Ultrasonic Nebulizer
NE-U780
(NE-U780-E)
Instruction Manual
■ This product is a medical device and should be used under the guidance of a physician. For type, dose,
and regime of medication, follow the instructions of your doctor or pharmacist.
■ This product is not designed to function as a home-use inhaler for the purpose of moistening the mucous
membranes of the nose and throat.

Table of Contents

Important Information
Intended Use ...............................1
Exemptions ..................................3
Know Your Unit
Product Features .........................4
Packaging Contents ....................5
Display .........................................5
Part Names .................................6
Operating Instructions
Before Inhalation .........................7
Inhalation Method ......................10
Care and Maintenance
Maintenance ..............................16
Disinfecting ................................19
Storage ......................................21
Technical Data, Warranty, etc.
Troubleshooting .........................22
Technical Data ...........................23
Warranty ....................................26
IM-NE-U780-E-01-11/2015
EN
FR
DE
IT
ES
NL
RU
AR
5371508-1B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NE-U780 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omron NE-U780

Summary of Contents for Omron NE-U780

  • Page 1: Table Of Contents

    Operating Instructions Before Inhalation ......7 Inhalation Method ......10 Inhalation Method (using optional accessories) ..13 Ultrasonic Nebulizer Care and Maintenance Maintenance ......16 NE-U780 Disinfecting ........19 Storage ........21 (NE-U780-E) Technical Data, Warranty, etc. Instruction Manual Troubleshooting ......22 Technical Data ......23 Optional Medical Accessories ...25 Warranty ........26...

  • Page 2: Intended Use

    Intended Use Medical Purpose This product is intended to be used for inhaling medication for respiratory disorders. Intended User Legally certified medical experts, such as doctor, nurse and therapist Caregiver or patient under the guidance of qualified medical experts Intended Patients Patients with asthma, nasal inflammation, or COPD Patients requiring humidified oxygen after surgery Environment...

  • Page 3: Important Safety Precautions

    Do not get nebulized medication in your eyes. Do not operate the nebulizer with the medication cup empty. Approved for human use only. Use only OMRON original and optional accessories specified for this device. Do not add more than 150 ml of medication to the medication cup.

  • Page 4: Exemptions

    (1) Unplug the product and ensure that it cannot be used. (2) Keep others from using the product by labeling it as broken. (3) Contact the distributor from which you purchased the product or an authorised OMRON retail outlet. Exemptions OMRON is not liable for any of the following: 1.

  • Page 5: Product Features

    Vibrator Product features A professional ultrasonic nebulizer with a removable tank The OMRON NE-U780 Ultrasonic Nebulizer features a removable water tank that can be submerged in liquid for disinfection and cleaning purposes. 1. Smooth shape for easy cleaning The main unit is easy to clean and disinfect by using sheet switches and air pathways that can be easily wiped clean and disinfected.

  • Page 6: Packaging Contents

    Packaging Contents ■ Medication cup cover ■ Medication cup holder Note: Includes silicon packing (Washer). ■ Main unit Note: Air filter already attached. ■ Mouthpiece ■ Inhalation hose M ■ Power cord ■ Removable water tank ■ Medication cup × 2 Note: This product provides Note: Includes handle cover.

  • Page 7: Part Names

    Part Names Medication Silicon packing (Washer) cup cover installation location Silicon packing (Washer) Medication Mouthpiece Inhalation hose Handle Display Medication Page 5) cup holder Removable water tank Water tank contact Power button Float button (detection of the shortage of water) Vibrator ■...

  • Page 8: Before Inhalation

    Before Inhalation 2. Placing your finger under the Clean and disinfect the product’s protrusion on the medication parts before using the product for cup holder, remove the the first time and after the product nebulization set. has not been used for an extended period of time.
  • Page 9 Before Inhalation 3. Align the mark on the Adding medication cup cover with the mark on the medication cup medication to the holder, press them together, medication cup and rotate the cover clockwise to the position indicated by the mark. 1.

  • Page 10: Main Unit

    Before Inhalation 3. Make sure the power button is in the “OFF” position and Assembling the connect the power cord to the main unit main unit and a wall outlet. Note: Use only the 1. Secure the removable water original power cord. tank in the main unit.

  • Page 11: Inhalation Method

    Inhalation Method Setting the Setting the inhalation time air-flow volume and nebulization Press the TIMER(MIN) buttons to set volume the inhalation time. ● Setting the timer Using the AIR-FLOW VOLUME adjustment The timer can be set to an interval of up to and the NEBULIZATION 30 minutes in 1-minute increments.
  • Page 12 Inhalation Method Pressing the Inhaling the aerosol START/STOP <Example use> button The START/STOP LED will light up, the fan will turn on, and nebulization will start. An inhalation mask (optional) can be used instead of the mouthpiece. ● During inhalation Do not bend the inhalation hose or block the mouthpiece.
  • Page 13 Inhalation Method ● To stop inhalation while using Stopping the timer Press the START/STOP button to stop inhalation operation. The remaining time will be reset, and the timer will revert to the time that was set initially. To restart inhalation, press the ●...

