Bfb 3D Touch Set Up And Operation Manual page 40

Print the raft check file
If this is your first print, you can print the raft check file to gain familiarity with the print.
If you do not have these files you can download them by clicking on the icon on the left. After downloading:
Make sure materials are loaded as per "Load the filament".
Follow the section k. How to start a print
Material type in Extruder 1
ABS
PLA
Examine each raft pad in the check file, as detailed in the following section.
Remove the raft print when complete.
Examine the raft check file
The print files required are already included on the USB memory stick supplied in your toolkit.
The printer can only see uncompressed files at the root of the USB stick i.e. do not put them inside a folder.
to print the appropriate raft check file for the material loaded in Extruder 1 (see table below).
File to print
RaftABS_CheckFile
RaftPLA_CheckFile
3D Touch
Unpack the files to the root of your USB stick.
Page 40
