- Page 1 73-1747-250 3/06 Lionel Lionel Pennsylvania Ballast Train Pennsylvania Ballast Train Owner’s Manual Owner’s Manual featuring SYSTEM...
- Page 2 • Directional lighting including markers • Front and rear ElectroCouplers • Illuminated front cab interior • Minimum Curve: O-31 minimum, O-36 recommended The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel ®...
-
Page 3: Table Of Contents
Reprogramming your locomotives to restore features Maintaining and servicing your locomotive Lubricating your locomotive Servicing your locomotive’s lamps Servicing the traction tires Maintaining your locomotives’ pantograph antennas Operating the ballast dump car Replacing the work caboose lamp Limited Warranty/Lionel Service... -
Page 4: Quick Start
Quick Start Conventional transformer operations 1. Place your train set on Lionel or Lionel-compatible O-31 minimum or larger track. O-36 track is recommended. 2. Power your train set at 8-19 volts with your alternating current (AC) transformer. Do not power your locomotive with a direct-current (DC) transformer. Damage to Note! sensitive electronic components may occur. -
Page 5: Conventional Transformer Operations
Conventional operations our train set is capable of operating in the conventional environment with nothing more than a standard Lionel alternating-current (AC) transformer. In the conventional environment, your locomotive cycles through a repeating pattern of operations: forward, neutral, reverse, neutral, and so on. To advance to the next operation, press the DIRECTION button on your transformer. -
Page 6: Operating Your Train Set In The Conventional Environment
Conventional transformer operations Operating your train set in the conventional environment 1. Place your train set on Lionel or Lionel-compatible O-31 minimum or larger track. O-36 track is recommended. 2. Power your train set at 8-19 volts with your alternating current (AC) transformer. -
Page 7: Locking Your Locomotive Into A Single Direction
Conventional transformer operations Locking your locomotive into a single direction hen the Command reverse unit switch is in the RUN position, your locomotive sequences through a repeating pattern of operations: forward, neutral, reverse, neutral, and so on. To “lock” your locomotive into a single direction (for example, to operate in forward only), you can deactivate the Command reverse unit’s sequencing function. -
Page 8: Uncoupling Your Locomotive In The Conventional Environment
ElectroCoupler is closed. Keep in mind that you may still make use of Lionel Remote-Control Track sections (6-65530 for O gauge; 6-12746 and 6-65149 for O-27 gauge; and 6-12020 and 6-12054 for FasTrack layouts) with the magnetic couplers on the rolling stock. -
Page 9: Odyssey System Operations
Odyssey System operations The Odyssey System he Odyssey System is “cruise control” for your powered locomotive. Once the speed is set (see below), your locomotive will maintain a constant speed, no matter what loads the locomotive pulls or what grades you have on your layout. This digitally-controlled system also allows for extremely slow movement that will amaze any “scale”... -
Page 10: Odyssey System Command Control Operation
Odyssey System operations Odyssey System Command Control operation hen the Odyssey System is activated, changes in the speed of the locomotive will correspond to each signal from the Command Base. For example, when you address the locomotive and slowly turn the throttle knob, the first flash of the light on the Command Base corresponds to the first speed step, which is the slowest speed of the locomotive. -
Page 11: Trainmaster Command Control Operations
TrainMaster Command Control operations TrainMaster Command Control operations rainMaster Command Control is the advanced model railroad control system from Lionel. To operate your locomotive set in the Command Control environment, you need a Command Base (available separately, 6-12911) and a CAB-1 Remote Controller (available separately, 6-12868). -
Page 12: Cab-1 Remote Controller Commands
TrainMaster Command Control operations CAB-1 Remote Controller commands he CAB-1 Remote Controller commands are detailed below. Releases the front coupler. Releases the rear coupler. Activates the numeric keypad. Toggles the headlights on and off. Accelerates the locomotive with a clockwise rotation. -
Page 13: Tuning Your Locomotive's Performance
TrainMaster Command Control operations Tuning your locomotive set’s performance rainMaster Command Control allows you to fine-tune the performance of your locomotive set. Use your CAB-1 Remote Controller to make these adjustments. Note! These settings will be lost if you assign a new ID#. MOMENTUM The TrainMaster Command Control momentum feature simulates the labored performance of a locomotive pulling a light, moderate, or heavy load. -
Page 14: Assigning Your Locomotive A New Id
TrainMaster Command Control operations Assigning your locomotive a new ID# s your roster of TrainMaster Command Control-equipped locomotives grows, you will want to give each unit a unique ID#. The locomotive will respond to commands associated with its ID# while all other units will disregard these commands. To restore your locomotive’s functions, see page 15. -
Page 15: Reprogramming Your Locomotives To Restore Features
TrainMaster Command Control operations Reprogramming your locomotive to restore features f your locomotive is unresponsive to your commands in the TrainMaster Command Control environment, we recommend that you follow this procedure to reset your locomotive. 1. Slide the Command reverse unit switch to the PROG position. 2. -
Page 16: Maintaining And Servicing Your Locomotive
Maintaining and servicing your locomotive Lubricating your locomotive elp your Lionel locomotive lead a long and productive life on your railroad by maintaining it properly. To keep your locomotive lubricated, we recommend that you purchase a Lionel Lubrication and Maintenance Kit (6-62927), available from your authorized Lionel dealer. -
Page 17: Servicing Your Locomotive's Lamps
Removing the body screws as shown on page 16 will allow access to the inside of the cab and the expired lamps. However, due to the close fit of many components and the inter-connected wiring, we recommend that you take your locomotive to your authorized Lionel Service Center for any required lamp replacement. -
Page 18: Servicing The Traction Tires
Maintaining and servicing your locomotive Servicing the traction tires our locomotive is packed with traction tires. Due to the short wheel base of this scale model, some track and switch layouts may cause the locomotive to lose power when the traction tires are installed and the locomotive operates at slow speeds. -
Page 19: Operating The Ballast Dump Car
Figure4. Positioning the car Replacing the work caboose lamp our work caboose is illuminated by one lamp (Lionel part no. 600-0161-300), During the course of normal operations, you may find that this lamp requires replacement. Replacement lamps are available at your authorized Lionel Service Center or from Lionel Service... -
Page 20: Limited Warranty/Lionel Service
Lionel L.L.C. or an authorized Lionel L.L.C. Service Center, together with proof of original purchase will, at the option of Lionel L.L.C., be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a replacement is not available, a refund of the original purchase price will be granted.
