TG7511CX(e).book Page 1 Wednesday, March 24, 2010 8:41 AM
Before initial use, see "Getting
Started" on page 8.
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and save
them for future reference.
This unit is compatible with Caller ID. You must subscribe to the appropriate
service offered by your service provider/telephone company.

Operating Instructions

Digital Cordless Phone
KX-TG7511CX
Model No.
