INSTALLATION INSTRUCTIONS

Rear USB Inputs

Two USB connector cables are located at the rear of the Motor 3 radio

IF USING A BEZEL

assembled radio from behind the dash until the bezel and radio face

IF USING A FACEPLATE, slide the radio into the hole from behind the

Using the supplied washers and shaft nuts (see "What's In the Box" on

Finally, you'll need to secure the rear of the radio using the supplied

back strap mounts using the threads in the rear of the radio body and

can be bent and adjusted to align with the mounting point of the

The included shaft covers may be used to cover up excess shaft metal

Slide the rear knob over the shaft, rotating it into the correct position,
