XTR-915 mod. Transceiver
Miniaturized data transceiver module, 100 Kbps maximum speed, 914,50 MHz operating frequency.
Especially suitable for use in North America Countries where the band assigned to short range devices (SRD)
is 902–928 MHz.

Pin-Out and block diagram

1 GND
RX-TX
switch
2 Antenna
Ampl.
3 GND
4 NC
5 NC
Preamp
O.L.
6 NC
PLL
Controlled
7 NC
BPF
8 NC
Saw Filter
9 GND
Mixer

Connections

Pin 1-3
RF GND
Pin 2
Antenna
Pin 9-10-18
GND
Pin 11
CD
Pin 12
RXD
Pin 13
AF
Pin 14
TXD
Pin 15
TX ENABLE
Pin 16
RX ENABLE
Pin 17
Vcc
The technical tests and reports have been carried out and obtained by the laboratories of:
Messrs PRIMA RICERCA & SVILUPPO – via Campagna, 58 – 22020 Gaggino Faloppio (CO).
Technical features are subject to change without notice. AUR°EL S.p.A does not assume responsibilities for any damage caused by the device's misuse.
AUREL S.p.A. Via Foro dei Tigli, 4 - 47015 Modigliana (FC) – ITALY
Tel.: +390546941124 – Fax: +390546941660
http://www.aurel.it
- email:
aurel@aurel.it
Vcc Tx-Rx
PLL Controlled
Power Supply
Oscillator
RX-TX
RX-TX
Enable switch
Tx Enable
Rx Enable
50 KHz
Buffer
Slicer
IF limiter
PLL
Demod.
RF circuit GND
50Ω impedance antenna connection
Connections to GND. Internally connected also to the module's
shield.
Carrier Detect. With enabled receiver, a low signal (voltage level 0V),
indicates that the receiver detects an RF carrier. The line activates
with an RF signal of minimum –96dBm applied to pin 2 (antenna).
High impedance output available only for loads under CMOS logic.
Receiver data output. Load impedance allowed: over 100KΩ without
any capacitor in parallel.
Filtered and buffered output of the FM detector. Load impedance
allowed: over 2KΩ and less than 100pF.
Input to transmitter; accepts serial data in TTL logic (0 ÷ 5V) with a
10KΩ load impedance.
Active when low, (voltage level 0V), enables the transmitter circuit.
Max 1mA
Active when low, (voltage level 0V), enables the receiver circuit.
Max. 0,5 mA
Connection to the positive pole of the supply voltage (+5V ± 10%)
Mechanical dimensions
18 GND
Aurel
17 Vcc
logo
16 Rx EN
15 Tx EN
Product
14 Mod. in
name
13 Analog out
12 Data out
CE
11 C.D.
Mark
10 GND
Lot
week/year
XTR-915

Instruction Manual

XTR-915
Rev. A, January 11th 2002
