Xray XLL Link Instruction Manual

Xray XLL Link Instruction Manual

1/12 pan car
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XLL Link and is the answer not in the manual?

Questions and answers

Related Manuals for Xray XLL Link

Summary of Contents for Xray XLL Link

  • Page 2: Before You Start

    We have made every effort to make these instructions as easy to understand as possible. However, if you have any difficulties, problems, or questions, please do not hesitate to contact the XRAY support team at info@teamxray.com. Also, please visit our Web site at www.teamxray.com to find the latest updates, set-up information, option parts, and many other goodies.

  • Page 3: Symbols Used

    (here twice) movement EQUIPMENT INCLUDED TOOLS REQUIRED Diff. Grease Allen Wrench 1.5mm Allen Wrench 2.0mm Allen Wrench 2.5mm Socket Driver 5.5mm XRAY Premium (HUDY #111540) (HUDY #112040) (HUDY #112540) (HUDY #170055) (HUDY #106211) Silicone Oil 350cSt (#359235) TOOLS REQUIRED Pliers...
  • Page 4 GRAPHITE PARTS PREPARATION PREPARE All GRAPhitE PARtS To protect and seal edges of graphite parts, sand edges smooth and then apply CA glue. Lightly file edges of battery slots to remove sharp edges. Do not file battery slots too much, or batteries may protrude below the chassis bottom.

  • Page 5: Front Suspension

    1. fRONT SUSPENSION 965019 372010 372290 372210 372085 372110 372280 377220 902308 373240 901304 372130 902312 372315 372130 371102 372315 372650 372620 903312 372290 372020 964032 960031 960031 372120 FRONt COil SPRiNGS 372220 372291 #372180 C=3.5 - GOLD (standard) 373240 375220 #372181 C=4.0 - SILVER (option)
  • Page 6 NOTE ORIENTATION 3x12 Marked “L“ Lightly tighten setscrews REACtivE CAStER SEttiNG 5.2mm 5.2mm = 2.5° = 5° INITIAL SETTING = 7.5° Use same bushings in left and right sides. ASSEMBLED VIEW ASSEMBLED VIEW NOTE ORIENTATION ASSEMBLED VIEW CASTER CAMBER 902308 902312 901304 SH M3x8...
  • Page 7 Moves freely The number of shims used affects the ride height of the car, so determine the proper amount of shimming based on your tire The number of shims used diameter. Marked “L“ affects the ride height of the For initial setting use 3.1x8x0.5 shims (3x) car, so determine the proper amount of shimming based on your tire diameter.
  • Page 8 INITIAL SETTING FRONt BRACES 0.5mm #372080 ALU ACTIVE BRACE (option) #372085 GRAPHITE BRACE (standard) After inserting clips, carefully tighten all M3x4 setscrews so the pins will not move. Do not overtighten or you may strip the plastic. Loosen all M3x4 setscrews so you If the arm does not have can easily remove the pins.

  • Page 9: Rear Suspension

    3. REAR SUSPENSION 302654 901308 372650 303120 303241 902308 371190 373081 373590 902258 903306 901308 373541 903306 902306 960031 373581 960031 372650 373590 373090 303123 373072 902306 373581 373065 303120 372651 903310 376350 903306 902306 373010 373030 903310 373590 371190 960031 376300 903310...
  • Page 10 Lightly tighten the screws so there is no free play, but do not overtighten otherwise the ball will not move freely. 3x10 3x10 DO NOT TIGHTEN FULLY Ensure free, smooth movement without excessive freeplay. 903306 903310 902306 960031 903310 SFH M3x6 SFH M3x10 SH M3x6 ALU N M3...
  • Page 11 DO NOT TIGHTEN FULLY, BALLS MUST TURN FREELY. ASSEMBLED VIEW TIGHTEN FULLY 960031 903314 902258 903306 ALU N M3 SFH M3x14 SH M2.5x8 SFH M3x6...
  • Page 12 2.5mm NOTE ORIENTATION 2.0mm "CLICK" 901308 903306 303120 SB M3x8 SFH M3x6 SHIM 3x6x2.5...
  • Page 13 2.5mm 2.0mm 902306 902308 303120 960031 903308 303123 960031 903306 902306 SH M3x6 SH M3x8 SHIM 3x6x2.5 ALU N M3 SFH M3x8 SHIM 3x6x2 ALU N M3 SFH M3x6 SH M3x6...

  • Page 14: Ball Differential

    4. BALL DIffERENTIAL 960031 375050 375030 930130 963030 930138 941438 941438 375080 375010 375896 375080 375090 951438 372070 375090 908258 951438 375040 372070 COMPOSITE RIDE HEIGHT ADJUSTER SET (2) 908258 HEX SCREW SOCKET HEAD CAP M2.5x8 (10) 375010 REAR AXLE SHAFT - GRAPHITE 930130 CARBIDE BALL 3.175MM (12) 375030...
  • Page 15 Bearing Oil (HUDY #106230) Use additional shims to widen the rear track-width. Use the same shims on both sides. For initial assembly use 6.4x8.4x1mm shims. Bearing Oil (HUDY #106230) Flanged Flanged The axle must have a VERY small amount of Use these Ride Height sideplay.
  • Page 16 3.2mm 3.0mm 8.0mm 7.8mm Diff Grease (HUDY #106211) Diff Grease (HUDY #106211) NOTE ORIENTATION NOTE ORIENTATION Bearing Oil Diff Grease (HUDY #106230) This nut affects the tightness and stiffness of the (HUDY #106211) rear differential. NOTE ORIENTATION Tighten the nut gently so the diff does not slip under power, but do not overtighten or damage Bearing Oil Diff Grease...

