Summary of Contents for BenQ i500

  • Page 1 Digital Projector Personal Smart Series User Manual...
  • Page 2: Copyright And Disclaimer

    BenQ warrants this product against any defects in material and workmanship, under normal usage and storage. Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ’s only obligation and your exclusive remedy shall be replacement of any defective parts (labor included).
  • Page 3: Statement Regarding Hyperlinks And Third-Party Websites

    Any third party content or service preinstalled in this product is provided "as is". BenQ does not, by expression or by implication, make any warrant to the content or to the services provided by third parties. BenQ does not warrant or guarantee that the content or services provided by third parties are accurate, effective, most up-to-date, legal, or complete.
  • Page 4: Table Of Contents

    Table of contents Copyright and disclaimer ...................................2 Copyright ........................................... 2 Disclaimer ..........................................2 Warranty............................................ 2 Statement regarding hyperlinks and third-party websites ..........................3 Package contents .......................................10 Standard accessories ......................................10 Introduction ........................................11 Projector features ........................................11 Front and upper side view ............................................ 13 Controls and functions ......................................17 Control panel ................................................
  • Page 5 Ending a Bluetooth connection ..........................................42 Deactivating the Bluetooth speaker ........................................42 BenQ Launcher ..................................... 43 Operating under the BenQ Launcher mode .............................. 43 Accessing the BenQ Launcher main page .....................................43 Using the BenQ Launcher applications ......................................44 Accessing the BenQ Launcher menus......................................44 Using the BenQ Launcher Settings page......................................47...
  • Page 6 Extending lamp life ..............................................61 Troubleshooting ......................................65 Specifications .......................................67 Projector specifications............................................67 3/30/16...
  • Page 7: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. 1.
  • Page 8 If the projector does become wet, disconnect it from the power point and call BenQ to have the projector repaired. 5. Do not block the vents holes while the projector is on (even in standby mode).
  • Page 9: Moisture Condensation

    Moisture condensation 12. This projector is capable of displaying inverted images for ceiling installation. Never operate the projector immediately after moving it from a cold location to a hot location. When the projector is exposed to such a change in temperature, moisture may condense on the crucial internal parts.
  • Page 10: Package Contents

    Carefully unpack and verify that you have the items below. Some of the items may not be available depending on your region of purchase. Please check with your place of purchase. Standard accessories Projector Adapter Remote Control with Battery i500 Ultra Lite LED Smart Projector Quick Start Guide HDMI Cable Warranty Card Quick Start Guide •...
  • Page 11: Introduction

    (both Mac and PC) and HDMI source. • Convenient Android-based BenQ Launcher The projector operates using the Android-based BenQ Launcher which complemented by a WLAN connection allows you to project/broadcast media via embedded or downloaded streaming apps. • Advanced LED light source The projector features a long lasting LED lightbulb that provides a longer lifespan than traditional bulbs.
  • Page 12 • Vivid color reproduction The projector features the capability of representing 1.07 billion colors. • Auto Keystone The projector offers an automatic keystone adjustment function which adjusts the projected image accordingly. • 3D function To enjoy the 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images through HDMI. •...
  • Page 13: Front And Upper Side View

    Projector exterior view Front and upper side view 1. Bluetooth button (See Control panel on page 17 for details.) 2. LED indicator light 3. Lens cap holder This magnetic component holds the lens cap while the projector is in use. 4.
  • Page 14: Rear And Upper Side View

    Rear and upper side view Connection on page 26 for connection details. 12. Microphone in jack 13. Audio input jack 14. Audio output jack 15. HDMI port This port can also be used for charging the connected HDMI compatible smart device as long as the power is fed to the projector.
  • Page 15 20. Speaker Grill Inside the speaker grill is the two 5-watt chamber speakers. 21. Vent (cool air intake) 12 13 14 15 16 17 18 19 The image above features the rear view with the IO port cover removed. For ease of use when removing the magnetic IO port you can place it on the speaker grill as a temporary holding place.
  • Page 16 Rear and left side view 22. Rear IR sensor 23. Rear power jack Please only use the supplied power adapter to avoid possible dangers such as electric shock and fire. The image above features the rear view with the IO port cover removed.
  • Page 17: Controls And Functions

