Owner's Manual
DisplayPort / Mini DisplayPort
v1.2 Multi-Stream
Transport Hubs
Models: (DisplayPort Out) B155-002-DP-V2,
B155-003-DP-V2, B155-004-DP-V2,
B156-002-V2, B156-003-V2, B156-004-V2
(DVI Out) B155-002-DVI-V2, B156-002-DVI-V2
(HDMI Out) B155-002-HD-V2, B155-003-HD-V2,
B155-004-HD-V2, B156-002-HD-V2,
B156-003-HD-V2, B156-004-HD-V2
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate
peace of mind. You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2016 Tripp Lite. All rights reserved.
1
16-02-394-93-35A3-EN.indd 1
3/2/2016 2:39:34 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B155-002-DP-V2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tripp Lite B155-002-DP-V2

Summary of Contents for Tripp Lite B155-002-DP-V2

  • Page 1 Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a $100 value! www.tripplite.com/warranty 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support Copyright © 2016 Tripp Lite. All rights reserved. 16-02-394-93-35A3-EN.indd 1 3/2/2016 2:39:34 PM...

  • Page 2: Product Features

    Product Features • Connect multiple monitors via the DisplayPort or Mini DisplayPort output on your computer to display the same image on each monitor, extend the desktop across monitors, or combine as one enlarged monitor in video wall mode.* • DisplayPort v1.2 and Multi-Stream Transfer (MST) compliant.* •...

  • Page 3: System Requirements

    System Requirements • A computer with a DisplayPort v1.2 compatible Graphics Card (e.g. AMD Radeon with AMD Eyefinity Technology). Backward compatible with most DisplayPort 1.1a equipment running current graphics drivers. The feature set is limited to that of the attached equipment (e.g. you may be limited to displaying in Clone / Mirror mode only).

  • Page 4: Package Contents

    Package Contents • DisplayPort or Mini DisplayPort MST Hub o 2-Port Models: USB Micro-B Cable – 3 ft. o 3- and 4-Port Models: External Power Supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5V 2A) • Owner’s Manual Optional Accessories • P561-Series DVI-D Single-Link Cables •...
  • Page 5 LED will illuminate. 3. (3- and 4-Port Models) – Connect the included external power supply to the hub and plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS) or Power Distribution Unit (PDU). The green Power LED will illuminate.

  • Page 6: Troubleshooting

    Troubleshooting If you are unable to get an acceptable image after following the installation instructions, try the troubleshooting tips below. 1. Is your equipment running the latest graphics driver? If not, download the latest graphics drivers for your equipment. The MST hub is backward compatible with most DisplayPort 1.1a equipment running current graphics drivers.
  • Page 7 It is recommended you use the Tripp Lite cables listed in the Optional Accessories section, as they have been tested to work with the MST Hubs.
  • Page 8 Warranty and Product Registration 1-YEAR LIMITED WARRANTY TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
  • Page 9 • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s authority to operate this equipment. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
  • Page 10 Notes 16-02-394-93-35A3-EN.indd 10 3/2/2016 2:39:34 PM...
  • Page 11 Notes 16-02-394-93-35A3-EN.indd 11 3/2/2016 2:39:34 PM...
  • Page 12 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support 16-02-394 93-35A3_RevA 16-02-394-93-35A3-EN.indd 12 3/2/2016 2:39:35 PM...

This manual is also suitable for:
