D-Link DGS-3610 Series Quick Installation Manual
Hide thumbs
Also See for DGS-3610 Series:
- Configuration manual (703 pages) ,
- Hardware installation manual (26 pages)
Related Manuals for D-Link DGS-3610 Series
Summary of Contents for D-Link DGS-3610 Series
- Page 1 DGS-3610 Series Quick Installation Guide Version 1.1...
-
Page 2: Product Overview
Product Overview The DGS-3610 series is a new generation of 10G multi-layer chassis switch developed by D-Link that features high performance, high-security, intelligence and ease of use. The DGS-3610 switch provides flexible media interfaces, which accommodate various media for connection in networking. In addition, this series can be flexibly expanded with various 10G modules to offer high expandability and meet the needs for large bandwidth. -
Page 3: Prior Preparation
Prior Preparation This switch is already prepared for installation at delivery. Before connecting the power supply and the network, please check all the accessories against the packing list in the packaging carton. Read the installation instructions carefully before you power on the system. -
Page 4: Rack Mounting
To prevent overheating of the switch, place the switch in a location where the ambient temperature is no more than 40° C. Also the spacing of at least 10cm should be reserved around the chassis for good ventilation. Warning Do not place any heavy objects on the switch. Caution Rack Mounting You can also mount the switch in the wiring section of a standard 19-inch rack. -
Page 5: System Connection
Figure 1-3 Schematic Diagram for Fastening the Switch Please ensure that the ventilation holes and fans on both sides and at the back of the chassis are not blocked. Caution System Connection 1.1.2 Connecting the RJ-45 Port Use shielded or unshielded twisted pair cables with RJ-45 connectors on both ends. Use cables of Category 3, 4, and 5 to connect the 10Mbps Ethernet, and use cables of Category 5 to connect the 100/1000Mbps Ethernet ports. - Page 6 1.1.4 Laser Safety Most optical transceiver modules supported by the DGS-3610 series are Class I laser products. Therefore, pay attention to the following during your use of this product: Do not stare into the optical module Tx ends or the connected fiber jumpers, as invisible laser radiation from them may hurt your eyes.