    Controls and functions Control panel 1. Focus ring Adjusts the focus of the projected image. 2. TEMPerature warning light Lights up red if the projector's temperature becomes too high. See Indicators on page 63 for more details. POWER Toggles the projector between standby mode and on. The icon on the Power button also acts as the power indicator light.
  • Page 18: Remote Control

    • When the OSD menu is off and you are under the BenQ Launcher mode, these keys are used as directional arrows to select the desired menu items and to make adjustments. 5. OK •...
  • Page 19 HOME Press this key to enter the home menu of the BenQ Launcher mode. This key is only available when the projector is under BenQ Launcher mode. 8. BLANK Switches the projected image to either a blank screen or switches the blank screen back to the original projected image.
  • Page 20: Replacing The Remote Control Battery

    Activating the remote control batteries 1. Pull out the plastic battery shield between the battery contacts on your remote control and the battery, as illustrated. • Avoid leaving the remote control and battery in an excessive heat or humid environment like the kitchen, bathroom, sauna, sunroom or in a closed car.
  • Page 21 • Operating the projector from the front • Operating the projector from the rear...
  • Page 22: Installation

    Installation Choosing a location Before choosing an installation location for your projector, take the following factors into consideration: • Size and position of your screen • Electrical outlet location • Location and distance between the projector and the rest of your equipment •...
  • Page 23 3. Front Ceiling: Select this location with the projector elevated near the ceiling in front of the screen. Turn on the projector and make the following settings: MENU > Settings > Projector Position > Front Ceiling The projector does not feature ceiling mount components/equipment so when choosing to use a front ceiling location you must place it on an elevated location of your choice.
  • Page 24: Projection Dimensions

    Obtaining a preferred projected image size The projected image size is determined by the distance from the projector lens to the screen, and the video format. Projection dimensions Use the illustration and tables below to help you determine the projection distance. Screen Size Screen Center of lens...
  • Page 25 Screen size Projector distance (mm) Diagonal H (mm) W (mm) Average Max. distance Inch 3556 1885 3015 1809 4064 2154 3446 1034 2068 4572 2423 3877 1163 2326 5080 2692 4308 1292 2585 All measurements are approximate and may vary from the actual sizes. If you want a permanent installation of the projector, we recommend that you use the actual projector to physically test the projection size, distance, and the projector's optical characteristics prior to the installation.
  • Page 26 Connection When connecting a signal source to the projector, be sure to: 1. Turn all equipment off before making any connections. 2. Use the correct signal cables for each source. 3. Make sure the cables are firmly inserted. 4. Place the projector within range of the wireless AP you plan to connect it to. A/V Device Notebook or Desktop Computer...
  • Page 27: Connecting With Video Equipment

    • In the connection illustrations shown above, some cables may not be included with the projector (see Projector exterior view on page 13). They are commercially available from electronics stores. • The illustrations above are for reference only. The rear connecting jacks available on the projector vary with each projector model. 1.
  • Page 28: Connecting Hdmi Devices

    Connecting HDMI devices HDMI (High-Definition Multimedia Interface) supports uncompressed video data transmission between compatible devices like DTV tuners, DVD players, Blu-ray players and displays over a single cable. You should use an HDMI cable when making a connection between the projector and HDMI devices.
  • Page 29: Connecting With A Computer

    Connecting with a computer Using a VGA cable Connect the projector to a computer with a VGA cable, and a separate audio cable (only if you want to broadcast audio from the computer). Notebook or Desktop Computer Audio Cable VGA Cable Using an HDMI cable Connect the projector to a computer with an HDMI cable.
  • Page 30: Connecting A Usb Flash Drive

    • Some computers feature HDMI ports that do not transmit audio, in such cases a separate audio cable must be connected to the projector. • Many laptops do not turn on their external video ports when connected to a projector. Usually a key combination like Fn + F3 or CRT/LCD key turns the external display on/off.
  • Page 31: Operations

