- Page 1 SUNNY BOY 4200TL HC / SB 5000TL HC PV Inverter Installation Guide Version 1.1 SBTLHCMS-IEN080411 IME-SB42-50-TLHC...
-
Page 3: Table Of Contents
Technologie AG Table of Contents Table of Contents Explanation of the Symbols Used ... . 5 Foreword ....... 7 2. - Page 4 Table of Contents Technologie AG 8. 3 General Data......35 8. 4 Operating parameters ..... 38 8.4.
-
Page 5: Explanation Of The Symbols Used
Explanation of the Symbols Used Technologie AG 1 Explanation of the Symbols Used To ensure optimum use of this document, note the following explanation of the symbols used. This symbol indicates an example. This symbol indicates a notice which, if ignored, will make the procedure or oper- ation more difficult. - Page 6 Explanation of the Symbols Used Technologie AG Page 6 SBTLHCMS-IEN080411 Installation Guide...
-
Page 7: Foreword
This installation manual is intended solely for qualified personnel. Its aim is to help install and set up SMA inverters type “SB 4200TL HC Multi-String“ or “Sunny Boy SB 5000TL HC Multi-String“ quickly and correctly. -
Page 8: Appropriate Usage
2. 3 Validity of the Documentation The Sunny Boy SB 4200TL HC Multi-String and Sunny Boy SB 5000TL HC Multi-String are identical except for the technical data. The devices are referred to as Sunny Boy in case the information applies for both models. -
Page 9: Safety Instructions
Pay attention to local regulations for the grounding of the modules and the PV- generator. SMA reccomends to electrically bond the module frames, the racks and all metal surfaces and ground these in order to have optimal protection of the system and personnel. - Page 10 Safety Instructions Technologie AG Page 10 SBTLHCMS-IEN080411 Installation Guide...
-
Page 11: Overview
Technologie AG overview 4 overview 4. 1 Unit Description The following diagram gives a schematic overview of the various components and con- nection points inside the Sunny Boy with the cover removed: Varistors, section 10 Socket for communication (RS232, RS485, NLM Piggy-Back, Radio), section 12 Sunny Display Operating... -
Page 12: External Dimensions
overview Technologie AG 4. 2 External dimensions 225 mm 470 mm 490 mm Page 12 SBTLHCMS-IEN080411 Installation Guide... -
Page 13: Installation Requirements
Technologie AG Installation Requirements 5 Installation Requirements Please check that all of the conditions listed below are met before installing and setting up the Sunny Boy. 5. 1 Installation Site Requirements The Sunny Boy weighs more than 31 kg. Please take this weight into account when choosing the installation site and method of installa- tion. - Page 14 Installation Requirements Technologie AG When choosing the installation site, be sure to note the following: Caution: high voltage! Unintentionally pulling out the DC plug connector under load can damage the plug and result in bodily injury or death! Install the Sunny Boy in such a way that it is not possible (e.g.
-
Page 15: Pv Generator Requirements
The unit has six DC plug connectors (four for String A and two for String B) for connect- ing the PV generators. The connecting cables from the PV generators must also be fitted with this type of plug connector. The SMA order codes for the various connectors are as follows: •... -
Page 16: Low-Voltage Grid (Ac)
Installation Requirements Technologie AG 5. 3 Low-voltage Grid (AC) Caution! The feed-in connection is fused by a 25 A circuit breaker type B. No further devices must be connected to the secured cable. The relevant technical regulations and the special instructions of the local grid operator must be followed. - Page 17 Technologie AG Installation Requirements Rating for a Line Circuit Breaker in a Photovoltaic Electrical Power Unit Operated in Grid-parallel Mode Various factors should be taken into account when selecting line circuit breakers. These include, for example: • The type of cable used (conductor material and insulation) •...
-
Page 18: Line Losses
Line losses depending on the cable length and cross-section are shown in the graph below. Multi-wire cables with copper forward and return conductors are used. Sunny Boy SB 4200TL HC Multi-String Do not use cables where the losses will exceed 1.0 % Cable length... - Page 19 Technologie AG Installation Requirements Sunny Boy SB 5000TL HC Multi-String Do not use cables where the losses will exceed 1.0 % Cable length The maximum cable lengths for the different cable cross-sections are as follows: Cable cross-section 6.0 mm² 8.0 mm² 10.0 mm²...
