL S.p.A. non si assume la responsabilità di danni causati dall'uso improprio del dispositivo.
-------------------------------------------------------------------------------------------------------------------------------------------------------------------
AUR° EL S.p.A. Via Foro dei Tigli, 4 - 47015 Modigliana (FC) – ITALY
Tel.: +39.0546.941124 Fax: +39.0546.941660
http://www.aurelwireless.com
high interference immunity
, XTR-8LR10
868÷868,6MHz (25mW ver. 8LR10), 869,4÷869,65MHz (25mW, ver. 8LR10),
European band with possibility to set the channel width.
, offering the user flexibility and multiple solutions to the many problems involved
- email:
rfcomm@aurel.it
,
high sensitivity and very low power consumption with
improves up to 20 dB the receiver sensitivity
,
working on data packages (max. size 255 bytes). It can
pick and place
.
Applications
XTR-8LR10
33.5 X 15.4 X 2.4 mm.
Agriculture Systems
Irrigation control
Photovoltaic monitor
Industrial sensors
SCADA
Tele-Alarms
Instruments Monitoring
AMR
Rev 1.0 09/07/2015
User manual
"LoRa SSM"
,
allowing
Pag 1 di 21
