Options
The options are supplied with the option description.
Desig- Description
nation
LBA Local bus adapter for the electronics box. This is
required for installing T300, CB1, TSY, SCB1 and SCB2
T300 Technology board for controlling technological
processes
TSY Synchronizing board
SCB1 Serial communications board with fiber-optic cable for
serial I/O system and peer-to-peer connection
SCB2 Serial communications board for peer-to-peer
connection and USS protocol via RS485
Use of the serial interface with USS protocol
CB1 Communications board with interface for SINEC- L2-DP,
(Profibus)
Use of the PROFIBUS DP interface
Table 6.2 Option boards and bus adapter
If the converter is supplied through an external main
contactor, the option board in the electronics box must
be supplied from an external power supply, according
to Table 6.3.
These values are required in addition to the current
drawn by the basic converter (+ section "Technical
Data").
6-2
Board
description
Board
description
Board
description
Board
description
Board
description
Application
description
Board
description
Application
description
Board
CB1
SCB1
SCB2
TSY w/out tacho
T300 w/out tacho
Standard tacho
Type: 1PX 8001-1
Table 6.3 Current drain of the option boards
SIMOVERT MASTER DRIVES
08.96
Order No.
6SE7090-0XX84-4HA0
6SE7087-6CX84-4HA0
6SE7090-0XX84-0AH0
6SE7087-6CX84-0AH0
6SE7090-0XX84-0BA0
6SE7087-6CX84-0BA0
6SE7090-0XX84-0BC0
6SE7087-6CX84-0BC0
6SE7090-0XX84-0BD0
6SE7087-6CX84-0BD0
6SE7087-6CX87-4KB0
6SE7090-0XX84-0AK0
6SE7087-6CX84-0AK0
6SE7087-6CX87-0AK0
Current drain (mA)
190
50
150
150
620
I 95
0
(190 at 6000 RPM)
