Data Sheet
Marking

Installation

Danfoss Heating Solutions
living connect®, Z-Wave Certified Electronic Radiator Thermostat
living connect® is supplied with adapters for
Danfoss RA valves and valves with M30X1.5
(K) connections (code no. 014G0002), two al-
kaline AA batteries and a 2 mm Allen key.
Inserting the batteries
Remove the battery cover and insert the two
batteries. Ensure that the batteries are cor-
rectly inserted. A capital "M" must flash on the
display before installation.
▪ Start by mounting the adapter.
▪ Tighten the RA adapter using the Allen
key. Tighten the K adapter by hand (max.
5 Nm).
▪ Screw the thermostat onto the adapter
and hand-tighten (max. 5 Nm).
▪ Press and hold for approx. 3 seconds
to fix the thermostat.
VDHMB202
RA
2 mm Allen key
© Danfoss 09/2011
K
3