- Page 20 Installation Requirements Technologie AG The Sunny Boy is designed for operation on 220 - 240 V grids at a grid frequency of 50 Hz. When connecting an inverter to the public grid, follow the connection require- ments of the local grid operator. Limit values for AC output Voltage range 198 V ...
-
Page 21: Installation
Technologie AG Installation 6 Installation 6. 1 Mounting the Unit To make the job easier, we recommend you use the supplied wall bracket to mount the Sunny Boy. For vertical installation on solid concrete or block walls, for example, you can fit the bracket using 8 mm x 50 mm hexagon bolts to DIN 571 standard, stainless steel type, and with wall plugs type SX10. -
Page 22: Electrical Installation
Installation Technologie AG Mount the wall bracket (1). To mark the posi- tions to drill the holes, you can use the wall bracket as a drilling template. Now hook the Sunny Boy onto the wall bracket (2) at its upper mounting plate so that it cannot be moved sideways. -
Page 23: View From Below
Technologie AG Installation View from below Socket for the AC plug for Electronic Solar Switch mains connection Plug and socket connector Opening for optional communication via for connection of the solar modules RS232, RS485 or radio (PG16) Installation Guide SBTLHCMS-IEN080411 Page23... -
Page 24: Connecting The Ac Output
Installation Technologie AG 6.2. 1 Connecting the AC Output To connect the AC cable, proceed as follows: Check the grid voltage. The Sunny Boys were prepared for the DIN VDE 0126-- 1-1 in two steps. In the first step the inverter disconnects from the grid when the grid voltage exceeds 253 V. - Page 25 Technologie AG Installation Connect the earth wire (PE) of the mains cable to the upper screw terminal with the earth sign. Reconnect the PE connection on the cover. Fix the housing cover of the and tighten the four screws evenly. Notice! A normal operation of your Sunny Boy requires, among other things, con- necting the PE conductor to the equipotential bonding of the building.
-
Page 26: Pv String (Dc) Connection
Installation Technologie AG 6.2. 2 PV String (DC) Connection To connect up the DC input, follow these steps: Remove the Electronic Solar Switch. Make sure the PV generator connectors have the right polarity and do not exceed the maximum string voltage of 750 V (DC). See also section 5. 2 "PV Generator Requirements"... - Page 27 Technologie AG Installation Repeat points 2 and 3 for each string. Connect up the faultless PV generator strings to the inverter. Ensure the assignment of the strings is correct. Close the unnecessary DC input sockets with the caps included in the delivery. Attach the handle of the Electronic Solar Switch.
-
Page 28: Startup
If despite checking the string voltages the LED signal occurs again when the PV gener- ator is connected to the SUnny Boy, disconnect the PV generator from the Sunny Boy again and contact SMA Technologie AG (see section 13 "Contact" (Page 61)). Page 28... - Page 29 Technologie AG Installation Green Yellow Status Illuminates continu- Is not illuminated Is not illuminated OK (working mode) ously Illuminates continu- Is not illuminated Disturbance ously Illuminates continu- OK (initialization) ously Flashes quickly Is not illuminated Is not illuminated OK (stop) (3 x per second) Illuminates continu- Is not illuminated...
- Page 30 Installation Technologie AG Page 30 SBTLHCMS-IEN080411 Installation Guide...
-
Page 31: Opening And Closing The Sunny Boy
Technologie AG Opening and Closing the Sunny Boy 7 Opening and Closing the Sunny Boy Notice! If you need to open the device for whatever reason, please pay attention to section 3 "Safety Instructions" (Page 9). 7. 1 Opening the Sunny Boy Notice! Follow the sequence below under all circumstances. -
Page 32: Closing The Sunny Boy
Opening and Closing the Sunny Boy Technologie AG 7. 2 Closing the Sunny Boy Caution! Follow the sequence below under all circumstances. Reconnect the earth wire (PE) to the housing cover. Now secure the housing cover to the Sunny Boy by tightening the four screws evenly. The screws must be tight- ened with approximately 4 Nm torque in order to guarantee the sealing of the en- closure. -
Page 33: Technical Data
Technologie AG Technical Data 8 Technical Data 8. 1 PV generator connection data Description Short Setting descrip- SB 4200TL HC SB 5000TL HC tion Max. input voltage 750 V DC, max Input voltage, MPP range 125V ... 750 V Max. input current 11 A for each input area "String A"... -
Page 34: Grid Connection Data
Technical Data Technologie AG 8. 2 Grid connection data Description Short Setting descrip- SB 4200TL HC SB 5000TL HC tion Nominal output power 4000 W 4600 W ACnom Max. output power 4200 W 5000 W ACmax Nominal output current 17.5A... -
Page 35: General Data
Via short circuit diode Protective function AC side Short-circuit proofing Grid-side via current regulation All-pole isolation on grid side Independent disconnection device (SMA grid guard), double imple- mentation External interfaces Data transmission over mains power line optional Data transmission over separate data cable... - Page 36 ηeuro European efficiency 95.5 % The efficiency of the Sunny Boy SB 4200TL HC depends greatly on the input voltage of the connected PV strings. The higher the input voltage, the higher the efficiency. Sunny Boy SB 4200TL HC Output power [kW]...
