Thank you for purchasing the Model Boat Products Air Buggy electric boat. These Operating Instructions are
provided to help you enjoy your new Air Buggy without any of the hassles you might expect. Please read
through any and all literature that is provided with your Air Buggy. Doing so will help you become familiar with
how your Air Buggy and radio control system operates.
The MBP Air Buggy is distributed exclusively by
Global Hobby Distributors
18480 Bandilier Circle, Fountain Valley, CA 92708
All contents copyright © 2004, Global Hobby
Distributors Version V1.0 June 2004
Product Part Number: 151151
IMPORTANT
Before beginning assembly, please read and understand the warnings listed on the next page.
Failure to do so could lead to bodily harm and/or injury. The Model Boat Products Air Buggy is not intended for
those under 12 years of age, unless closely supervised by an adult.
OPERATING INSTRUCTIONS
SPECIFICATIONS AND FEATURES:
Length: 13.75 Inches
Width: 8.25 Inches
Run-Time: 12 Minutes (Approximately)
Completely Built and Ready-to-Run
Preinstalled Solid State ESC and FM Receiver
Twin 280 Size Electric Motors with Propellers
6 Cell 900mAH NiMH Battery and 110V AC Charger
Safety Cage Keeps Fingers Out of Propellers
