Introduction
The PoE switch supports IEEE 802.3at standard for Power over Ethernet (PoE) with the
maximum power delivery up to 150 Watts. That makes it suitable to various applications that
demand for remote power feeding and meet high level requirement for power. The PoE
switch is totally equipped with 30 Watts per PoE port, which effectively helps allocate power
for connected
Key Features
• Compliant with IEEE 802.3at standard
• Supports Power over Ethernet on 8 ports of 10/100M
• Provides 135Watts (max) Power
• Supports Auto-MDI/MDI-X
• Support Non-Blocking Data Forward
• Supports Auto-Negotiation and feature of store-and-forward
• LED indicators for PoE activity
Package Contents
Before you start installing package contents:
•
PoE Switch x 1
•
Quick Installation Guide x1
•
Power Cord x1
•
Mounting Kits & Screw
•
Rubber feet x4
Quick Installation Guide
8Port PoE+1Uplink/IEEE802.3at/100Mbps
1
Advertisement
Table of Contents
Related Manuals for Repotec RP-PE801
Summary of Contents for Repotec RP-PE801
-
Page 1: Key Features
Quick Installation Guide 8Port PoE+1Uplink/IEEE802.3at/100Mbps Introduction The PoE switch supports IEEE 802.3at standard for Power over Ethernet (PoE) with the maximum power delivery up to 150 Watts. That makes it suitable to various applications that demand for remote power feeding and meet high level requirement for power. The PoE switch is totally equipped with 30 Watts per PoE port, which effectively helps allocate power for connected Key Features... -
Page 2: Front Panel
Front Panel LED indicators For definitions of LED indicators, please refer to the following table: Status Indication On/Green Power is On Power is off UpLink On/Green Uplink port is in connection Blink/Green Receiving or transmitting data No device attached On/Green The Ethernet port is connecting with the device Port1~8 Blink/Green... -
Page 3: Specifications
For cable selection, refer to the following table: Network Speed Cable Type Max. Length Cat.3,4,5,5eUTP/STP 100 meters 100M Cat. 5,5e UTP/STP 100 meters Note :To prevent costly equipment damage and downtime, please consider installing a surge uppression device or a UPS (Un-interrupted Power Supply). Specifications IEEE 802.3at IEEE 802.3 10 BaseT... - Page 4 FCC MARKING This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
