2 INSTALLATION

The PCI-DIO96 boards are completely plug-and-play. There are no switches or
jumpers on the board. All board addresses are set by your computer's plug-and-play
software.
InstaCal is the installation, calibration and test software supplied with your data
acquisition / IO hardware. Refer to the Extended Software Installation Manual to
install InstaCal.
If you need it, there is some on-line help in the InstaCal program.
Owners of the Universal Library should read the manual and examine the example
programs prior to attempting any programming tasks.
3 I/O CONNECTIONS

3.1 CABLES AND SCREW TERMINAL BOARDS

The board has a 100-pin, high-density Robinson-Nugent male connector (Figure 3-1).
A C100FF-x cable is used to split the 100 I/O lines into two, 50-wire cables. One
connector has pins 1 to 50, the other has 51 to 100. The two I/O connectors can be
connected directly to two screw-terminal boards such as the CIO-MINI50,
CIO-TERM100, CIO-SPADE50 or SCB-50. See Figures 3-2 and 3-3 for
configuration and pin out.
