ENGLISH
LCD Television
Model No:NLT-32HDB4
,

Owner s Manual

Please read this manual carefully before operating the unit,
and retain it for future reference.

Advertisement

Table of Contents
loading

Related Manuals for NEC NLT-32HDB4

Summary of Contents for NEC NLT-32HDB4

  • Page 1: Owner S Manual

    ENGLISH LCD Television Model No:NLT-32HDB4 Owner s Manual Please read this manual carefully before operating the unit, and retain it for future reference.

  • Page 2: Table Of Contents

    Wall Mounting Information/ signal source) Technical Drawing Connecting the DVD, VCR or other NEC Service Centers video apparatus using AV and S- VIDEO input FOR LCD TV Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots.

  • Page 3: Safety Instructions

    Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8.
  • Page 4 Safety Instructions - The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. - Minimum distances(e.g. 10cm) around the apparatus for sufficient ventilation “WARNING - To reduce the risk of fire or electric shock, do not expose the apparatus to rain or moisture.

  • Page 5: Installation

    Service Never remove the back cover of the set as this can expose you to very high voltage and other hazards. If the set does not operate properly, unplug it and call NEC Service centre. Aerial Connect the aerial cable to the socket marked ATV/DTV Tuner on the back cover. For the best reception an outdoor aerial should be used.

  • Page 6: Remote Control

    Remote Control Remote Control 1. POWER( ): Press to turn on and off. 2. Mute( ): Switches the sound on or off. 3. 0~9 Number Buttons: Press 0~9 to select a channel, and input the password. 4. SLEEP:Press repeatedly until it displays the time in minutes (10,20, 30, 40, 50, 60, 90, 120 and Off) that you want the TV to remain on before shutting off.
  • Page 7 Remote Control 17. INFO: Press to display the channel information; this information disappears after 9 seconds. 18. PSM: Press to cycle through the picture modes: Cinema/Sport/Vivid/Hi-Bright/User. 19. SSM: Press to cycle through the sound modes: Concert/LivingRoom/Hall/Bathroom/Cave/Arena /Church/Off. 20. ARC: Press to change the screen size, such as Auto, Normal, Letterbox.

  • Page 8: Controls Of Side Panel

    Controls Of Side Panel - Shown is a simplified representation of the set. - Here shown may be somewhat different from your set. INPUT MENU VOL+ VOL- POWER Infrared Receiver Window Power Indicator Infrared Receiver Window MENU To receive the signal from remote control. Selects a menu.

  • Page 9: Controls Of Back Panel

    Controls Of Back Panel - Shown is a simplified representation of the set. - Here shown may be somewhat different from your set. Main Power Switch NLT-32HDB4 COAXIAL OUT AV-OUT HDMI VGA-AUDIO ATV/DTV TUNER AV-IN S-VIDEO IN POWER CORD SOCKET S-VIDEO IN This set operates on an AC power.

  • Page 10: Basic Operation

    Basic Operation Insertion of Batteries: - Turn over the remote control, press and slide off the battery cover. - Insert two 1.5V (AAA) batteries into the compartment, take care to observe the markings indicated inside. - Replace the cover and slide in reverse until the lock snaps. Range of Remote Control - Ensure the remote control is pointed towards the remote control window on the display unit.

  • Page 11: Connecting The Dvd Player Or Hdtv

    Basic Operation COAXIAL OUT AV-OUT HDMI VGA-AUDIO ATV/DTV TUNER AV-IN S-VIDEO IN Connecting the DVD player or HDTV Set-top box using YPbPr input Remove power from the LCD (unplug from the wall outlet) and external equipment before connecting cables. Green 1.

  • Page 12: Connecting The Dvd, Vcr Or Other

    Basic Operation Connecting the DVD, VCR or other video apparatus using AV and S-VIDEO input Remove power from the LCD (unplug from the wall outlet) and external equipment before connecting cables. 1. With a S-VIDEO cable connect the LCD to the VCR or other device. S-VIDEO will connect only the video portion (image only) of the signal.

  • Page 13: How To Connect A Device Using

    Basic Operation How to connect a device using HDMI Connection: Connect the HDMI cable between the HDMI interface on the unit and HDMI output on the device. To play from the device using HDMI: 1. Turn on your TV, then press Source button. The Source menu opens. 2.

  • Page 14: Connecting The Computer Using Vga Input

    Basic Operation Connecting the Computer using VGA input Remove power from the LCD (unplug from the wall outlet) and external equipment before connecting cables. 1. Connect the LCD to the computer with the D-Sub (VGA) cable. 2. Connect the audio output of the computer to the VGA-Audio input on the LCD 3.

  • Page 15: Initial Setup Instruction Guide

    Basic Operation Initial Setup Instruction Guide Please make sure the main power switch is Initial Setup in the"ON" position. Welcome Welcome to use Wizard for Connect the power and antenna to your television; then Initial Setup !! turn on the TV. The first time you use your LCD the initial Please press [ENTER] to start the wizard.

  • Page 16: Power On/Off

    Basic Operation Power ON/OFF: The Display is in Standby mode Please make sure the main power switch is in the "ON" position. - Press POWER ( ) button on the remote control or on POWER the side panel to turn on the unit. The power indicator changes from red to green.

