Snack Drawer

To remove and replace the snack drawer:
1. Pull drawer out to full extension. Tilt up front of drawer and
pull straight out.
2. Replace the snack drawer by inserting the drawer into the
frame rails and push the drawer back into place.
Meat Storage Guide
Store most meat in original wrapping as long as it is airtight and
moisture-proof. Rewrap if necessary. See the following chart for
storage times. When storing meat longer than the times given,
freeze the meat.
Fresh fish or shellfish......................... use same day as purchased
Chicken, ground beef, variety meats (liver) ......................1-2 days
Cold cuts, steaks/roasts................................................... 3-5 days
Cured meats ................................................................... 7-10 days
Leftovers - Cover leftovers with plastic wrap, aluminum foil, or
plastic containers with tight lids.

FREEZER FEATURES

Your model may have some or all of these features.

Ice Service Rack

(on some models)
The ice service rack holds an ice cube tray.
To install and remove the ice rack:
1. Install the ice rack by sliding the L-shaped groove in the side
of the shelf onto the wall screw. Push the rack toward the
back. Then, lower the front of the rack onto the front screw.
2. Remove the ice rack by lifting the front of the rack from the
front wall screw. Then, pull the rack forward and lift up to
unhook it from the rear wall screw.
14

Freezer Shelf

To remove and replace the freezer shelf:
1. Remove the shelf by pulling it out to full extension. Tilt up the
front of the shelf and pull it straight out.
2. Replace the freezer shelf by inserting it into the freezer liner
rails and push it to the back of the compartment.

Wire Basket

To remove wire basket:
Pull drawer open to full extension. Tilt the lower basket forward
and lift out.
To replace wire basket:
Tilt the lower basket front down and set the basket into the
basket cradles on the drawer rail.

Freezer Door Shelf

(on some models)
Convenient storage for smaller frozen food items.
To remove and replace the shelf:
1. Remove the shelf by sliding it up and pulling it straight out.
2. Replace the shelf by sliding it in above the desired support
and pushing it down until it stops.
