• Faster graphics support makes monitoring and control more efficient.
• Virtual CD enables you to configure and diagnose a server remotely without a visit
from your IT staff.
• IMM supports Secure Sockets Layer (SSL) and Lightweight Directory Access
Protocol (LDAP).
High-performance server subsystems
System x3400 M2 servers are high-throughput, two-way, SMP-capable network
servers with excellent performance scalability when you add memory and a second
processor. They incorporate powerful Intel Xeon DP processors with QPI. These flip-
chip DP chipset 36D processors feature advanced transfer L2 caches integrated onto
the processor core and run at the same clock speed as the processor core.
Two processor connectors are standard on the system board to support installation
of a second processor. High-speed, 1333 MHz DDR3 RDIMMs are optimized for 1333
MHz processor-to-memory subsystem performance. The System x3400 M2 servers
use the Intel Tylersburg DP chipset 36D to maximize throughput from processor to
memory, and system I/O buses.
Standard x3400 M2 configurations
Model Processor
7836-12x 1.86 GHz/4.8 GTS
7836-14x 1.86 GHz/4.8 GTS
7836-22x 2.0 GHz/4.8 GTS
7836-24x 2.0 Ghz/4.8 GTS
7836-32x 2.26 GHz/5.86 GTS
7836-34x 2.26 GHZ/5.86 GTS
7836-42x 2.4 GHz/5.86 GTS
7836-44x 2.4 GHz/5.86 GTS
7836-52x 2.53 GHz/5.86 GTS
7837-12x 1.86 GHz/4.8 GTS
7837-14x 1.86 GHz/4.8 GTS
7837-22x 2.0 GHz/4.8 GTS
7837-24x 2.0 Ghz/4.8 GTS
7837-32x 2.26 GHz/5.86 GTS
7837-34x 2.26 GHZ/5.86 GTS
7837-42x 2.4 GHz/5.86 GTS
7837-44x 2.4 GHz/5.86 GTS
7837-52x 2.53 GHz/5.86 GTS
Note: EMEA x=G
Additional features:
• Ability to upgrade to two-way SMP processing by adding a second processor of the
same speed and processor type.
• System board that contains twelve DIMM connectors supporting 1 GB, 2 GB, and
4 GB DDR3-1333 MHz SDRAMs (model dependent), 8 GB DIMM optional (post
system availability).
– Up to 96 GB of system memory (with 8 GB memory DIMMs installed)
• High-speed, wide-bandwidth, PCI bus slots
– Slot 1 : PCIe2 x8 : PCI-E x8 slot with x8 lanes (Gen2, from IOH) support
– Slot 2 : PCIe2 x16 (8,1) : PCI-E x16 slot with x8 lanes (Gen2, from IOH)
support
– Slot 3 : PCIe2 x8 (4,1) : PCI-E x8 slot with x4 lanes (Gen2, from IOH) support
– Slot 4 : PCIe2 x8 (4,1) : PCI-E x8 slot with x4 lanes (Gen2, from IOH) support
– Slot 5 : PCIe2 x8 : PCI-E x8 slot with x8 lanes (Gen2, from IOH) support
– Slot 6 : PCI-32 : PCI-32 slot with 32-bit/33MHz (from ICH-10) support
• Optional extender board supports 2-PCI-X or one PCI-E x4 slot
• Eight channel SAS/SATA RAID controller that supports high-speed internal storage
solutions
IBM Europe, Middle East, and Africa
Hardware Announcement ZG09-0254
Cache Memory HDD Interface
4 MB 2 GB S/S SATA
4 MB 2 GB HS SFF SAS/SATA
4 MB 2 GB S/S SATA
4 MB 2 GB HS SFF SAS/SATA
8 MB 2 GB S/S SATA
8 MB 2 GB HS SFF SAS/SATA
8 MB 2 GB S/S SATA
8 MB 2 GB HS SFF SAS/SATA
8 MB 2 GB HS SFF SAS/SATA
4 MB 2 GB S/S SATA
4 MB 2 GB HS SFF SAS/SATA
4 MB 2 GB S/S SATA
4 MB 2 GB HS SFF SAS/SATA
8 MB 2 GB S/S SATA
8 MB 2 GB HS SFF SAS/SATA
8 MB 2 GB S/S SATA
8 MB 2 GB HS SS SAS/SATA
8 MB 2 GB HS SFF SAS/SATA
IBM is a registered trademark of International Business Machines Corporation
Mechanical
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
Tower