  • Page 17: Osd Functions

    Basic Operation Press the Menu button on the remote control or on the side panel, it will change in the following sequence: Main Menu Menu/exit Sub Menu exit exit 1. Press the Menu button to display the menu system. 2. Press button to select the menu pages.
  • Page 18 6. Basic Operation Adjustment of Saturation (inactive for VGA) “ ” Picture Mode Video Vivid Brightness 1. Press the Menu button, and the Video menu “ ” Audio Contrast Saturation appears. 2. Press or Enter button to enter the Video menu. “...
  • Page 19 Basic Operation Selection of Color Temperature “ ” 1. Press the Menu button, and the Video menu “ ” appears. Picture Mode Video Vivid Brightness 2. Press or Enter button to enter the Video “ ” Audio Contrast menu. Saturation 3.Press button to highlight your selection.
  • Page 20 Basic Operation Table of Video Adjustment Setting Description Item Status Off, Low, Medium, Select to control the sharpness and Strong Auto noise reduction. Off, Low, Medium, Select dynamic color improvement Strong level. Selecting On to correct the flesh “ ” On, Off Flesh Tone tone automatically.

  • Page 21: Audio Page Menu

    Basic Operation Table of Display Adjustment Items Description button to select it. H. Position Use < or > button to move the image left or right. button to select it. V. Position Use < or > button to move the image up or down. button to select it.

  • Page 22: Tv Page Menu (Only For Tv)

    Basic Operation Selection of SPDIF Type “ ” 1. Press the Menu button, and then press Video Balance to select the Audio menu. “ ” Bass Audio 2. Press or Enter button to enter the Audio menu. “ ” Treble Sound Surround 3.
  • Page 23 Basic Operation Using the Channel Scan “ ” 1. Press the Menu button, and then press to select the TV menu. “ ” 2. Press or Enter button to enter the TV menu. “ ” 3. Press or button to highlight your selection. 4.
  • Page 24 Basic Operation Selection of “C hannel Edit ” 1. Press the Menu button, and then press select the “TV” menu. Video 2. Press or Enter button to enter the “TV” Menu. Country Region NSW/ACT Stereo Audio Channel Audio 3. Press button to highlight your selection.
  • Page 25 Basic Operation Item Status Channel Number: 0~9999 1~9, Channel Name: VHF 0~12 UHF 27~69 Television Channel Auto, PAL Color system Sound system Selection of Analog channel Fine Tune “ ”(only for ATV) Video Country Australia 1. Press the Menu button, and then Country Region NSW/ACT Audio...

  • Page 26: Setup Page Menu

    Basic Operation Setup Page Menu Video Time Setup Use of the Time Setup menu “ ” Reset Default Audio 1. Press the Menu button, and then press to select the Setup menu. “ ” 2. Press or Enter button to enter the Setup menu. “...
  • Page 27 Basic Operation Using of Time “ ” Video Time Zone GTM +0:00 Time After entering the Time Setup menu: “ ” Audio Sleep Timer 1. Press button to highlight your selection. 2. Press or Enter button to enter the sub-menu. Setup 3.

  • Page 28: Parental Page Menu

    Basic Operation To Reset Default “ ” The factory setting is to change your own custom setting to factory default setting: Video Time Setup Reset Default 1. Press the Menu button, and then Audio press or button to select “ Setup menu.
  • Page 29 Basic Operation Entering the password Video Password **** . When the password is already stored: Press the Audio Password incorrect Number buttons (0~9) to enter the 4-digit password Please enter again! used for blocking channels. Setup Note: The initial password for the system is “0000” . Parental If you have forgotten the password, use the super password “2580”.
  • Page 30 Basic Operation Video Channel Block Using the Program Block item “ ” Program Block Audio 1. After entering the Parental menu, press or “ ” Input Block Change Password button to highlight the Program Block item. “ ” Clean All 2.
  • Page 31 Basic Operation Video Channel Block Using the “Input Block” Item Program Block Audio Input Block 1. After entering the Parental menu, press or “ ” Change Password Clean All button to highlight the “Input Block” item. Setup 2. Press or Enter button to confirm. Parental 3.
  • Page 32 Basic Operation Using the Channel Block item “ ” 1. After entering the Parental “ ” Video menu, press or button to Channel Block Program Block highlight the Clean Block “ ” Audio Input Block item. Change Password Clean All 2.

  • Page 33: Technical Specification

    Technical Specification Product Model NLT-32HDB4 TV System AUTO/PAL VIDEO System NTSC/PAL 32 Diagonal ” Screen Size 697.685mm(H) x 392.256mm(V) Active Area Aspect Ratio 16:9 Main Unit (with stand) 795 mm (W) x 574 mm (H) x 233 mm (D) Main Unit (without stand)

  • Page 34: Support The Signal Mode

    Support the Signal Mode VGA Mode Horizontal Vertical Frequency Frequency Resolution (Khz) (Hz) 31.5 640 x 480 37.9 37.5 37.9 800 x 600 48.1 46.9 48.4 1024 x 768 56.5 60.0 - When the signal received by the Display exceeds the allowed range, a warning message shall appear on the screen.

  • Page 35: Wall Mounting Information

    *3. First please detach the stand from the unit, then fix the cover board to the corresponding position following as Diagram 2. NEC understand that some user’s may wish to mount their LCD Television on the wall or to fixed surface. All NEC Models have this ability, however we strongly recommend that you have this procedure completed by a specialist installer.

  • Page 36: Nec Service Centers

    Western Australia 131-632 Perth 45 Sarich Court, Osborne Park 6017 For Service in outer areas, please contact your NEC retailer for the address of the nearest Authorised NEC Service Centre NEC Australia Pty. Ltd. Display and Home Group 244 Beecroft Road EPPING 2121...