  • Page 17: Shock Absorbers

    5. SHOCk ABSORBERS 378110 970050 BAG 05.1 378110 SIDE SHOCK ABSORBER 378160 971022 378010 378120 965015 378010 378010 901303 378050 378060 378170 378080 965015 971022 971022 378030 378030 ShOCk OilS 378020 378092 378110 901303 #359210 100cSt (option) 378010 #359215 150cSt (option) #359220 200cSt (option) #359225...
  • Page 18 BAG 05 CENTER SHOCK ABSORBER Carefully remove the shock piston from the frame, and remove all excess plastic flash Shock Oil Shock Oil ASSEMBLED VIEW 965015 971022 C 1.5 O 2x2...
  • Page 19 dEFAult ShOCk SEttiNG FOR CENtER ShOCk ABSORBER Follow the steps below to set the shock. HALF TIGHTEN TIGHTEN FULLY 100% 350cSt 3~5x UP & DOWN ➐ Keep the shock shaft ➊ ➋ ➌ ➍ ➎ ➏ pushed in the shock body and tighten the shock cap Extend the shock shaft Move the shock shaft up and...
  • Page 20 INITIAL SETTING ASSEMBLED VIEW Press the collar FULLY onto the end of the shock shaft and tighten the M3x3 setscrew. For initial setting, thread fully. SHOCK 901303 SB M3x3...
  • Page 21 BAG 05.1 SIDE SHOCK ABSORBER NOTE S H O Carefully remove the shock piston from the ORIENTATION frame, and remove all excess plastic flash L O N Shock Oil Shock Oil 965015 971022 C 1.5 O 2x2...
  • Page 22 350cSt 350cSt approx. from top Extend the shock shaft 1) Slowly move the shock Extend the shock shaft 1) Install the 5x1 o-ring Screw fully the shock cap in completly. Fill the shock shaft up so the shock completly to release the onto shock shim.
  • Page 23 CENTER SHOCK ABSORBER SIDE SHOCK ABSORBER The thickness of the side shock oil directly influences the movement of rear pod suspension. The thicker the shock oil, the slower the pod moves. dOWNStOP AdjuStmENt The length of the shock Thicker shock oil will make the car understeer more and absorber affects the amount make it easier to drive.

  • Page 24: Final Assembly

    6. fINAL ASSEMBLY LiPo BATTERY 376130 (not included) SPEED CONTROLLER (not included) 903305 376310 376255 RECEIVER 371320 306219 STEERING SERVO (not included) (not included) 301159 309400 903310 306131 981210 903305 372661 372650 372610 372501 901303 372661 372501 NOT INCLUDED FROM SERVO 375390 902308 NOT INCLUDED...
  • Page 25 We recommend using a micro 3x6x2 for initial setting servo for 1/12 pan cars. LEFT SERVO POSITION Servo (not included) RIGHT SERVO POSITION NOTE from servo ORIENTATION Hitec 26.4mm KO Propo Futaba Left thread Use the adapter that matches your servo. Note the orientation of servo saver when servo is 26.4mm...
  • Page 26 NOTE ORIENTATION Note groove position NOTE ORIENTATION Note groove position 902308 981210 903310 981210 ACKERMANN SH M 3x8 P 2x10 SFH M 3x10 P 2x10...
  • Page 27 Speed controller Receiver wire Motor PiNiON GEARS Alu hARdCOAtEd (not included) (not included) #305968 18T / 64P (option) #305969 19T / 64P (option) #305970 20T / 64P (option) Receiver (not included) #305971 21T / 64P (option) Pinion (not included) #305972 22T / 64P (option) ➊...
  • Page 28 liPo BAttERY CONFiGuRAtiON 1: liPo BAttERY CONFiGuRAtiON 2: Forward Position Rearward Position INITIAL ASSEMBLY BATTERY BATTERY POSITION POSITION 903305 903305 SFH M3x5 SFH M3x5...
  • Page 29 10a. 10b. Nimh BAttERY CONFiGuRAtiON 1: Nimh BAttERY CONFiGuRAtiON 2: Forward Position Rearward Position BATTERY BATTERY POSITION POSITION 903305 903305 SFH M3x5 SFH M3x5...
  • Page 30 Battery Pack ASSEMBLED VIEW (not included) When inserting or removing the batteries from the car, remove the center shock from one of its holders. Rear Wheels & Tires (not included) Front Wheels & Tires (not included) Bearing Oil Fibre Tape (HUDY #106230) (HUDY #107870) (not included)
  • Page 31 NOTES...
  • Page 32 5 8 1 7 0 3 9 1 0 7 2 5...