    2. Connect any video equipment to the respective port on the rear of the projector. If you do not want to project video via such equipment but want to access the BenQ Launcher, you do not need to connect any video equipment.
  • Page 32 • Use OK to confirm the selected menu item. The Setup Wizard screenshots below are for reference only and may differ from the actual design. Step 1: Specify Projector Position. For more information about projector position, see Choosing a location on page...
  • Page 33 Step 2: Specify OSD Language. Available languages may vary by the product supplied for your region and may be updated without prior notice. Step 3: Specify Auto Keystone.
  • Page 34 Step 4: Specify Auto Source. Step 5: Specify the Network Settings (either connecting to a WLAN AP or using LAN connection). You may need to enter a password if you choose to connect to a WLAN AP.
  • Page 35 6. The projector starts to search for available input signals. The current input signal being scanned displays on the screen. If the projector is unable to detect a valid signal, the projector will automatically open the BenQ Launcher. You may press on your remote control to select your desired input signal.
  • Page 36: Shutting Down The Projector

    Shutting down the projector 1. Press on the projector or on your remote control. The projector displays a shutdown confirmation message. 2. Press a second time. The POWER indicator light flashes orange and the fans run for about two minutes to cool the lamp. The projector does not respond to any commands during the cooling process.
  • Page 37: Using The Security Bar

    Securing the projector Using the security bar The projector has to be installed in a safe place to prevent theft. It has a security lock bar located at the bottom of the projector which you can use to secure the projector via a variety of purchasable self-locking cables. Security Bar Selecting an input source The projector can be connected to multiple equipment at the same time.
  • Page 38 To select the video source: 1. Press on your remote control to display the source selection bar. 2. Press until your desired signal is selected and press OK. Once detected, the selected source information displays on the screen for seconds. If there are multiple pieces of equipment connected to the projector, repeat steps 1-2 to search for another signal.
  • Page 39: Adjusting The Projection Angle

    Adjusting the projected image Adjusting the projection angle The projector is equipped with a quick-release adjuster foot and a rear adjuster foot. These adjusters change the image height and projection angle. To adjust the projection angle: • Press the quick-release button and lift the front of the projector. Once the image is positioned as desired, release the quick-release button to lock the foot in position.
  • Page 40: Fine-Tuning The Image Clarity

    Fine-tuning the image clarity To sharpen the picture, rotate the focus ring on the projector. Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen.
  • Page 41: The Bluetooth Speaker

    • To correct keystoning at the top of the image, use on your remote control. • To correct keystoning at the bottom of the image, use on your remote control. • When done, press BACK to save your changes and exit. You may only make these adjustments if Auto Keystone is disabled in the Setting menu, see Auto Keystone on page 58 for details.
  • Page 42: Ending A Bluetooth Connection

    1. Press the Bluetooth button on the top of the projector. If your projector is on when you press the Bluetooth button, a prompt will display asking you to confirm whether or not you want to activate the Bluetooth speaker and put the projector on standby, confirm this selection. After confirming the selection your projector will automatically be placed on standby.
  • Page 43: Benq Launcher

    Accessing the BenQ Launcher main page When the projector is not projecting an image from a connected source be in BenQ Launcher mode by default. If the projector is projecting a source you can return to BenQ Launcher mode by pressing on your remote control.
  • Page 44: Using The Benq Launcher Applications

    Featured Apps section - A rotating selection of specially featured apps BenQ selects for users of the projector. • System section - A group of apps that help you configure the BenQ Launcher, and access more apps from the BenQ Launcher. They include the following menus: •...
  • Page 45 Notification - Select this menu to view any app or system related messages for the projector. • Clean Tool - Select this function to clear the memory cache for the projector, which speeds up the performance of the BenQ Launcher.
  • Page 46 Press twice on your remote control from the main menu to view a list of recently opened apps. Actual screen may vary based on your BenQ Launcher firmware version. To re-open an app from the History menu use on your remote control to navigate to the app you want to re-open, and then press OK to re-open that app.
  • Page 47: Using The Benq Launcher Settings Page

