General Description Thank you for purchase the products of Yongnuo firstly. YN-622N-TX i-TTL wireless flash controller is for supporting the use of YN-622N i-TTL wireless flash trigger transceiver. This product adopts flexible LCD menu control, supporting mixed use of the A/B/C three groups of flashes using i-TTL, manua, or super sync flash mode, can be adjusted the exposure compensation or flash output of each group.
The latest version of the compatibility list and user manual, firmware, please visit www.hkyongnuo.com. Upgrade to the latest firmware ver sion before using(P15). YN-622N-TX YN-622N The below icon used in this manual: Refers to short press the button. Refers to long press(hold down) the button.
Supported Functions List LCD screen display, multi-buttons quick operation The firmware can be upgraded through the USB interface Support wireless shutter release function The focal length(zoom)of the A/B/C three groups of flash can be adjusted separately ...
Name of Parts/LCD ※The protective film can be torn out. i-TTL balanced fill-flash High speed sync Battery electricity Rear curtain Sync Channel ZOOM Flash parameter area AF assist beam emitter...
Name of Parts/Quick Start Guide A-LCD: Display all the settings of controller, convenient for your view and setup. B-2.5MM Shutter release interface: Wireless shutter release function(P.13). C-AF assist beam emitter: (P.10) D-PC interface: Input the flash sync signal(P.12). E-USB interface: Firmware upgrade through connecting the computer(P.15).
Preparation Before Use 1. Installing the Batteries Open the cover and install two AA batteries (excluded)according to the marks , rechargeable batteries of 1.2V can be used. Remove the batteries when the product is not used for long time. Please replace the both two batteries at the same time.
Page 11
: Transceiver and Flash Settings Set the transceiver’s receiving group, and set the same channel as the YN-622N-TX controller. Set the flash to i-TTL flash mode*, the flash will fire according to the flash mode and parameters set by the controller , support i -TTL/manual flash.
Setting 1. Groups and Modes Setting(Remote Control) Shooting with a Different Flash Mode for Each Group 1 ) . P r e s s t h e [ G R O U P ] b u t t o n t o choose the setup group, press with the arrow to select A/B/C group.
Page 13
Setting About the Super Sync(SS) Use the non-high speed sync flash to realize higher sync speed, this function is more applicable to strobe flashes whose flash duration is longer, and it is for the camera w h i c h s u p p o r t A u t o F P o n l y. S u p p o r t s e t u p t h e t i m e d e l a y parameter of Super Sync.
Setting 3.ZOOM It support the controller setting the the focal length of the flash lamp holder on the transceiver. Each short press the [ZOOM/CH] button, choose one of the A/B/C group, press the [UP] [DOWN] [LEFT] [RIGHT] buttons to setup, supports the range of setup: 24- 200,AU (automatic), press the [OK] button to confirm.
Flash awaking and triggering 1.Flash awaking&Testing flash When half press the shutter button of the camera or press the [TEST] button of the controller , the awaking indicator light of green light will bright, the hot-shoe flash on the transceiver will be awakened. When loosing the [TEST] button, the groups have been selected of flash will be tested for once.
The other Trigger Modes 1.Non-Remote Control Mode: Set the compatible flash on the transceiver to Manual or RPT flash mode, the flash will work according to the mode and parameters displayed, the controller will not support the remote controlling the flash mode or flash exposure compensation (flash output).
Use the YN-622N transceiver for wireless transmitting, the YN-622N-TX controller as the shutter signal output. 1).Install the YN-622N-TX controller on the camera’s hot shoe, and use LS-2.5 series shutter connecting cable(may additional purchases) to connect the controller and camera.
Reference 1.Flash Shutter Sync: Refer to the camera’s setting. Supports front-curtain sync, rear-curtain sync and high speed synchronous(Auto FP*).The relevant icons will be displayed on the LCD(P.4). Using high-speed synchronization need to set the flash sync speed of the camera to “AUTO FP”. The maximum sync speed is 1/8000s or 1/4000s (depends on the camera).
Page 19
6.USB Firmware Upgrade 1).Visit YONGNUO official website: http://www.hkyongnuo.com/e-detail.php?ID=339 to download the firmware upgrade software and the latest firmware. 2).Turn off . Keep pressing [mode] button and turn on again. The...
Troubleshooting 1. Fail to power on or automatic shutdown: The battery is loaded inversely or exhausted. Install the battery according to the correct direction the Ø battery compartment indicates and ensure the battery is full and restart the power . 2.
The functions of this user manual are based on test conditions of our company. Further notice will not be given if the design and specifications change. The YONGNUO logo in this manual includes the registered trademark or trademark of Shenzhen Yongnuo Photography Equipment Co.,Ltd in China or/and other countries(regions).
