Extruder Control - Bfb 3D Touch Set Up And Operation Manual

Use the Y buttons to change the mapping.
Press X+ to save, or Escape to quit without saving.
The user is notified prior to printing that extruder remapping is enabled as the remapping can result in unexpected behaviour if the user is
unaware of the active remapping function.
The remapping configuration settings are not stored persistently as this is deemed undesirable. When the printer power is turned on the
remapping reverts to 1:1 direct mapping. (The aforementioned pre-print remapping prompt is not shown when the mapping is 1:1)
Please ensure the Gcode file allows enough room between the left of the print and the printer framework. I.e. attempting to print the test raft
Gcode file with a double extruder RapMan will cause the extruder carriage to hit the framework when it attempts to position physical
extruder 2 into the far left corners of the print bed as the raft Gcode file instructs.
Manual move
See Manual move .

Extruder control

See Extruder control .
Home tool head
Push 'Enter' to move all axes to their home position.
Make sure the bed is in position before homing the tool head. The bed contains a sensor necessary for homing. Without the
sensor, the machine will drive the bed frame into the waste disposal stand-offs. Repeated collisions will damage the machine.
Extruder offsets
Extruder offsets defines the position of extruders 2 and 3 in the 3D Touch, relative to extruder 1. These values are determined in the factory, and
should only be changed if:
a new extruder/hot-end has been installed, or
multi-material prints are noticeably out of registration.
Settings here should only be changed during the calibration procedure.
3D Touch
Click here to go to the calibration manual.
Page 55
