LOCATION OF CONTROLS AND INDICATOR
front
16 17
1. EQ Button
2. PRESET - Button
3. PRESET + Button
4. TUNING SKIP/SEARCH
5. TUNING SKIP/SEARCH
6. CD Door
7. FUNCTION Button
8. PLAY/PAUSE
9. STOP/BAND
10. VOLUME
11. VOLUME
12. POWER Button
13. Remote Sensor
18
Button
Button
Button
Button
Button
Button
back
19 20 21 22
top
14. CD Door OPEN/CLOSE
15. STANDBY/ON indicator
16. PHONES Jack
17. AUX IN Jack
18. iPod/USB Tray
19. AC IN Jack
20. Component Pr Jack
21. Component Y Jack
22. Component Pb Jack
23. VIDEO OUT Jack
24. S-VIDEO OUT Jack
25. FM ANT Jack
26. MW ANT Jack
