Owner's Manual
4Kx2K
UHD HDMI Switch
Models: B119-002-UHD (2-Port),
B119-004-UHD (4-Port)
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2015 Tripp Lite. All rights reserved.
1
15-10-235-933512-EN.indd 1
11/9/2015 10:14:29 AM
Advertisement
Related Manuals for Tripp Lite B119-002-UHD
Summary of Contents for Tripp Lite B119-002-UHD
- Page 1 Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a $100 value! www.tripplite.com/warranty 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support Copyright © 2015 Tripp Lite. All rights reserved. 15-10-235-933512-EN.indd 1 11/9/2015 10:14:29 AM...
-
Page 2: Product Features
Product Features • Switch between multiple HDMI source devices connected to a single HDMI port on a monitor • Switch devices via pushbutton or the included remote control • Intelligent Auto Switching functionality will automatically switch to the next powered-on device when the power to the current device is turned off* •... - Page 3 Package Contents • B119-002-UHD or B119-004-UHD • Remote Control • External Power Supply (Input: 100-240V, 50/60Hz, 0.4A; Output: 5V, 2A) • Owner’s Manual Optional Accessories • P568-Series High Speed HDMI Cables 15-10-235-933512-EN.indd 3 11/9/2015 10:14:29 AM...
-
Page 4: Installation
16 ft. (5 m). 5. Connect the external power supply to the switch, and then plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS), or Power Distribution Unit (PDU). The red Power LED and green Input 1 LED will illuminate to indicate that power is being received. - Page 5 Installation 7. Switch between source devices via the Select pushbutton on the unit or the included remote control. You can also let the Auto Switch functionality automatically switch to ports that are powered on. When multiple ports have powered on devices connected to them, the lowest numbered port will be switched to.
-
Page 6: Troubleshooting
If not, restart them. 3. What resolution are you trying to reach? Tripp Lite’s B119-002-UHD and B119-004-UHD are tested to support 4Kx2K Ultra High Definition (UHD) video resolutions up to 3840 x 2160 @ 60Hz, and 48-bit (16-bits per channel) Deep Color. - Page 7 It is recommended that you use Tripp Lite’s P568-Series High Speed HDMI cables, as they have been tested to work with the B119-002-UHD and B119-004-UHD. 6. Test your cables to ensure they are working properly. For example, connect...
-
Page 8: Specifications
Specifications Model B119-002-UHD B119-004-UHD Connectors Input (x2) HDMI Female (x4) HDMI Female Output HDMI Female HDMI Female Video Maximum 3840 x 2160 (60Hz) 3840 x 2160 (60Hz) Resolution Color Depth 48-bit Deep Color 48-bit Deep Color (16-bits per channel) (16-bits per channel) - Page 9 Warranty and Product Registration 1-YEAR LIMITED WARRANTY TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
