BOARD'S
100-PIN I/O
CONNECTOR
I/O PINS 1 TO 50
SIGNAL
CONDITIONING or
50-PIN SCREW
TERMINAL BOARD.
Figure 3-2. Cable C100FF-xx Configuration
C100FF-xx
SIGNAL CONDITIONING OR
50-PIN SCREW TERMINAL BOARD
4
CABLE
I/O PINS 51 TO 100