    Using the BenQ Launcher Settings page The Settings page for the BenQ Launcher offers a set of configurations that allow you to make adjustments to the BenQ Launcher environment. Actual screen may vary based on your BenQ Launcher firmware version.
  • Page 48 Submenu Functions and Descriptions Allows you show the connected smart device’s screen from the projector. To perform the screen mirroring function, follow the Mirror instructions in the connected device’s user manual. Allows you to: • Change the language for the projector. •...
  • Page 49: Using The All Apps Page

    Changing network settings The BenQ Launcher allows you to change your wireless connection settings via the WLAN Settings menu within the Internet menu, which can be accessed by selecting the Settings menu from the System section in the main menu.
  • Page 50: Inputting Text

    Inputting text Various menus within the BenQ Launcher may require that you input text. To input text in a text field: 1. Select the text field where you want to input text. 2. Press OK on your remote control, a full alphanumeric keyboard will appear on screen.
  • Page 51: Navigating The Osd Menus

    Navigating the OSD menus About the OSD menus To let you make various adjustments or settings on the projector and the projected image, the projector provides a multilingual On-Screen Display (OSD) menus, which contains primary menu functions. (See Using the OSD menu on page To access the OSD menu, press MENU on your remote control.
  • Page 52 The following is the OSD menu: Use the arrow keys ( ) on your remote control to move through the menu items, and use OK to confirm the selected menu item.
  • Page 53: Using The Osd Menu

    The following is the Settings menu of the OSD menu: When selecting items within the Setting menu press OK, and then ( /) to toggle through the options. Press when you want to confirm your selection and return to navigating the Settings menu. Using the OSD menu The OSD menu provides primary menu functions.
  • Page 54 Menu Submenus and descriptions Selects a preset picture mode to suit your operating environment and input signal picture type. The preset picture modes are described as below: Maximizes the brightness of the projected image. This mode is suitable for environments where extra-high Bright brightness is required, such as using the projector in well lit rooms.
  • Page 55 Menu Submenus and descriptions The options available for color temperature* settings vary according to the connected input signal. There are many different shades that are considered to be “white” for various purposes. One of the common methods of representing white color is known as the “color temperature”...
  • Page 56 Menu Submenus and descriptions The native display resolution of this projector is in a 16:10 aspect ration. However you may use this function to display projected pictures in a different aspect ratio In the following illustrations, the black portions are inactive areas and the white portions are active areas. •...
  • Page 57 (with 3D game discs), 3D Blu-ray players (with 3D Blu-ray discs), 3D TV (with 3D channel), and so on. After you have connected the 3D video devices to the projector, wear the BenQ 3D glasses and make sure the power is on to view 3D contents.
  • Page 58 Menu Submenus and descriptions Projector The projector can be installed on in a high location or behind a screen. See Choosing a location on page 22 Position for details. Sets whether the projector searches automatically for input sources. Select On to enable the projector to Auto Source scan for input sources until it acquires a signal.
  • Page 59 Menu Submenus and descriptions Displays the following information about your projector. • Source: Displays the current signal source. • Picture Mode: Displays the current Picture Mode. • Resolution: Displays the native resolution of the input source. Information • Color System: Displays input system format. •...
  • Page 60: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you have to do on a regular basis is keep the lens clean. Never remove any parts of the projector. Contact your dealer or local customer service center if the projector fails to operate as expected. Cleaning the lens Clean the lens whenever you notice dirt or dust on the surface.
  • Page 61: Transporting The Projector

    Storing the projector To store the projector for an extended time: • Make sure the temperature and humidity of the storage area are within the recommended range for the projector. Refer to Specifications or consult your dealer about the range. •...
  • Page 62 Setting LED Mode Setting the projector in Economic mode extends the lamp life. LED mode Description Normal 100% lamp brightness Economic mode dims the projector’s LED lamp which will lower power consumption, extend the LED lamp Economic life and reduce the projector’s noise level. The reduced light output will result in darker projected pictures. If you set your projector to Economic mode choose Normal to return to the default normal mode.
  • Page 63 Indicators There are two indicators which show the status of the projector and the Bluetooth speaker. Check the following information about the indicator lights. If there is anything wrong, turn the projector off and contact your dealer. • When the projector is in a normal state TEMP Status &...
  • Page 64 • When the projector is undergoing system updates or in an abnormal state TEMP Status & description Red Flashing Red Flashing Red Flashing Projector is downloading a firmware update Firmware is finished, once the indicators turn off the projector has Green returned to a normal state Green...
  • Page 65: Troubleshooting