- Page 37 Technologie AG Technical Data Efficiency Sunny Boy SB 5000TL HC Multi-String Efficiency ηmax Max. efficiency 96.2 % ηeuro European efficiency 95.6 % The efficiency of the Sunny Boy SB 5000TL HC depends greatly on the input voltage of the connected PV strings. The higher the input voltage, the higher the efficiency. Sunny Boy SB 5000TL HC Output power [kW] Installation Guide...
-
Page 38: Operating Parameters
Technical Data Technologie AG 8. 4 Operating parameters Warning! Unauthorized changes to the operating parameters may result in: • injury or accidents as a result of changing the internal safety routines in the Sunny Boy, • voiding the Sunny Boy's operating approval certificate, •... - Page 39 Sunny Boy and want to use the data from the old device. Hardware-DC-BFS Hardware version of the DC operation control unit (DC-BFR) Inst.-Code Parameters for self contained power system recognition can only be changed after entering the SMA grid guard password. Installation Guide SBTLHCMS-IEN080411 Page39...
- Page 40 Plimit Upper limit for AC output power Ripple-Ctl-Frq The Ripple-Ctl-Frq, Ripple-Ctl-Lev, Ripple-Ctl-Rcvr parameters are intended to handle ripple control signals from the SMA inverters. Ripple-Ctl-Lev These parameters are not available for all inverters. These pa- Ripple-Ctl-Rcvr rameters may only be changed after prior agreement with SMA Technologie AG.
-
Page 41: Parameter Settings For Germany
Technologie AG Technical Data Name Explanation Uac-Tavg Averaging time of grid frequency gaging Uzwk-Start The DC voltage required before the Sunny Boy begins feeding power into the mains supply. Usoll-Konst A PV desired voltage for constant operational voltage. These pa- rameters are only important when the "Betriebsart"... - Page 42 0 ... 750 Parameters designated with * are safety-related grid monitoring parameters. To change the SMA grid guard parameters, you must enter your personal SMA grid guard password (Inst.-Code). Please call the SMA Service Line to obtain your per- sonal SMA grid guard password.
-
Page 43: Country-Specific Parameter Settings
Ni-Test T-Start Uac-Min Uac-Max 8.4. 4 Non-modifiable Parameters The following parameters are displayed in the parameter list but cannot be changed: Name Short Factory setting descr. SB 4200TL HC SB 5000TL HC Fac-Tavg Firmware-DC-BFR Hardware-DC- Plimit 4200 5100 SMA-SN Software-BFR... - Page 44 Technical Data Technologie AG Page 44 SBTLHCMS-IEN080411 Installation Guide...
-
Page 45: Inspection Of The Electronic Solar Switch
The Electronic Solar Switch can no longer safely disconnect the DC side if one of the metal tongues is completely worn out (see figure below). The Electronic Solar Switch must then be exchanged. Metal tongues Replacements for damaged Electronic Solar Switch handles are available from SMA. Installation Guide SBTLHCMS-IEN080411 Page45... - Page 46 Inspection of the Electronic Solar Switch Technologie AG Page 46 SBTLHCMS-IEN080411 Installation Guide...
-
Page 47: Replacing The Varistors
The Sunny Boy is a complex high-technology device. As a result, the possibilities for fix- ing faults on site are limited to just a few items. Do not attempt to carry out repairs other than those described here. Use the SMA Technologie AG 24-hour exchange service and repair service instead. - Page 48 (crimp) must be fitted to ter- 4200TL HC Multi-String and SB 5000TL HC minal 1 when replacing the Multi-String and are not commercially available. varistor. They must be ordered directly from SMA Tech- nologie AG (SMA order code: „MSWR-TV6“). Page 48 SBTLHCMS-IEN080411 Installation Guide...
