- Page 1 PE8720 Digital Projector Ceiling Mounting Guide Welcome...
-
Page 2: Table Of Contents
Do not install the projector in a location that is subject to high levels of dust or humidity. Do not install the projector in a location that is exposed to direct sunlight or in a location that is subject to extreme fluctuations in temperature (such as near an air conditioner). -
Page 3: Names Of Parts
L-ADJUST BOLTS x 2 TUBE BOLTS x 3 M3 SCREWS x 2 ADJUSTMENT ASSEMBLY M3 SCREWS x 4 NUTS x 4 PROJECTOR ADAPTER PIPE M3 SCREWS x 8 SQUARE TUBE M6 SCREWS x 4 ADJUSTMENT ASSEMBLY BOLTS x 7 (TUBE BOLTS x 2, L – ADJUST... -
Page 4: Projector Installation And Throw Distance Chart
180 / 457 435 / 1104 There is 3% ~ 5% tolerance among these numbers due to optical component limits. * 1 m = 3.28 feet, 1 feet = 0.305 m 4 Projector Installation and Throw Distance Chart Floor Installation Diagonal Screen... -
Page 5: Installation Procedure
Insert the U-PLATE into the CEILING ADAPTER, and tighten two M4 SCREWS (from the bottom) STEP A into the screw holes. Then attach the top part to the ceiling. U-PLATE M4 SCREWS Ceiling mount screws (not included) Ceiling Mount Device CEILING ADAPTER Installing a Projector with the Ceiling Bracket 5... - Page 6 Install the PIPE and the TUBE with 2 sets of BOLTS & NUTS (L-ADJUST BOLT). STEP D Install the base-assembly. STEP D1 Combine the SQUARE TUBE and the PIPE with 2 BOLTS. 6 Installing a Projector with the Ceiling Bracket TUBE BOLTS x 2 TUBE NUTS x 2 L-ADJUST BOLTS x2 PIPE...
- Page 7 STEP E Assemble the PROJECTOR ADAPTER and PROJECTOR with 4 M6 SCREWS. M6 SCREW STEP F Slide the projector with adapter into the ceiling assembly and fix the projector with 4 M3 SCREWS. Ceiling mount bracket BASE-ASSEMBLY M3 SCREW Installation finished.
-
Page 8: Height Adjustment
Adjusting the Ceiling Bracket Height Adjustment Make sure to remove the projector first. Loosen the nuts securing to the two L-ADJUST BOLTS. Remove the L-ADJUST BOLTS from the PIPE. Adjust to the correct position for the height of the screen. The height can be adjusted to 309 mm or any value in a range between 639 mm and 849 mm in increments of 30 mm. - Page 9 Horizontal Angle Adjustment Hold the projector’s right and left sides and push it up slightly. Adjust the horizontal angle so that it is correct for the orientation of the screen. The swivel angle can be set within a range of negative to positive 30 degrees.
-
Page 10: Specifications And Diagrams
Specifications and Diagrams Specifications Adjustment Range Height 309 mm, 639 mm, 669 mm, 699 mm, 729 mm, 759 mm, 789 mm, 819 mm and 849 mm. Horizontal angle –30 to +30 degrees Vertical angle -5 to +30 degrees Swing angle -15 to +15 degrees Weight 4.2 kg...
