Topcom Babytalker PMR 1010 User Manual page 9

20 Push to talk button
21 On/Off Button
22 Lock button
23 Antenna
13 LCD Display information
13.1 Baby unit
(See picture 3 on the folded cover page)
A Call Tones icon
B Channel indicator
C Auto monitor function icon
D Beep tone function icon
E Battery level indicator
F Power adapter connected icon
G Channel Memory indicator
H Tranmission icon
I Channel/Memory channel number
14 Turning the Babytalker 1010 ON/OFF
14.1 Baby unit
14.2 Parent unit
PTT
To turn ON:
• Set the On/Off switch
will show the current channel or memory location.
To switch OFF
• Set the On/Off switch
display will turn blank.
To turn ON:
• Press and hold the
LCD display will display the current channel.
To switch OFF
• Press and hold the
LCD display will turn blank.
13.2 Parent unit
(See picture 4 on the folded cover page)
a Receive icon
b Channel/Memory channel number
c Key pad lock icon
d Speaker volume
e Battery level indicator
f Channel Memory indicator
g VOX icon
h SCAN icon
i Transmission icon
3
to the top position (I), the LCD display
3
to the bottom position (O), the LCD
21
- button . The unit will "beep" and the
21
- button . The unit will "beep" and the
TOPCOM Babytalker 1010
9