- Page 49 Technologie AG Replacing the Varistors 10. If no replacement varistors are available on site, the Sunny Boy can temporarily run without them. To do this, remove the varistors you identified as being faulty and in their place, bridge the termi- nals 2 and 3 with a length of wire.
- Page 50 Sunny Boy is functioning correctly. If no ground fault and no defective varistor were found, there is probably a fault in the Sunny Boy. In this case, contact the SMA Service Line to discuss what to do next. Page 50...
-
Page 51: Rating For A Line Circuit Breaker
Example for the thermal rating for a line circuit breaker in a photovoltaic electrical power unit operated in grid-parallel mode. A PV system with 9 inverters type Sunny Boy SB 4200TL HC Multi-String or Sunny Boy SB 5000TL HC Multi-String is assumed, with 3 inverters per phase. - Page 52 Rating for a Line Circuit Breaker Technologie AG When selecting line circuit breakers, a number of load factors need to be taken into account. These can be found in the respective data sheets. Example for the thermal selection of a 25 A line circuit breaker with B sensitivity with no gap between the circuit breakers: For example, one manufacturer's circuit breaker may be designed for an ambient tem- perature of 50 °C.
-
Page 53: The Communications Interface
Installation or replacement of the communications interface is only to be carried out by a qualified electrician. The communications interface is used to communicate with SMA communication devic- es (e.g. Sunny Boy Control, Sunny WebBox) or a PC with appropriate software (e.g. -
Page 54: Connection Rs232, Rs485, Radio Piggy-Back
Technologie AG 12. 1 Connection RS232, RS485, Radio Piggy-Back This section describes the installation of the Piggy-Backs for the different Sunny Boy com- munication systems. RS232 Piggy-Back (SMA-Order No: 232PB-MS-NR), RS485 Pig- gy-Back (SMA-Order No:: 485PB-MS-NR), Funk Piggy-Back (SMA-Order No: BEAMPB-NR). -
Page 55: Jumper Functions
Technologie AG The Communications Interface Connect the jumpers (E) if the connection diagram of the communication device indicates this as necessary. The table shown to the right provides an overview of the jumper functions. 10. Plug the communications interface to the left of the board (F). 11. -
Page 56: Powerline Connection
Technologie AG 12. 2 Powerline Connection This chapter describes the installation of the "Powerline Kit" (SMA order number: NLMPB-MS-NR) for the mains grid communication in a Sunny Boy. When opening the Sunny Boy, follow all the safety instructions as de- scribed in section 3. - Page 57 Technologie AG The Communications Interface Open the inverter as described in section 7. 1. Press the lockings at the sides of the plug connector and remove them as displayed in the figure below. Installation Guide SBTLHCMS-IEN080411 Page57...
- Page 58 The Communications Interface Technologie AG Plug the NLM Piggy-Back into the board (F). Do not mount any jumpers. Place the included support (G) of the PLC power module in the socket as seen in the figure (the rightmost). It must snap into place. Then place the PLC power module (H) in the socket as seen in the figure.
- Page 59 Technologie AG The Communications Interface Note on the Different PLC Power Module Variants Different variants of the PLC power module may be delivered. The modules only differ in the location of the sockets for the plug connectors, which may be ei- ther horizontally or vertically arranged (see figure).
- Page 60 The Communications Interface Technologie AG Page 60 SBTLHCMS-IEN080411 Installation Guide...
-
Page 61: Contact
Technologie AG Contact 13 Contact If you have any questions or technical problems concerning the Sunny Boy, contact the SMA Service Line. Have the following information available when you contact SMA: • Inverter type • Type and number of modules connected •... -
Page 62: Exclusion Of Liability
The information contained in this document is the property of SMA Technologie AG. Publishing its content, either partially or in full, requires the written permision of SMA Technologie AG. Any internal company copying of the document for the purposes of evaluating the product or its correct implementation is allowed and does not require permission. - Page 64 Sales Solar Technology www.SMA.de SMA Technologie AG Hannoversche Strasse 1–5 34266 Niestetal, Germany Tel. : +49 561 9522 4000 Fax: +49 561 9522 4040 E-Mail: Info@SMA.de Freecall: +800 SUNNYBOY Freecall: +800 7 8 6 6 9 2 6 9 Innovation in Systems Technology...