    Troubleshooting Problem Cause Remedy Plug the power cable into the AC inlet on the rear of the projector, and plug the power cable into to the There is no power from the power cable. power outlet. If the power outlet has a switch, make The projector does not turn on.
  • Page 66 Problem Cause Remedy The 3D glasses are out of battery. Recharge the 3D glasses. The settings in the 3D menu are not set Correctly set the settings in the 3D menu. correctly. 3D content does not display correctly Your Blu-ray Disc is not in 3D format. Use a 3D Blu-ray Disc and try again.
  • Page 67: Specifications

    Specifications Projector specifications All specifications are subject to change without notice. Optical Resolution 1280 (H) x 800 (V) Display system Mstar ARM A7 Quad-Core CPU Lens F/Number F = 1.6, f = 6.154 mm Lamp Type OSRAM PIW LED Lamp Life (Normal/Economic) 20,000/30,000 hours Lamp life results will vary depending on environmental conditions and usage.
  • Page 68 Audio Supported Audio (HDMI Mode) • Supports LPCM, two audio channels • Supported audio sampling rates: 32kHz, 44.1kHz, and 48kHz • Supported audio bit rates: 16 bits, 20 bits, and 24 bits Supported Audio (DVI/PC Mode) Analog audio is supported through the PC audio input port Electrical Power supply AC100–240V, 3.5 A, 50-60 Hz (Automatic)
  • Page 69: Input Terminals

    USB port 2.0 Type-A x 1 USB port 3.0 Type A x 1 The USB ports only output power, which allows you to charge attached USB-enabled devices (i.e. a smartphone, tablet, etc.). Control IR receiver x 2 Input terminals Computer input D-Sub 15-pin (female) x 1 Video signal input SD/HDTV signal input...
  • Page 70 Environmental Requirements Operating temperature 0°C–40°C at sea level Operating relative humidity 10%–90% (without condensation) Operating altitude 0–1499 m at 0°C–35°C...
  • Page 71 Dimensions (with adjustment feet not extended) 215.63 mm x 201.7 mm x 93.16 mm (W x D x H) 215.8 127.6...
  • Page 72: Timing Chart

    Timing chart Supported timing for video input Timing Resolution H. Frequency (KHz) V. Frequency (KHz) Dot Clock Frequency (MHz) 480i**** 720 (1440) x 480 15.73 59.95 480p**** 720 x 480 31.47 59.94 576i 720 (1440) x 576 15.63 576p 720 x 576 31.25 720/50p** 1280 x 720...
  • Page 73 Supported timing for PC input Timing Resolution H. Frequency (KHz) V. Frequency (KHz) Dot Clock Frequency (MHz) VGA_60 59.940 31.469 25.175 VGA_72 72.809 37.861 31.500 640 x 480 VGA_75 75.000 37.500 31.500 VGA_85 85.008 43.269 36.000 SVGA_60 60.317 37.879 40.000 SVGA_72 72.188 48.077...
  • Page 74 Timing Resolution H. Frequency (KHz) V. Frequency (KHz) Dot Clock Frequency (MHz) SXGA_60 60.020 63.981 108.000 1280 x 1024 SXGA_75 75.025 79.976 135.000 1360 x 768 1360 x 768_60 60.015 47.712 85.500 1440 x 900 WXGA+_60 59.887 55.935 106.500 1400 x 1050 SXGA+_60 59.978 65.317...
  • Page 75: Supported File Formats

    Supported file formats File type File extension Description Adobe PDF 1.0 - 1.4 (.pdf) MS PowerPoint 97 - 2010 (.ppt, .pptx) Documents MS Excel 95 - 2010, Office XP (.xls, .xlsx) MS Word 95 - 2010, Office XP (.doc, .docx) Photos JPG (.jpg, .jpeg), BMP (.bmp) Music...
