- Page 1 USER MANUAL HD-CVI PTZ Speed Dome Model: SCC-242KZNA Version 1.1sfi/0116/engl/A5...
- Page 2 Please follow all instructions and observe the warnings contained in this manual. Please contact your local dealer or SANTEC directly if you have any questions or if you wish to claim for a service or warranty. You will find further information on our website: www.santec-video.com...
-
Page 3: Table Of Contents
User Manual SCC-242KZNA Table of contents Safety precautions Safety instructions About this user manual PART I: CAMERA DESCRIPTION, TECHNICAL SPECIFICATIONS, INSTALLATION 1. Items included in the delivery 2. Technical drawing 3. Connections 4. How to open and close the housing 5. -
Page 4: Safety Precautions
User Manual SCC-242KZNA Safety precautions Caution Description of symbols Danger: This symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to a person. -
Page 5: Safety Instructions
User Manual SCC-242KZNA Safety instructions Before operating the appliance, please read this manual carefully and retain it for further reference. Before cleaning the appliance, it has to be switched off and unplugged from the power outlet. Wipe the appliance with a soft damp cloth. -
Page 6: About This User Manual
User Manual SCC-242KZNA Upon completion of any service or repairs to the appliance, ask the service technician to perform safety checks to verify that the appliance is in proper operating condition. The appliance should only be installed by qualified service personnel and has to comply with local specifications and regulations. -
Page 7: Part I: Camera Description, Technical Specifications, Installation
User Manual SCC-242KZNA Part I: Camera description, technical specifications, installation 1. Items included in the delivery 1x Camera SCC-242KZNA 1x Power adapter 1x Allen wrench 1x Mounting drawing paper 1x Quick installation guide and security notes 2. Technical drawing All dimensions in mm. Drawing not true to scale. -
Page 8: Connections
User Manual SCC-242KZNA 3. Connections The dome camera comes with the following connection options (open cable ends): Connection Colour 24 V AC Power 24 V AC Black Earth Yellow-green Audio In White Audio Black Yellow RS-485 Orange Alarm_IN1 Alarm_IN2 Brown... -
Page 9: Dip-Switch Settings (Only For Rs-485 Connection)
User Manual SCC-242KZNA 5. Dip-switch settings (only for RS-485 connection) Note: Dip-switch settings are only relevant if you connect an external device via RS-485 to the camera (e.g. a control keyboard). If you don’t use the RS-485 connection, the Dip-switches have no function. - Page 10 User Manual SCC-242KZNA Baudrate and parity: Setting the Baudrate (switches 1 and 2): Baudrate 9600bps 4800bps 2400bps 1200bps Einstellung der Parität (Schalter 3 und 4): Parity NONE EVEN EVEN The following default settings apply (factory default): Address: Baudrate: 9600 Parity: None If you change the Dip-switch settings, you need to reboot the camera.
-
Page 11: Installation
User Manual SCC-242KZNA 6. Installation The dome camera can be ceiling or wall mounted. Please ensure that the surface is solid enough to carry the weight of the dome camera. For safety reasons, it is recommended to ensure that the surface can carry 8x the camera weight. -
Page 12: Self-Diagnosis
User Manual SCC-242KZNA 7. Self-diagnosis If you run the dome camera for the first time of if you have reset it to factory default settings, the camera will perform a self-diagnosis test. The following information will be displayed for approx. 4 minutes:... -
Page 13: Technical Specifications
User Manual SCC-242KZNA 8. Technical specifications Model SCC-242KZNA Camera type HD-CVI PTZ dome camera Installation and outdoors Video norm PAL / NTSC 1/2.8” 2 Megapixel Exmor CMOS Image sensor Effective pixel 1944 (H)x 1092 (V) Resolution 1080p, 720p Frame rate... -
Page 14: General
Connect the dome camera, a mouse and a monitor to the recorder. Note: The settings described in this manual are based on using a SANTEC HD-CVI recorder, model SCVR-2411K. It is exemplary for the other SANTEC recorders models. 2. Calling-up the PTZ control menu Login to the recorder using your user name and password. - Page 15 User Manual SCC-242KZNA Zoom, Focus, Iris: Use the plus/minus buttons to adjust the zoom, focus and iris. PTZ direction: Use the 8 direction arrows to move the dome into the desired direction. Select zoom area: In the center of the direction arrows, you will find a button to select a zoom area. Click on this center button.
-
Page 16: Ptz Functions Using The Ptz Control Menu
User Manual SCC-242KZNA 3. PTZ functions using the PTZ control menu 3.1 Calling-up the OSD menu of the PTZ dome camera 1. Call-up the PTZ control menu as described in chapter 2. 2. In the PTZ control menu, click on the arrow on the right hand side to extend the menu: 3. - Page 17 User Manual SCC-242KZNA OSD menu settings using the „Menu Operation“ window: Use the displayed „Menu Operation“ to navigate through the OSD menu by clicking on the arrows. Note: You cannot mouse-click directly on a OSD menu item but you have to use the arrows in the „Menu Operation“...