  • Page 14: Inhalation Method (Using Optional Accessories)

    Inhalation Method (using optional accessories) Using a bacterial filter You can use the optional U17-2-E Bacterial Filter to generate air from which bacteria has been removed. The filter cannot be reused and should be discarded after use. The following optional accessories are required in order to use the U17-2-E Bacterial Filter: Long time Nebulization set NEB-LMCC-78E Fan cover for bacterial filter NEB-BFC-78E An additional inhalation hose M NEB-HS-L70E...
  • Page 15 Inhalation Method (using optional accessories) Using as a humidifier When using as a humidifier, connect the external Air volume Oxygen oxygen supply to the optional NEB-LMCC-78E adjustment lever pipe Long time Nebulization set’s oxygen pipe. To stop air from the main unit’s fan, for example to allow for oxygen therapy, set the air-flow volume to “0”, remove the air volume adjustment lever, Air outlet cap...
  • Page 16 Inhalation Method (using optional accessories) Fill the supply medication Supply medication set (U10-11-E) bottle with medication. Make sure that there is silicon packing (Washer) on the inside of the supply medication bottle Supply medication bottle cap and close the cap tightly. Note: Failure to do so will allow air to leak into Supply the bottle from the cap, causing the...

  • Page 17: Maintenance

    Maintenance Maintaining the product’s parts Remove the nebulization set Warning from the removable water tank When assembling the product, do not directly touch and disassemble it. parts through which the medication or aerosol will pass. Do not touch the vibrator while the product is plugged in.
  • Page 18 Maintenance Inspecting the air filter When the nebulization time has exceeded about 100 hours, the “ CHECK FILTER” Error LED will flash. Inspect the air filter. Turn off the power button and Remove the air filter case and disconnect the power cord make sure the air filter is not from both the main unit and contaminated.
  • Page 19 Maintenance Fan maintenance Turn off the power button and Reattach the fan, air filter case, disconnect the power cord and fan cover. from both the main unit and When reattaching the fan, push it firmly all the outlet. the way onto the fan installation axis. Align the medication cup cover so that it is once more connected to the fan cover.

  • Page 20: Disinfecting

    Disinfecting Disinfecting the main unit ● Sterilization with an EOG sterilizer Only the main unit can be sterilized with an EOG sterilizer. Do not attempt to sterilize the removable water tank or other parts with an EOG sterilizer. Refer to the sterilizer’s instruction manual and contact the EOG sterilizer manufacturer for more information.
  • Page 21 Disinfecting ● Disinfection chart Parts can be disinfected using the methods listed in the chart below. For more information about disinfecting the main unit, see “Disinfecting the main unit”. ( Page 19) For more information about the disinfection process, see the disinfectant’s instructions and precautions. Note: Materials are indicated by the following abbreviations: Acrylonitrile butadiene styrene resin: ABS, Poly phenylene sulfide resin: PPS, Polyethylene resin: PE, Polycarbonate resin: PC, Polymethylpentene: PMP, Polypropylene resin: PP, Polystyrene resin: PS,...

  • Page 22: Storage

    Disinfecting Boiling Chemical Parts Materials Autoclave water disinfectant Mask: TPE Inhalation mask (L) set String: Rubber (Do not disinfect string.) (Do not disinfect string.) (Do not disinfect string) Mask: TPE Inhalation mask (S) set String: Rubber (Do not disinfect string.) (Do not disinfect string.) (Do not disinfect string.) Inhalation hose M Hose: TPE Inhalation hose L...

  • Page 23: Troubleshooting

    Page 9) Note: If the suggested remedy does not solve the problem, do not try to repair the device - the device is not user serviceable. Return the device to an authorised OMRON retail outlet or distributor.

  • Page 24: Technical Data

    ** Measured values reflect internal data obtained by NEXT GENERATION IMPACTOR (NGI), using 30 ml of NaF aqueous solution. Measured by OMRON HEALTHCARE Co., Ltd., according to EN13544-1:2007+A1:2009. *** Measured by OMRON HEALTHCARE Co., Ltd. Note: Performance may vary with medication such as suspensions or high viscosity. See medication supplier's data sheet for...
  • Page 25 EN60601-1-2:2007 standard has been implemented. This standard defines the levels of immunity to electromagnetic interferences as well as maximum levels of electromagnetic emissions for medical devices. This medical device manufactured by OMRON HEALTHCARE conforms to this EN60601-1-2:2007 standard for both immunity and emissions.

  • Page 26: Optional Medical Accessories

    (within the scope of EC Medical Device Directive 93/42/EEC) The following optional accessories listed below are available. To order an optional accessory, please contact an authorised OMRON retail outlet or distributor. Note: Materials are indicated by the following abbreviations: Acrylonitrile butadiene styrene resin: ABS, Poly phenylene sulfide resin: PPS, Polymethylpentene: PMP,...

  • Page 27: Warranty

    Warranty Thank you for buying an OMRON product. This product is constructed of high quality materials and great care has been taken in its manufacturing. It is designed to give you a high level of comfort, provided that it is properly operated and maintained as described in the instruction manual.
  • Page 28 Manufacturer OMRON HEALTHCARE Co., Ltd. 53, Kunotsubo, Terado-cho, Muko, KYOTO, 617-0002 JAPAN EU-representative OMRON HEALTHCARE EUROPE B.V. Scorpius 33, 2132 LR Hoofddorp, THE NETHERLANDS www.omron-healthcare.com OMRON HEALTHCARE Co., Ltd. Production facility Matsusaka Factory 1855-370, Kubo-cho, Matsusaka-shi, Mie, 515-8503 Japan OMRON HEALTHCARE UK LTD.
