Remote System Configuration; Tools; Remote Management - Provision ISR AHD Series User Manual

②
Select backup files and click "Browse" button to set the save path. Then click "Backup"
button to start backup. The backup files will be saved on user's PC.

8.6 Remote System Configuration

You can do remote setup of the device which includes functions like basic configuration, live
configuration, record configuration, schedule configuration, alarm configuration, network
configuration, PTZ configuration and user configuration. You should select an option from the
menu list on the left and then set up the relative parameters. Only one user can do configuration
setup at a given point of time. Click Config tab to go to the below interface
The sub menu list and the options in every menu are similar to that of the DVR. Please refer to
Chapter 4 Main Menu Setup Guide for more details.

8.7 Tools

Click on the tool's tab to access the Disk Management tool. The user can view the status of the
hard drive(s), view/change the read write properties and format the hard drive(s).

8.8 Remote Management

The Info interface provides a web based interface to access the general information pertaining
to the DVR's settings. The interface includes five submenus: System, Event, Log, Network and
Online users.
Note: There may be subtle differences with respect to functions of remote surveillance
between through IE and through Apple PC. Here we only take IE remote access for
example.
AHD DVR User Manual
Fig 7-9 Remote Menu Setup
57