-
Page 18: Ptz Functions Using The Osd Menu
User Manual SCC-242KZNA 3.2. PTZ functions using the OSD menu Navigate through the OSD menu by using the „Menu Operation“ window (see chapter 2). You can define how long the OSD menu is to be displayed on the screen. See chapter 4.4: ... -
Page 19: Display Setting
User Manual SCC-242KZNA Important note on menu item "Video Output: HD/SD": It is possible to change the video output from HD-CVI (item “HD” in the OSD menu) to 960H CVBS (analogue) (item “SD” in the OSD menu). If you do so, please note the following: When changing the video output of this HD-CVI dome from “HD“... -
Page 20: Camera Setting
User Manual SCC-242KZNA 3.2.3 Camera Setting Use the up/down arrows in the „Menu Operation“ window to select the menu item „Camera Setting“. It is now marked with a diamond. Confirm your selection by clicking on „Enter“. Use the up/down arrows to select a sub-menu item. Use “Enter” to confirm your selection. - Page 21 User Manual SCC-242KZNA Menu item Sub-menu item Additional items / Remarks Day/Night Day/Night Day/night switching: Setting Auto, Night, Day Type Mechanism, Electron. Threshold Switching the day/night mode according to the here defined threshold: 1-8 Back, Exit Focus Focus Mode Setting the focus:...
-
Page 22: Function Setting
User Manual SCC-242KZNA 3.2.4 Function Setting Use the up/down arrows in the „Menu Operation“ window to select the menu item „Function Setting“. It is now marked with a diamond. Confirm your selection by clicking on „Enter“. Use the up/down arrows to select a sub-menu item. Use “Enter” to confirm your selection. - Page 23 User Manual SCC-242KZNA Menu item Sub-menu item Additional items / Remarks Auto Pan Pan Speed Pan speed: 1-8 Alternatively, set the speed using the PTZ contorl menu (see chapter 2). Manual start: The dome begins 360° continuous rotation. Stop Manual stop: The dome stops 360° continuous rotation.
- Page 24 User Manual SCC-242KZNA Menu item Sub-menu item Additional items / Remarks Pattern Pattern No. Pattern number 1-5 Program Start Define a start point. Program Stop Define a stop point. Call Start the selected pattern manually. Stop Stop the selected pattern manually.
- Page 25 User Manual SCC-242KZNA Menu item Sub-menu item Additional items / Remarks PTZ Speed Set Zero Move the dome to the horizontal coordinates. Power Up Power Up Define the PTZ action the dome has to assume when it is booted: None, auto, preset, pattern, tour, scan Parameter Select the number for prreset/pattern/tour/scan.
-
Page 26: Alarm Setting
User Manual SCC-242KZNA 3.2.5 Alarm Setting Use the up/down arrows in the „Menu Operation“ window to select the menu item „Alarm Setting“. It is now marked with a diamond. Confirm your selection by clicking on „Enter“. Use the up/down arrows to select a sub-menu item. Use “Enter” to confirm your selection. -
Page 27: Additional Ptz Functions Using The Ptz Control Menu
User Manual SCC-242KZNA 3.3 Additional PTZ functions using the PTZ control menu In the PTZ control menu, the following additional PTZ functions are available: Symbol Function Symbol Function Preset Flip Tour Reset Pattern Aux config. Autoscan Aux on/off Autopan Enter menu Click on the symbols (e.g. -
Page 28: Aux Configuration
User Manual SCC-242KZNA 3.3.1 Aux configuration Note: The following settings can also be made by using the OSD menu (see chapter 3.2.4). Click on the “Aux config.” symbol. The following window is displayed: Preset: For preset settings, use the direction arrows to move the dome camera into the desired position. - Page 29 User Manual SCC-242KZNA Pattern: For pattern settings, use the direction arrows to move the dome camera into the desired position. Enter a pattern number. Click on „Begin“ or „End“. Border: Use the direction arrows to position the camera within its left and right borders.
-
Page 30: Aux On/Off
User Manual SCC-242KZNA 3.3.2 Aux on/off Click on the aux symbol. The follow window is displayed: The settings defined here depend on the selected protocol. “Direct aux” represent the aux on/off button of a decoder. _________________________________________________________________________________ - 30 -... - Page 31 User Manual SCC-242KZNA Notes: _________________________________________________________________________________ - 31 -...
- Page 32 Your local distributor: __________________________________________________________________________ www.santec-video.com...
